Agrison ME8000 Operating Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
https://tractormanualz.com
ME80
000 Excavator
O O pe
erating Manual
ti g M
l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ME8000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Agrison ME8000

  • Page 1 https://tractormanualz.com ME80 000 Excavator O O pe erating Manual ti g M...
  • Page 2 https://tractormanualz.com FOREWORD This manual contains information, such as technical parameters, safety information, operation, lubrication, maintenance, adjustment and Accidents check guidelines which is primarily for the operator and the maintenance crew. The operator should read this manual carefully before operating or working on the excavator.

  • Page 3: Table Of Contents

    https://tractormanualz.com INDEX I.MACHINE DESCRIPTION AND TECHNICAL DATA Machine description, technical data…………………………………………………….1 Ⅱ.SAFETY INFORMATION General safety information……………………………………………………………….5 Crushing and burn prevention……………………………………………………………6 Fire and explosion prevention……………………………………………………………7 Machine start up safety……………………………………………………………..……8 Machine operating safety………………………………………………………….….….8 Machine parking safety……………………………………………………………….….10 Machine transportation safety……………………………………………………………10 Machine towing safety…………………………………………………………….….….11 Machine maintenance safety……………………………………………………………..11 Hydraulic pipeline……………………………………………...
  • Page 4 https://tractormanualz.com Maintenance principles of the excavator………………………………………………..66 Fuel system………………………………………………………………………………66 Air filter………………………………………………………………………………….67 Undercarriage……………………………………………………………………………68 Checking mounting screws for tightness………………………………………………...69 Hydraulic system………………………………………………………………………...69 The electrical system…………………………………………………………………….70 The swing and travel brake……………………………………………………………...71 Adjusting the clearance of the bucket…………………………………………………...72 Replacing wear and tear items…………………………………………………………..72 Maintenance schedule…………………………………………………………………...72 Ⅵ.TROUBLE ANALYSIS GUIDELINE Engine trouble…………………………………………………………………………...76 Trouble of electrical system……………………………………………………………..76 Others……………………………………………………………………………….…...77...
  • Page 5 https://tractormanualz.com Ⅰ. MODEL AND TECHNICAL SPECIFICATIONS Engine Model YC4F60Z-T10 No. of cylinders Vertical, Water-cooled,4 Stroke, In line Bore and stroke 92x100 mm Displacement 2.66L Rated power 43Kw/2200rpm Max. torque 215N.m/r/min Fuel consumption <230g/kwh Oil consumption <2 g/kwh Travel system Type Travel motor Variable axial piston motor Low speed...
  • Page 6 https://tractormanualz.com Swing system Swing motor type Swash plate-piston motor Brake Oil release Parking brake Hydraulic disc Swing speed 10~13rpm Tail swing radius 2700mm Cab controls New ergonomic cab, which strengthens the structure of the entire stamping, with the feature: strong impact resistance, vibration damping pads, absorbing vibration, comfortable with broad vision, using of leather...
  • Page 7 https://tractormanualz.com Volume of Hydraulic tank/ system 120L/420L Bucket Mode backhoe bucket 0.3m³ Capacity No. of teeth Width of bucket 651mm Digging force Boom Length 3250 mm Arm length 2000mm Bucket digging force 115KN Arm digging force 92.5KN Operating weight ,ground pressure shoe width 420mm Material...
  • Page 8 https://tractormanualz.com Normal operating range...

  • Page 9: Ⅱ.safety Information

    https://tractormanualz.com Ⅱ.SAFETY INFORMATION Working with an Excavator can be dangerous; it could result in injury or death if proper precautions are not taken! We urgent you to read this manual carefully! This safety information is provided to operators and maintenance mechanics to ensure the safe operation and maintenance of the Excavator.

  • Page 10: General Safety Information

    https://tractormanualz.com GENERAL SAFETY INFORMATION Study the Operation and Maintenance Manual before operating or working on the excavator. Make sure that you have additional information for special attachments of your machine, read it and understand it! Allow only authorized personnel informed about the safety rules to operate, service or repair the excavator.

