- Page 1 We.R Family and Home Management Kit We.R Control Unit (M8000C) User Manual Essence Home & Family Ltd. www.essence-grp.com © 2010 Essence Home & Family. Information contained within this document may change without notice, v0.3...
-
Page 2: Table Of Contents
Contents Welcome! ........................4 Radio frequency interference statement ..............4 System Activation ....................6 Registration ......................7 Installing We.R Application on your Mobile ............7 We.R Applications – Control Your System Remotely .......... 9 Web Application ....................9 Mobile Application ................... 10 Managing Devices .................... - Page 3 Disarm ......................25 Handling Alarms ....................26 Burglary Alarm ....................26 10 Watching Real-Time Videos ................. 27 10.1 Web Application ....................27 10.2 Mobile Application ................... 27 11 History – Reviewing Past Events ................ 28 11.1 Web Application ....................28 11.2 Mobile Application ...................
-
Page 4: Welcome
Welcome! This manual will assist you in installing and using your new We.R Family and Home Management Kit. Soon, you will be able to use a web browser, mobile phone or key fob to monitor and secure your premises with state-of-the art motion detection, image capture and window/door sensors. - Page 5 Consult the dealer or an experienced radio/TV technician for help. Essence Home & Family is not responsible for any radio or communication interference caused by using other than specified or recommended cables and battery or by unauthorized changes or modifications to this equipment. Unauthorized changes or modification could void the user’s authority to operate the equipment.
-
Page 6: System Activation
1 System Activation 1. Open back of control unit and write the 8-digit alpha-numeric serial number here for future reference : 2. Insert SIM card. 3. Plug the power cable into the control unit and into an electrical socket. (The light on the front of the control unit will glow orange.) 4. -
Page 7: Registration
2 Registration 1. Open a PC-based web browser and go to www.wersystem.com. 2. If prompted, install the Microsoft "Silverlight" web application framework from http://silverlight.net. 3. Click on the "Register" button, then click "Go to first time registration page" Enter the 8-digit alpha-numeric serial number taken from the Control Unit during the “System Activation”... - Page 8 4. Click “Send Link”. 5. On the mobile phone, click on the link received within the SMS message and follow the instructions on the phone to load the We.R mobile software. 6. If prompted where to install the application, select phone memory. Page 8 of 30...
-
Page 9: We.r Applications - Control Your System Remotely
4 We.R Applications – Control Your System Remotely 4.1 Web Application Log-in to the We.R system at www.wersystem.com to access the web-based user interface to operate the system. The system screens can be accessed through the Menu button, located on the left side of the display. -
Page 10: Mobile Application
4.2 Mobile Application 1. Open the We.R Mobile application 2. If prompted to “Allow application We.R Mobile to use network and send or receive data?”, then click “Yes”. 3. Enter your 4-digit PIN Code (from step #6 of “Registration” section), then click “Login”. -
Page 11: Managing Devices
5 Managing Devices The kit you have purchased contains devices that were already added to the kit in our factory, and so, they should not be added again to the system by you. The “Adding a New Device” section below refers to new devices that were purchased separately from the basic kit and the keyfob. - Page 12 3. You can customize the following advanced properties for cameras, motion detectors and window/door magnets: “Part arm” scenarios Detection behavior when armed Detection behavior when disarmed a. Part arm scenarios: Use this feature to make your everyday use of the we.R system customized to your unique needs.
-
Page 13: Removing Existing Device
i. Day Arm – this scenario is mostly used for child care and safety, allowing you to monitor and protect zones while at home. For example, monitor your medicine cabinet by simply associating the medicine cabinet door sensor with the “day arm” scenario and activate this scenario while at home. -
Page 14: Editing Existing Device Details
5.1.3 Editing Existing Device Details 1. Select the device on the device list. 2. In the “Device properties” window on the right, edit the relevant fields. 3. Click “Save” 5.1.4 Device Status The system informs you regarding the current status of each installed device. The status includes the following: - Low battery. -
Page 15: Mounting And Activating Devices
6 Mounting and Activating Devices TIP: When mounting all devices, ensure to attach the device to a surface that is clean, dry, flat and smooth – for optimal performance of the adhesive. 6.1 Mounting Camera 1. Please note that the Camera functions also as a Motion Detector. 2. - Page 16 4. Place the Motion Detector in a suitable location that does not face into sunlight or other strong light sources. 5. For optimal surveillance, the Motion Detector should be placed in a position where it will detect movement inside the home. 6.
