Summary of Contents for Mobi Technologies MOBI-WIFI
- Page 1 User Manual (Mobi-WiFi)
- Page 2 Product Feature MOBI-750 is a video recording device helping analyze the causes of accidents by providing video, audio and location information recorded at the time of vehicle accidents caused by shocks, sudden unintended accelerations, etc. Continuous Recording Function It records video images at all time regardless of the occurrence of an accident Event (Shock) Recording Function It records video images for a certain period of time before and after a shock on a vehicle is detected.
-
Page 3: Table Of Contents
Index Safety Instructions ....................................Precautions in Using the prodcuct ............................... Product Configuration ................................... Product Part Name ....................................7 Installation ......................................9 1. Blackbox installation ................................9 2. Connection of Video output Cable............................11 3. Insertion of a micro SD memory card ........................... 11 Product Usage .................................... -
Page 4: Safety Instructions
Safety Instructions Instructions for user’s safety and prevention of properties damages. Please carefully read these safety instructions before using the product. Avoid installing the product in the area preventing from safe driving. Do not disassemble or repair the product and apply any strong shock on the product. Do not try to operate the product when driving. -
Page 5: Precautions In Using The Prodcuct
Precautions in using the product Before starting to use the product, please read this user manual carefully and use the product correctly. After mounting the product on a vehicle, try to check before use if the product is working properly by carrying out the test for manual video recording and shock sensing. -
Page 6: Product Configuration
Product Configuration Power cable Micro SD card Main Body (Cigar Jack) Micro SD card Fixing Tape VIDEO Cable (RCA Cable Holder adapter type) Wireless Wifi Receiver GPS Receiver User manual (option) Product configuration is subject to change without prior notice for function or quality improvement. ... -
Page 7: Product Part Name
Product part name Front Back ① ② Upper ⑦ ⑨ ⑩ ⑧ ④ ⑤ ③ ⑥ Name Description Security LED Displays Security operating condition of the product. Camera Records front view images of a vehicle. Speaker Place that voice or event sound is heard Power Connection Terminal Place to connect power cable. - Page 8 Right Side Left Side ⑫ ⑬ ⑪ Name Description USB Connector Connects Wifi Receiver. Slot for micro SD memory card Slot where the micro SD memory card is inserted Power Switch Turns power on/off Operation Security Power LED Operation LED Power LED Status LED Security LED...
-
Page 9: Installation
Installation 1. Black box installation. * Select the best spot for mounting of the product linked with a navigation device and a smart phone before installation by checking if it blocks driver's view and if it prevents the operation and mount it on the selected spot. 1) After selecting the best spot for the mounting of MOBI-750, align the camera angle of the product to be in line with the ground. - Page 10 5) Firmly attach the product not to be fallen off by thoroughly pressing the area of the mounting cradle where the product is attached with the double- sided adhesive tape. Attach GPS receiver as well in the proper position firmly not to be fallen off. ...
-
Page 11: Connection Of Video Output Cable
2. Connection of Video output cable Connect a video output cable to the body of MOBI-750 Connect a video cable to 'VIDEO' port on the top of the body and RCA cable in the opposite side (yellow area on the picture) to the A/V INPUT of a navigation device. -
Page 12: Product Usage
Product Usage Explanation on recording features of MOBI-750 1. Continuous Recording The video images are automatically recorded and saved in the micro SD memory card once the power is supplied to the Black box even the product is not set in an external shock mode or manual recording mode. The constant recording images will be saved in [Normal] folder. -
Page 13: Manual Recording
3. Manual Recording In case that recording function is necessary in addition to the basic constant recording mode, the image can be saved in manual recording mode In case that the left button in the main body is pressed, a voice prompt saying 'video images are being recorded' will be heard and images for total 20 seconds 10 seconds before/10 seconds after the button is pressed in case of MOBI-750, will be saved in the micro SD memory card at the same time. - Page 14 Setting of parking mode Automatic mode: it automatically switches to the parking mode if no shock is detected for 20 minutes while ignition of a vehicle is turned on Manual mode: it manually switches to the parking mode when the right button in the main body is pressed and held for more than 5 seconds, (Manual mode is prior to Automatic mode and it switches immediately to the parking mode by pressing and held the right button in the main body for more than 5 seconds even the automatic mode is on)
-
Page 15: Audio Recording
5. Audio Recording Voice recording function can be turned on or off during images are being recorded. Voice recording function can be turned on or off by pressing the left button in the main body for more than 5 seconds ... -
Page 16: Voice Guidance Description
Voice Guidance description Operation Voice Prompts Remark Power ON Ding-dong + Hello. This is MOBI-I When starting recording or resuming Initiating image recording. recording GPS is connected. When GPS is connected Power is disconnected When external power is cut Memory card cannot be recognized after Please check the memory card power is on Please restart system. -
Page 17: Button Function Description
Button function description Following functions can be carried out by using buttons in the main body. Button Menu - Press short: Manual recording function ※ When recording function is OFF Left Button ‘ Triple beep sound’ will be heard - Press and hold (more than 5 seconds): ※... -
Page 18: Structure Of Storage Folders And File Name
Structure of storage folders and file name Recorder video images are saved by mode in the micro SD memory card. The saved video images are saved in a regular video file format and can be played in popular PC video playback programs (Window media, KMP, etc.) MOBI-750 ... - Page 19 2) If the relevant folder is clicked, saved video files and JPG files are displayed. (Ex.: Event folder) - JPG file is a image files used to display the saved file in a thumbnail image. - The name of the video files will be saved by category shown below. Ex.) E000_0711105035 E000 0701 10 50 35...