  • Page 11: Fire And Explosion Prevention

    https://tractormanualz.com Do not install any equipment or attachments made by other manufacturers or any which are not specifically authorized by Shandong Kadekor Power Machine Co.,Ltd for installation without first obtaining the written permission from Shandong Kadekor Power Machine Co.,Ltd. Never work underneath the excavator unless it is safely resting on the ground and /or is properly blocked and supported and /or it is properly blocked and supported.

  • Page 12: Machine Start Up Safety

    https://tractormanualz.com MACHINE START UP SAFETY Before excavator start up, perform a thorough walk around inspection. Visually inspect the excavator, look for loose bolts, cracks, wear, any leaks and any evidence of vandalism. Never start or operate an unsafe excavator. Report all defects to your foreman or supervisor and make sure they are corrected immediately.
  • Page 13 https://tractormanualz.com Be alert of changing weather conditions, bad or insufficient visibility and of changing ground conditions. Be alert for utility line, check the location of underground cables, gas and water lines, and work especially careful in that vicinity. If necessary and/or if required, call local authorities to mark the location.

  • Page 14: Machine Parking Safety

    https://tractormanualz.com device designed for this specific application. Allow only experienced persons to attach loads or to guide operators. The guide must be visible by the operator and/or must be in voice contact with him. Depending on the attachment combination, it is possible for the bucket teeth to hit the cab, the cab protection or the boom cylinders.

  • Page 15: Machine Towing Safety

    https://tractormanualz.com underpasses, utility lines, and in tunnels. During the unloading procedure, proceed with the same care and caution as during the loading procedure. Remove all chains and wedges. Start the engine as outlined in the Operation and Maintenance Manual. Carefully drive off the loading platform. Keep the working device as close as possible to the ground level.
  • Page 16 https://tractormanualz.com capacity. Never position yourself, walk or work underneath suspended loads. Never use damaged lifting devices or devices which are not sufficient to carry the load. Always wear gloves when handling wire cables. Ask only experienced personnel to attach loads and guide and signal the crane operator. The guide must be within the visibility range of the operator and /or must be in direct voice contact with the operator.

  • Page 17: Additional Safety Guideline For Cabin

    https://tractormanualz.com inspection: -- Damage on the external layer into the inner layer (such as chaffing, cuts and rips) -- Brittleness of the outer layer and -- Changes in shape. -- Corrosion on fittings, Crack, wear and squeeze. -- Storage or service life has been exceeded. When replacing hoses or lines, always use the original parts of Shandong Kadekor Power Machine Co.,Ltd.
  • Page 18 https://tractormanualz.com Other signs should be treated as the same as the above mentioned. 1. Warning Sign on hydraulic oil tank: To avoid being scalded. Caution 1. Turn off the Engine before open the cover. 2. Don’t open the cover when the oil temperature is high. 3.

  • Page 19: Ⅲ.operation And Control

    https://tractormanualz.com Ⅲ OPERATION AND CONTROL “OPERATION AND CONTROL” contains the following items. 1. Position of each parts 2. Cab 3. Instrument panel 4. Appliance board 5. Air conditioner system 6. Sound system 7. Adjustment of seat 8．Safe belt 9. Front glass 10.
  • Page 20 https://tractormanualz.com 1. boom 2. boom cylinder 3. bucket arm cylinder 4. bucket arm 5. bucket cylinder 6. connecting rod 7. connecting rod 8. bucket 9. swing platform 10. engine hook 11. fuel tank 12. hydraulic oil tank 13. cab 14. balance weight 15.

