Industriefunkuhren
_____________________________________________________________
Technical Manual
Network Clock Device
Model 8030NTS/NCD
For DIN Rail Installation
(DIN EN 60715 TH35)
Version: 04.00 - 19.06.2018
_____________________________________________________________
SET
Valid for
Version: 04.xx
ENGLISH
IMAGE (8030)
FIRMWARE (8024)
Version: 04.xx
Version: 02.xx
Advertisement
Table of Contents
Related Manuals for hopf Elektronik GmbH 8030NTS/NCD
Summary of Contents for hopf Elektronik GmbH 8030NTS/NCD
- Page 1 Industriefunkuhren _____________________________________________________________ Technical Manual Network Clock Device Model 8030NTS/NCD For DIN Rail Installation (DIN EN 60715 TH35) ENGLISH Version: 04.00 - 19.06.2018 _____________________________________________________________ IMAGE (8030) FIRMWARE (8024) Valid for Version: 04.xx Version: 04.xx Version: 02.xx...
- Page 2 2 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
- Page 3 Functionality Disregard may impact function of system/device. Information Notes and Information. Network Clock Device 8030NTS/NCD - V04.00 3 / 36 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
- Page 4 EU directive - especially with regard to protection of health and safety for the operator and the user - and may be released for sale within the common markets. 4 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH...
-
Page 5: Table Of Contents
.......... 20 7 HTTP/HTTPS WebGUI – Web Browser Configuration Interface ....... 22 8 SSH and Telnet Basic Configuration ................. 23 9 Fault Analysis / Troubleshooting ................24 Network Clock Device 8030NTS/NCD - V04.00 5 / 36 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... - Page 6 11.2 Technical Data of the modules ................27 11.3 Power Supplies ....................... 27 11.4 Dimensions – DIN Rail Housing................29 12 Factory Defaults of Time Server 8030NTS/NCD ............30 13 Glossary and Abbreviations ..................30 13.1 NTP-specific Terminology..................30 13.2 Abbreviations ......................31 13.3 Definitions .......................
-
Page 7: Network Clock Device 8030Nts/Ntc
EVICE Network Clock Device 8030NTS/NCD The Network Clock Device 8030NTS/NCD consists of a Network Time Client 8030NTC and a Network Time Server 8030NTS/M. Module 8030NTC acts as time source for the appliance, module 8030NTS/M as NTP Stratum 1 Time Server or as PTP Grandmaster. - Page 8 Diffferent Managemenet and Monitoring Functions are availabe as options (e.g. SNMP, SNMP-Traps, E-mail notification, Syslog-messages including MIB II and private Enterprise MIB). A few other basic functions of the Network Clock Device 8030NTS/NCD: • Operates as NTP Server with Stratum 1 or as PTP Grandmaster •...
- Page 9 8030NTS/NCD ETWORK LOCK EVICE Overview of the functions of the Network Clock Device 8030NTS/NCD: Ethernet Interface • Auto negotiate • 10 Mbps half-/full duplex • 100 Mbps half-/full duplex • 1 Gbps full duplex Time Protocols • RFC-5905 NTPv4 Server...
-
Page 10: System Structure
Views of the Network Clock Device 8030NTS/NCD with AC and DC power supply. Housing The Network Clock Device 8030NTS/NCD is built into a closed aluminium profile housing for horizontal DIN Rail mounting according to DIN EN 60715 TH35. Power Supply Currently the following types of power supplies are available: •... -
Page 11: Function Principle
UNCTION RINCIPLE Function Principle This chapter describes the function principle of the Network Clock Device 8030NTS/NCD and the internal relations between the different functional groups. Block Diagram • Internal Supply Voltage The individual functional components are supplied with the required operating voltage via the implemented power supply unit. -
Page 12: Function 8030Ntc
Module 8030NTS/M will be adjusted based on the time information delivered by module 8030NTC and provides this time information to all other activated network time services. 12 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 13: System Behaviour
This chapter describes the behaviour of the system in special operational phases and condi- tions. Boot Phase The boot process of the Network Clock Device 8030NTS/NCD starts after turning on the sys- tem or a reset. During the boot process the Modules 8030NTC and 8030NTS/M boots its operation system and is therefore not available via LAN. -
Page 14: Installation
The installation of the Network Clock Device 8030NTS/NCD is described below. Installation/Dismounting of the DIN Rail Housing The Network Clock Device 8030NTS/NCD can be mounted on all rails in accordance with DIN EN 60715 TH35 and is designed for horizontal mounting. -
Page 15: Protective Earth Conductor (Grounding)
NSTALLATION Protective Earth Conductor (Grounding) Grounding of the Network Clock Device 8030NTS/NCD is achieved via the PE line of the power supply wiring. Power Connection Depending on the version of the appliance an AC or DC power feeding is available. -
Page 16: Connection To Various Power Networks
The connector must always be mounted using the housing and strain re- lief fitting provided. 16 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 17: Voltage Input / Fuse Protection