-
Page 20: Environment Setting
Environment Setting MOBI-750 The function in MOBI-750 playing video images saved in a micro SD memory card by smart phones equipped with a slot for a micro SD memory card is one of the additional features to the basic function available in an ordinary Black box and may be limited in some smart phones. - Page 21 3) Run 'MOBI WiFi' application program and then main window shown below will display. Please use default network SSID and password set at the time of shipment from the factory until the product is confirmed to work properly after installation of the product in a vehicle and it, after confirming proper working of the product, is highly recommended to immediately change the default network SSID and password to your own choices through the dedicated viewer for your own security.
- Page 22 Live Video This is a live view function making it possible to view, through a smart phone, the video images being currently recorded in a micro SD memory card. Play Video ‘If ‘Files in Local Storage' is clicked, ‘If ‘Files in the Black box' is clicked, the images downloaded to a smart phone will be played.
- Page 23 If a folder is clicked, list of video images stored If a video image is clicked, thumbnails are displayed as shown in under the folder will be displayed the left picture and if [Download] is clicked, video images will start to be downloaded to a smart phone - If [Cancel] is clicked, download of video images will be stopped.
- Page 24 Setup Product parameters such as image recording quality, voce recording, etc. can be changed Video recording quality: Select the quality of the image to be stored (Setting values: Maximum/Normal/Minimum) Audio Record: Set to activate or deactivate voice recording function. ...
- Page 25 Shock detection in the parking mode: Set the shock sensitivity in the parking mode. (Setting values: 1 minimum sensitivity ~ 5 maximum sensitivity) Shock detection in the driving mode: Set the shock sensitivity in the driving mode. (Setting values: 1 minimum sensitivity ~ 5 maximum sensitivity) ...
- Page 26 Emergency Service License number of a vehicle: Enter license number of a vehicle to be displayed in emergency service. After entering the license number, press [Confirm] button. Driver's information: Enter driver's information. After entering driver's name, press [Confirm] button. ...
-
Page 27: Use Of Dedicated Viewer
Use of Dedicated Viewer After installing MOBI-I dedicated viewer in a PC, the video images saved in a micro SD memory card can be played back. Note Even the saved video images can be played back in ordinary video programs, information such as driving speed or route (map) can be checked in the dedicated viewer only. -
Page 28: Viewer Screen Description
4) Short cut icon of the dedicated viewer will be generated in the desktop screen upon completion of the installation. Viewer Screen description ① ⑫ ⑬ ② ⑪ ⑩ ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ Name Description This is a connection Icon of MOBI-I homepage. Playback Screen Play back the saved video images. - Page 29 Name Description : Stop the playback of video image. : Play back a previous file : Move to previous playback screen. : Move to the video image played one second before. Buttons to control : Play back video images. playback : Move to the video image behind one frame : Move to the next playback screen fast.
-
Page 30: Playback Of Video Images In A Dedicated Viewer
Playback of video images in a dedicated viewer The video images saved in a micro SD memory card can be played back using the dedicated viewer 1) Remove the micro SD memory card from the product and insert it into a PC using a card reader after packed it in an appropriate adaptor. -
Page 31: How To Capture Images
5) When the video file is played back, map information linked with GPS is displayed at the top right side of the screen allowing to identify the driving routes and locations - The map can be magnified and 3 modes of map/satellite/combination are provided. -
Page 32: How To Capture Video Images
How to capture video images The part of a video image being played back can be stored. In the middle of playback of video images, stop a screen temporarily by pressing 'pause' button or hit the space bar. Select a video section you want to store by adjusting playback section selection bar (bar in green). -
Page 33: Environment Setting Using Dedicated Viewer
Environment setting using dedicated viewer Detailed environment parameters of the product can be set through the dedicated viewer How to set the detailed environment parameters 1) Click [Environment setting] button in the playback window of the dedicated viewer 2) When environment parameter window is popped up, change the settings suitable for your use. - Page 34 2) Setting in the parking mode Switch to automatic parking mode: Set to enable or disable the automatic switch to parking mode. (Setting values: on / off) Monitoring a vehicle in parking: Select the type of monitoring a vehicle in parking (Setting values : Shock sensor/Motion detection) ...
-
Page 35: Specification
Specification Operating temperature - 20 ° ~ +70 ° Input Voltage DC12V / DC24V Operation Voltage Min DC8V ~ Max DC30V (FREE) Camera Color CMOS Sensor 1/4" Image sensor resolution 1600 X 1200 Pixel 2 Megapixel File format AVI (H.264 / PCM) Recording resolution 1280 X 720P 30 frames / sec (Max) Video clip...