  • Page 21: Instrument Panel

    https://tractormanualz.com 2－2 1.Instrument panel 5.left joystick 9.travelling bar 13.radio 2.starting switch 6.right joystick 1O.trabelling bar 3. horn switch 7.manual accelerator 11.safe bar 4.AC control panel 8.dozer blade joystick 12.buttons...
  • Page 22 https://tractormanualz.com 1. Instrument panel Fig. 2-8 2. Starting switch Fig 2－3 Start and stop the engine A. “start” position-turn to this position, electric appliances on, the charging and engine oil pressure lights on B “off” position-turn to this position, the engine flameout, electric system power C “switch on”...
  • Page 23 https://tractormanualz.com Horn switch (right joystick) 4. AC control panel Fig 2－5 a. AC switch (Fig, 2-6) Clockwise rotate the AC switch when the engine is running, AC compressor works, turn back to the OFF position, the AC compressor stop. b. blowing rate switch(Fig 2-6 left switch) blowing rate switch is to control the blowing Fig 2－6...
  • Page 24 https://tractormanualz.com The joystick control the movement of boom and bucket, press the button on the top of the stick, the horn sound. 7. Hand throttle control It is to control the engine speed. A: low speed, B: high speed Fig 2－ 9 8.
  • Page 25 https://tractormanualz.com 12. Radio Refer to the sound...
  • Page 26 https://tractormanualz.com Instrument panel Water temperature gauge Fuel level gauge Working hour gauge Engine speed indicator Company logo mute Fig 2-14 Instrument panel mainly includes water temperature gauge, fuel level gauge, working hour gauge, engine speed gauge and mute button. 1. Water temperature gauge : LCD blue part indicate, when temperature is from 40-106℃, it indicate the green area, when temperature is above 106℃, it indicate the red area and the buzzer sound, press the mute...
  • Page 27 https://tractormanualz.com 3. Working hour indicator to show the total working hour of the engine, it ranges from 0-19999.9h, showed accurately on the LCD. 4. Mute button: when the indicators indicate there is some faults happens to the machine, the buzzer sound, when it is sound, press the button now the mute indicator light, buzzer stop sound.
  • Page 28 https://tractormanualz.com ▲ WARNING If the front glass is dry, please first spray water, then use the windshield, unless it may break the glass or the wiper. When there is some sand or dirt on the glass, please clean the glass first, then use the windshield, unless it may break the glass or the wiper.

  • Page 29: Keyset

    https://tractormanualz.com Keyset Fig 2－15 1. Alarm relay 2. Key set 3. Electronic regulator 4. Compound relay 5.electric horn relay 6. Head light relay 7. Fuse block 1. Alarm relay: when the electric switch is on, the alarm relay is connected and output control signal.
  • Page 30 https://tractormanualz.com 3. Electronic regulator: it controls the electronic system to make the system works well, and the machine voltage. The electronic regulator output control signal to ensure the electric system works well. 4. Starting compound relay: it is to control the starting motor on the engine, when the starting switch is on ON position, starting compound relay supply power to motor to start the motor.

  • Page 31: Ac System

    https://tractormanualz.com AC SYSTEM wind speed switch refrigeration indicator AC switch control panel Fig 2-16 Fig 2-17 Ventilation elementary operation Fig 2—16, turn the AC switch anticlockwise to O position Fig 2—16, turn the wind speed switch clockwise accordingly to L, M, H position to get low, middle and high speed wind.
  • Page 32 https://tractormanualz.com Fig 2-16, turn the AC switch anticlockwise to O position, then turn the wind speed switch to O position to shut down the AC.

  • Page 33: Sound System

    https://tractormanualz.com Sound system ⑦ ⑧ ⑨ Fig 2－18 ① ② ③ ⑩ ④ ⑤ ⑥ 1. Controller and switch ① ON/OFF& volume ②pause, play ③ random ④digital LCD ⑤ function switch ⑥ sound mode ⑦ former ⑧next ⑨FM/AM ⑩USB...

  • Page 34: Seat Adjustment

    https://tractormanualz.com Seat adjustment Front and back adjustment Move the adjusting rod to adjust the proper position (left, right), adjustment range: 160mm. Seat adjustment Fig 2－19 Lift the adjusting rod on the left of the seat to get the ideal height.