-
Page 17: Mounting Window / Door Sensors
6.3 Mounting Window / Door Sensors 1. Each window / door sensor has 2 components: a Magnetic Detector and a smaller Magnet. Remove one Magnetic Detector from the box. Open the Magnetic Detector, using a coin or a screw driver, insert one AA battery and then close the device. -
Page 18: Mounting Indoor Siren
9. For a quick test while magnet is fully installed: Close the door / window – a Green light will glow, indicating correct installation. Open the door/ window – a red light will glow, indicating correct installation. 10. For detaching the Magnetic Detector from the surface of the door or window (in case of battery replacement or any other maintenance activity) insert a coin or a screw driver to hole, at the side of the device, and lift the Magnet cover up. -
Page 19: Buttons And Indications
To insert the batteries: Using a small coin, rotate the battery cover ¼ turn counter-clockwise, until the two dots on the battery cover and the back of the device are adjacent to one another, and remove the cover. On the battery, note the surface marked +, indicating positive polarity. With the surface marked + facing up, insert the battery into the battery holder. - Page 20 Table 1: Buttons and LEDs Description ARM button and LED DISARM button NIGHT-ARM button and LED DAY-ARM button and LED STATUS button The table below summarizes the possible states of the LEDs. Table 2: LED States Status Description Status Short Press on Status Button –...
-
Page 21: Managing Users
7 Managing Users 7.1 Web Application In the We.R System, go to the Menu and select “Users”. 7.1.1 Adding a New User 1. Click “Add New User”. 2. In the “New User properties” window on the right, enter information for all fields: ... -
Page 22: Removing Existing User
Mobile# – The user’s mobile phone (country code and number-digits only) PIN Code – a unique 4-digit number to enter the We.R Mobile application Send System Messages Via – For users of non-compatible phones, select “SMS” to receive SMS messages only. ... -
Page 23: Removing Existing User
Master – Administrative privileges & full access to system functions Standard – Full access to system functions 3. Click "Add". 7.2.2 Removing Existing User 5. Select the user in the users list. 6. Click “Remove User” Page 23 of 30... -
Page 24: Arming And Disarming The System
8 Arming and Disarming the System 8.1 Arm 1. When the system is disarmed, you can arm it by pressing one of the “Arm” buttons: a. “Full Arm” your system to protect all zones while away. This will arm all of the devices in your premises and alarm will be triggered by any detection. -
Page 25: Disarm
Force Arm When arming the system, one or more of the devices may be tampered or open (in case of monitored window/door). In this case you will be notified about these devices and the system will allow you to perform a “force arm” – activate the arm anyway, while the tampered and open devices will be bypassed. -
Page 26: Handling Alarms
9 Handling Alarms 9.1 Burglary Alarm 1. Once your system is armed, a burglary alarm will be triggered in the following cases: a. A monitored window/door was opened b. A motion was detected by the motion detector or the camera 2. -
Page 27: Watching Real-Time Videos
10 Watching Real-Time Videos 10.1 Web Application 1. On the main “Dashboard” screen, in the center “Camera/s” section, select your Camera and push the “Play” button. 2. A 45 second video clip will run on your display. 10.2 Mobile Application 1. -
Page 28: History - Reviewing Past Events
11 History – Reviewing Past Events Review historical events of all types (security, safety, comfort) Get additional event information by selecting from the events list and reviewing the data in the “Event properties” window on the right. Watch recorded videos by selecting relevant event and playing video in the “Event properties”... -
Page 29: Mobile Application
11.2 Mobile Application On the main Status screen of the We.R Mobile application, click "Menu", then "History". Page 29 of 30... -
Page 30: Troubleshooting
12 Troubleshooting 1. Trouble Activating a Device - If you have trouble activating a device within the system, please ensure that the device is at least 2 meters away from the control unit. If that does not help, then please perform these steps to restart the system: a.
