Summary of Contents for Hanson Technology FelTouch 100
- Page 1 FelTouch 100 User’s Manual | Hanson Technology Limited...
-
Page 2: Table Of Contents
Remote Control: Front, Back and Side panels ............5 Function items ......................6 USB dongle ........................8 Installation .......................... 9 Touch actions ........................10 Operating Modes ......................13 Function Buttons ....................... 14 Software compatibility ...................... 16 Other Technical Specifications ..................17 Contents | Hanson Technology Limited... -
Page 3: Introduction
HTPC (Home Theater PC) that are connected to TV in living room, OR other places where mouse/keyboard operation is not convenient (for example, no desk and standing surface for mouse/keyboard operation). Product overview A summary of this product features is Introduction | Hanson Technology Limited... - Page 4 Capacitive touch with high sensitivity Mouse alternative use Full QWERTY keyboard Stylish touch, button zero design Touch gestures for navigation - zoom in/out, scroll up/down 90 degree rotation for landscape operation Operated by normal AA batteries | Hanson Technology Limited...
-
Page 5: Getting Started
Getting Started Product package The product package includes FelTouch remote control FelTouch USB dongle AA Battery X 3 Remote Control: Front, Back and Side panels Actual top cover pattern is showed in next page. Getting Started | Hanson Technology Limited... -
Page 6: Function Items
FelTouch 100 Function items Notification LED, see description below Getting Started | Hanson Technology Limited... - Page 7 Function buttons are for Mode changes of the device. They include power on/off, switch between cursor mode and keyboard mode, rotate the device 90 degree to more fit into modern TV/ display landscape view. Getting Started | Hanson Technology Limited...
-
Page 8: Usb Dongle
Surbox. This device works as a standard USB HID mouse and keyboard, means users can choose FelTouch mainly as cursor operation and key inputs (with short messages), and at the same time, still able to use full function keyboard for text input intensive applications. Getting Started | Hanson Technology Limited... -
Page 9: Installation
FelTouch remote device. This device can work for 2 months, or last longer, from one time battery change. However, the actual work time may be different based on various usage patterns and different battery models. Installation | Hanson Technology Limited... -
Page 10: Touch Actions
(1-2 sec.) until activation. Parallel line 1. Two fingers touch in parallel, To scroll up and down when cursor vertically or horizontally. is on browsing mode. 2. LED color will change between GREEN and RED. Touch actions | Hanson Technology Limited... - Page 11 Move right to browse content right, horizontally. index. Slide Left One finger touches the active Only work in Media Control mode. area and move from right to Move left to browse content index. Touch actions | Hanson Technology Limited...
- Page 12 Move up to browse content index. top, vertically. Slide Down One finger touches the active Only work in Media Control mode. area and move from top to Move down to browse content bottom, vertically. index. Touch actions | Hanson Technology Limited...
-
Page 13: Operating Modes
Mouse button. And LED Media control actions does not work flashes 1-3 times in short period to reflect Media control : current gesture mode. Enable all touch gestures And media control actions But cursor is not work Operating Modes | Hanson Technology Limited... -
Page 14: Function Buttons
At Windows OS mode, it opens up the [Start] menu. Menu At Android OS mode, it slides up the MENU tool bar. At Windows OS mode, it opens up the tool window – same as the function by pressing mouse Right button. Function Buttons | Hanson Technology Limited... - Page 15 In Media Control mode, it is used to select an item, while other touch operations are limited to gestures only. Delete In text edit, it sends [DELETE] command to device. Function buttons are always active, not related to which mode the device is set to. Function Buttons | Hanson Technology Limited...
-
Page 16: Software Compatibility
New touch gestures dedicated to specific software items are being added continuously, based on customer feedback and demand. FelTouch also works together with other HID devices seamlessly, as it complies to the same USB HID class standard and 2.4GHz RF regulations. Software compatibility | Hanson Technology Limited... -
Page 17: Other Technical Specifications
10 meter @ 2.4GHz frequency band Host interface USB device with HID keyboard/mouse class Software support Android OS, Windows, Mac OS, and Linux USB class support HID classes – Keyboard, Mouse, Consumer Audio Other Technical Specifications | Hanson Technology Limited... - Page 18 Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Other Technical Specifications | Hanson Technology Limited...