  • Page 35: Front Window

    https://tractormanualz.com Front window Install and detach the front window 1. Disconnect the wiring of the front window washing motor (Fig 2-22). Fig 2-22 2. Loosen the both side locking pin of the window on the top the cab (Fig 2-23) 3.
  • Page 36 https://tractormanualz.com Action bar of open and close door Push the action bar as the indicated direction to open the lock. Fig 2-25 Interior lamp in the cab Press the switch ① , the lamps works. Fig 2-26...

  • Page 37: Grinding-In New Machine

    https://tractormanualz.com Grinding-in new machine New machine grinding-in is to running-in the each and every part well, to ensure the backhoe loader work reliably and prolong its lift span. During the period of grinding-in, please operate and maintain the machine according to the following instructions. 1.

  • Page 38: Starting And Stopping

    https://tractormanualz.com Starting and stopping Engine-checking before starting ▲ WARNING If there are combustibles such as paper and leaves on the high temperature parts, such as the air intake tube, muffler, it may cause fire, the leakage on the fuel and hydraulic tank may cause first too.
  • Page 39 https://tractormanualz.com 3 make sure the traveling action bar①, dozer blade action bar ② in neutral position (Fig 3—2)。 NOTE: do not touches any switch when start the engine. 4. Turn the switch to the “start” position to check if all lights works, turn all other lights except the followings.
  • Page 40 https://tractormanualz.com 4．The engine should be started in 5s after turn the switch to “start” position ▲WARNING If the engine do not started after 10s, turn the switch back to “off” position, start again after 5m. Fig 3－5 5．The key will go back to “start” position automatically after the engine is started and loosen the key.
  • Page 41 https://tractormanualz.com Instrument panel indicator light Indicator display Coolant temperature gauge Green area Green area Fuel gauge Charging indicator light Engine oil pressure indicator light Preheat finish indicator light Hydraulic greasy dirt warning indicator light Air filter warning indicator light 8．Purging system checking no color or blue-engine works well ·...
  • Page 42 https://tractormanualz.com Using Auxiliary boost battery to start the engine ▲WARNING 1. Wear safe glasses 2. Do not connect positive and negative pole directly 3. Do not connect the earth wire of the auxiliary boost battery to the engine battery directly, find a connecting position on the machine.
  • Page 43 https://tractormanualz.com IMPORTANT The electric system is 24V with the negative pole connecting to the ground, auxiliary starting use the same battery with 24V. When start the engine, if the battery is discharged, using the auxiliary or boost battery start the engine 1.
  • Page 44 https://tractormanualz.com 2．Put the safe pole①(Fig 3－13) “unlock” position Fig 3－13 3. Slowly move cylinder of the boom , bucket arm and bucket for 5 times to let the hydraulic oil cycle without load in the hydraulic system. 4. Check the interval of working devices Lift working devices then turn Fig 3－14 clockwise for 3 cycles then anticlockwise...
  • Page 45 https://tractormanualz.com 2 ． Running the engine in middle speed without load for 5 minutes 3．Put the safe pole ①(Fig 3—18) Fig 3－17 on “unlock” position to switch on the pilot oil Fig 3－18 4．Slowly operate the boom, arm and Bucket without load for 5 times to cycle The hydraulic oil in the hydraulic system For 5 minutes NOTE: do not let the cylinder to reach...
  • Page 46 https://tractormanualz.com Then slowly cycle 3times clockwise and anticlockwise. 8. Put the working device on ground to let one side of the track shoe off ground on a firm ground, the other side track shoe on ground, control the traveling motor forward and backward for two times, then check the other side track shoe in the same way.
  • Page 47 https://tractormanualz.com 6．Put the safe operating bar back to the “lock” position, check again after stop the machine. 3-24 Checking after engine stop 1． If the excavator oil or coolant liquid leak, check and repair. 2 ． Check the working devices and under part. 3．...
  • Page 48 https://tractormanualz.com Safety pole ▲WARNING Be sure to lock the safety pole after stop the machine and leave the cab, unless may cause series accidents if touch the operating bar. Draw back or put down the safety pole, be careful do not touch the operating poles 1．Draw back the safety pole ①(Fig 3—25), make the left operating device up to the lock position, when the safety pole (Fig 3—25) is...