Further equipment protection is not required because the device is fused internally. Recommended External Fuse When connecting the Network Clock Device 8030NTS/NCD a suitable fuse protection of the power supply needs to be observed. Accordingly, the performance data should be taken from the nameplate of the device. Cur- rently the standard versions of the Network Clock Device 8030NTS/NCD are supplied with power supplies with power consumption between 6 and 15VA. -
Page 18: Power Supply Unit Specifications
All specifications regarding the DC power supply can be found in Chapter 11.3 Power Sup- plies. 5.3.2.2 Fuse Protection When connecting the Network Clock Device 8030NTS/NCD a suitable fuse protection of the power supply needs to be observed. Accordingly, the performance data should be taken from the nameplate of the device. Cur- rently the standard versions of the Network Clock Device 8030NTS/NCD are supplied with power supplies with power consumption of max. -
Page 19: Commissioning
OMMISSIONING Commissioning For putting Network Clock Device 8030NTS/NCD into operation the application must be sup- plied with voltage first. After that modules 8030NTC and 8030NTS/M can be configured. Please have a look at the individual module-manuals how to put both applications into opera- tion. -
Page 20: Network Configuration For Eth0 Via Lan Through Hmc
Network Configuration for ETH0 via LAN through After connecting the system to the power supply and creating the physical network connection to the LAN interface of the modules from the Network Clock Device 8030NTS/NCD, the mod- hopf ules can be searched for on the network via the Management Console). - Page 21 OMMISSIONING The determination of different devices (or other products variants) is made via Hardware Ad- dress (MAC Address). For an extended configuration of the Time Server 8030NTS/NCD through a browser via WebGUI the following base parameters are required: • e.g. hopf8030nts Host Name •...
-
Page 22: Http/Https Webgui - Web Browser Configuration Interface
Detailed information can be found in the module specific technical manuals of the modules 8030NTC and 8030NTS/M. 22 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 23: Ssh And Telnet Basic Configuration
SSH and Telnet Basic Configuration Only basic configuration is possible via SSH or Telnet. The complete con- figuration of the Network Clock Device 8030NTS/NCD takes place exclu- sively via the WebGUI. It is just as easy to use SSH (Port 22) or Telnet (Port 23) as the WebGUI. Both protocols use the same user interface and menu structure. -
Page 24: Fault Analysis / Troubleshooting
24 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 25: Maintenance
The Network Clock Device 8030NTS/NCD is generally maintenance-free. The following points should be observed if a cleaning of the system might be necessary. 10.1 General Guidelines for Cleaning The following must not be used to clean the Network Clock Device 8030NTS/NCD: • Fluids •... -
Page 26: Technical Data
EN 60950-1 : 2006 MTBF MTBF > 250,000h 26 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 27: Technical Data Of The Modules
Function Display (Power LED) LED green LED green Network Clock Device 8030NTS/NCD - V04.00 27 / 36 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... - Page 28 Function Display (Power LED) LED green LED green 28 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com...
-
Page 29: Dimensions - Din Rail Housing
ECHNICAL Dimensions – DIN Rail Housing 11.4 Network Clock Device 8030NTS/NCD - V04.00 29 / 36 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 30: Factory Defaults Of Time Server 8030Nts/Ncd
8030NTS/NCD ACTORY EFAULTS OF ERVER Factory Defaults of Time Server 8030NTS/NCD The factory settings of the two modules of the Network Clock Device 8030NTS/NCD can be found in the respective module description. Glossary and Abbreviations 13.1 NTP-specific Terminology Stability The average frequency stability of the clock system. -
Page 31: Abbreviations
µsec microsecond (10 seconds) parts per million (10 Network Clock Device 8030NTS/NCD - V04.00 31 / 36 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 32: Definitions
NTP can be installed over firewalls and offers a range of security functions. See RFC 5905 for further information. 32 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 33: Snmp (Simple Network Management Protocol)
The PTP-devices use either Ethernet or UDP for their network communication. UDP uses the Ports 319 and 320. Network Clock Device 8030NTS/NCD - V04.00 33 / 36 hopf Elektronik GmbH... -
Page 34: Accuracy & Ntp Basic Principles
3. It goes without saying that the accuracy of the synchronised time cannot be better than the accuracy resolution of the local clock on the NTP server and NTP client. 34 / 36 Network Clock Device 8030NTS/NCD - V04.00 hopf Elektronik GmbH... -
Page 35: List Of Rfcs
• SYSLOG (RFC 5424) • SMTP (RFC 5321) Network Clock Device 8030NTS/NCD - V04.00 35 / 36 hopf Elektronik GmbH Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: +49 (0)2351 9386-86 • Fax: +49 (0)2351 9386-93 • Internet: http://www.hopf.com • E-Mail: info@hopf.com... -
Page 36: List Of Open Source Packages Used
OURCE ACKAGES List of Open Source Packages Used hopf Network Clock Device 8030NTS/NCD includes various software packages which are subject to other license conditions. In case the use of such a software package might hopf violate the licence conditions will ensure immediately after written notice that the licence conditions are met again.