  • Page 49: Walking

    https://tractormanualz.com Walking ▲WARNING 1. Be sure to know the excavator parking direction before operating the walking rod. If you see the traveling motor by seating in the cab, what you see is the rear part. If you draw back the traveling bar, the machine goes forward. 2.
  • Page 50 https://tractormanualz.com 3．Draw back the working device to let it off ground. Fig 3—28。 4 ． make sure the bucket ground completely. Fig 3－28 6． When walks on uneven ground, choose low speed(1.0—1.5km/h) reduce speed of the engine(Fig 3—29)。 7．Walking slowly on irregular, frozen or uneven ground.
  • Page 51 https://tractormanualz.com To let the excavator works on even ground as far as possible (Fig3-30) 5 ． Try to walk on firm ground, avoiding suddenly move and turning in small angle Fig 3－29 ▲ WARNING If to support any part of the excavator by boom or arm, swing the bucket to make sure the under part of the bucket touch ground, and the angle between boom and arm should...
  • Page 52 https://tractormanualz.com Make sure sludge cleared. Fig3—32 and Fig 3—33. Fig 3-33 10．When going straight(Fig 3-34)， push forward or pull backward the operating rod/ pedal. The movement of the operating rod / pedal bigger, the faster of the machine will be. Fig 3－34 ▲WARNING There needs a trailer to transport the machine is the displacement distance is...
  • Page 53 https://tractormanualz.com 12．One track move forward, while the other track move backward, excavator will circle around the machine center.(Fig 3—36) Fig 3－36 13． Stop walking (Fig 3—37)－ put the operating rod in the center position, the machine will brake automatically and parked. Fig 3－37 Action bar (ISO) ▲warning...
  • Page 54 https://tractormanualz.com Here is the indicator drop of boom, bucket arm and bucket. Left operating rod (Fig 3—39 and Fig 3-40) ①bucket arm stretch out ②bucket arm draw back ③swing ④swing NOTE: swing brake is realized by the spring and release the hydraulic pressure, when the Fig 3-39 operating rod is in the middle position or the engine is stop, the excavator will swing-...

  • Page 55: Operating Instructions

    https://tractormanualz.com Operating instructions ▲ WARNING When operating the machine work, do not put your feet on the walking operating rod, the machine may move suddenly. 1. First to know the terrain and the edaphic condition before working, level the earth if it is necessary 2.
  • Page 56 https://tractormanualz.com 6．When there is resistance when the bucket works, do not swing the machine or walks(Fig 3—46)。 Fig 3－46 7．Do not increase the digging force by using the machine self weight(Fig 3－47)。 8 ． When works on soft earth or muddy ground, be careful the sink of the machine.
  • Page 57 https://tractormanualz.com 11．Keep the enough space between the machine and the wires in the air Fig 3—50。 Fig 3－50 12． When works in tunnel or in building, be careful do not crash the roof and keep good ventilation. Fig 3－51。 Fig3－51 13．Do not use the bucket as a hammer or a pile driver, it is dangerous, will cause serious problem to the machine.
  • Page 58 https://tractormanualz.com 15．When traveling on high speed, do not operate the rods quickly. a) Avoiding start suddenly b) When the machine needs to move to opposite direction, it should stop first. c) Avoiding stop suddenly, push back the operating rod to neutral position, Fig 3－54 do not release the rod suddenly.
  • Page 59 https://tractormanualz.com 1．If the riverbed is not even or the water is swaft, be careful, do not let the water cover the above side of the guide pulley, do not let water or sands to into the rotary unit or slewing bearing.
  • Page 60 https://tractormanualz.com Level ground IMPORTANT Do not overuse the bucket to lev ground; otherwise some parts wi break due to overload working. 1 ． Using the dozer plate to level ground. 2． Using the boom, bucket arm and bucket. A． When level the ground from front to back, raise the boom, at the same time slowly move the bucket arm, when the bucket arm is near the machine, stably lower the boom to let the bucket move horizontally.
  • Page 61 https://tractormanualz.com Be careful when raising the working device 1．Be careful when raising the front working device, do not let the bucket touch the dozer plate. Fig 3-62 Be careful do not let the dozer plate Touch anything 1. do not let the dozer plate touch anything, otherwise the dozer plate cylinder or other parts may be broken.
  • Page 62 https://tractormanualz.com Packing of excavator Fig 3－70 1．Park the excavator on a solid even ground, lower the bucket and dozer plate. Fig 3－71...
  • Page 63 https://tractormanualz.com 2．Put the engine manual accelerator operating rod (Fig 3—72) on the idle position, run the machine For 3-5 minutes Fig 3－72 3．Turn the key to “OFF” position, shut down the engine(Fig 3—73) 4．Pull out the key Fig 3－73 5．Put the safety rod ①(Fig 3—74) on the lock position. Fig 3－74...

  • Page 64: Ⅳ.lubrication

    https://tractormanualz.com Ⅳ LUBRICATION GENERAL SAFETY INFORMATION It is very important that all guidelines describing lubrication, checking the oil level, replacing the oil are strictly adhered to! This maintenance increases the life of the Excavator and improves its dependability. It is especially important to change the oil regularly and in the intervals noted on the maintenance schedule! Only use specified lubricants and oils! CAUTION: When checking or replacing the oil, observe the following:...
  • Page 65 https://tractormanualz.com covers Refrigeratin 1.2kg g agent for air R-134a conditioner Refrigerator 0.21 L SP20 conditioner compressor Industrial windshield washer fluid denatured alcohol Windshield 5.0 L washer system Use only fuel with a sulfur content of less than 0.5% and not less than the requirement of GB252-94 115L Fuel Diesel...

  • Page 66: Checking Coolant Level

    https://tractormanualz.com Note: (1) For further detail, please see the refilling materials chart. (2) The responsibility of breakdown caused by the low-grade oil should be born by the Buyer. LUBRICATION CHART: --------Changing the lubrication oil. ---------The components should be checked regularly after refilling. --------- Period to add oil and to lubricate.
  • Page 67 https://tractormanualz.com IMPORTANT! The correct concentration of corrosion inhibitors inside the coolant must be maintained permanently. The concentration has to be checked after each important coolant make up, and at regular intervals if smaller coolant quantities are refilled frequently. If necessary, anticorrosion additives must be added to the cooling system. To replace the water filter at regular intervals is sufficient to maintain the correct concentration of anticorrosive agent.

  • Page 68: Lubrication Of The Swing Ring Teeth

    https://tractormanualz.com change intervals. LUBRICATION OF THE SWING RING TEETH A housing around the pinion of the swing gear contains all the necessary lubrication reserves for the swing ring teeth lubrication. There is a cover on the right side of the swing platform. Remove the cover, connect a grease gun to pump the grease about 20 times through this hole and then turn the upper-carriage by 360º.

  • Page 69: To Drain And Add Oil To The Hydraulic Tank

    https://tractormanualz.com 1) In standard applications 2) In dust intensive applications To limit the hydraulic oil contamination when working under extreme dusty conditions. In order to avoid any premature wear and failure of hydraulic components in consequence of this contamination reduce the oil change intervals as described above and, in addition, observe following recommendations: 1.
  • Page 70 https://tractormanualz.com Unscrew the breather valve 2 one turn; remove the plug 3 to drain the oil. TO ADD OIL Unscrew the breather valve 2 one turn. Add the oil via the opening of the breather valve 2 until the oil level reaches the middle level on the sight gauge.

  • Page 71: Maintenance Principles Of The Excavator

    https://tractormanualz.com Ⅴ MAINTENANCE MAINTENANCE PRINCIPLES OF THE EXCAVATOR Make the excavator in a state of safety when maintenance. Stop it on the flat ground and switch off the engine without special instruction. Do not make the maintenance and repairing which you are not familiar with by yourself. Maintenance according to the stipulated time, and use the proper tools.

  • Page 72: Air Filter

    https://tractormanualz.com Air filter Air inlet system of the engine In order to protect the engine, check the inlet system regularly. Dust sensor When the monitor light lit up, it indicates that the filter is blocked, and clear it at once. Stop the engine when cleaning and washing.

  • Page 73: Undercarriage

    https://tractormanualz.com Warning: wear protective glasses to keep safe when using compressed air. Check air inlet soft tubes When clearing the air filter, check the inlet tubes. Replace them if there is breakage or leakage. Notice: the leakage of the filter will wear away the engine greatly and shorten the lifespan of the engine a lot.

  • Page 74: Checking Mounting Screws For Tightness

    https://tractormanualz.com Check the bolts of the travel motor and undercarriage, and the bolts of travel motor and sprocket. Check these bolts regularly to make sure of their tightness. Bolts :M16 (10.9) Force moment: 280-330 N·M. Washing tracks Check the undercarriage after working. Warning: do not switch on the excavator if big stones are stuffed tight between the tracks.

  • Page 75: The Electrical System

    https://tractormanualz.com When in the maintenance, repair of the hydraulic system, first release the pressure of the oil. First go out the engine and then keep the starting key in the state of “on”, trip the two operating hand shank. Loose pressure vent valves (3-5 turns as serial 1 in the picture. So loosen the pressure in the hydraulic tank.
  • Page 76 https://tractormanualz.com obstructing ring of the cylinder or other components. Protecting of cylinder rod. corrosion can destroy the excavator as the abrasion and rupture. Please abide when the excavator are not used exceeding 4 weeks or transported by ship: 1, place the excavator as seen in the picture. make the cylinder rod withdraw as possible. 2, lubricate all the joint points with the anticorrosive lubricant.

  • Page 77: The Swing And Travel Brake

    https://tractormanualz.com Radio, roof light Monitor, buzzer, light, rain wiper, air conditioner relay Electromagnetic valve, swing lock relay, travel relay Speaker, rain wiper, working light air conditioner Cigarette lighter Spare Spare spare Swing and travel brake The swing and travel brake are all wet brakes, which are sealed in the swing reducer and the travel reducer.
  • Page 78 https://tractormanualz.com Replace the wearing parts Besides the necessary maintenance, the driver and servicemen should also do some repairing work. For example, replace the bucket teeth, hydraulic hoses, seal rings and so on. Maintenance plan Please check and service according to the plan, and keep records. Thanks for your collaboration.
  • Page 79 https://tractormanualz.com density of the anti-corrosion additive in cooler Check adjust rotate speed control parts Check the fixing bolts of the diesel engine Check the air inlet and outlet system Replace the air filter core (at least once a year) Replace oil separator (every 2 years) Replace cooler (every 2 years) Check and adjust oil spray mouth (every 3000 hours)
  • Page 80 https://tractormanualz.com Check the fixing bolts Check the space of the gears Working hours Travel motor Check the leakage and oil level Check the functions and travel brake Check the fixing bolts Replace the gear lubricant (1 within 500 hours) Working hours Tracks Check the tensity of the tracks Clear the tracks and sprockets (after...

  • Page 81: Engine Trouble

    https://tractormanualz.com Ⅵ BREAKDOWN ANYLASIS Engine Breakdown Breakdown Repair Note When increasing the rotate Add oil to to the standard level speed of the engine, oil Replace the oil filter core pressure monitor light is Check the leakage of tubes or joints Replace the monitor There is steam out of the Add cooler and check leakage...

  • Page 82: Others

    https://tractormanualz.com running up or the light motor twinkles when the engine is running. The charge light is on Check the engine when the engine is running Check the wires The sound of the electrical Check the electrical motor motor is abnormal Power switch is on but the Check and repair the relevant wires start motor doesn’t work...
