DesignerPlus V6 - Carving Stamps
Open a New File
Select File/New or click on the New File icon.
Right click on Show Hoop.
Make sure Display Hoops is checked and select artista 400 x
150 Mega—Auto Split Machines.
Draw the rectangles
Select C42 from the Color Bar.
Select the Rectangle tool and draw a rectangle by clicking in the
upper left hand corner and dragging to the lower right hand cor-
Select the rectangle and open Object Properties. Click on the
General tab. Make sure Proportional Scaling is turned off.
Change the width of the rectangle to 70 mm and the height to
85 mm. Click OK.
Quick Clone (right click and drag on the object) to make a copy
of the rectangle. Move the copy in a below the first rectangle.
Clone the second rectangle; position below the second object.
Select File/Save As.
Navigate to the folder in which the file will be stores. Name the
file Carving Stamps. Click Save.
Using an Object for a Stamp
Select File/Insert Design.
Navigate to My Computer/C: My Designs Embroidery Software
6. Select the Animal folder. Open the folder.
Select FB 253-48. Open the file.
Decrease the size of the dragonfly by clicking and dragging on
one of the corner black sizing handles. Move it away from the
Note: Decrease th object so that it will fit within the rectangle, or
use the stamp so that only part of the object stamps the back-
Open the Carving Stamp dialog box.
Click on the Use Object Tab.
Click on the Start Selecting button and use one of the selection
tools to select the dragonfly. The dragonfly will appear in the
Use Object window. Press Esc.
Select one of the rectangles. Click on Use Stamp—the outline
of the stamp is visible.
of America, Inc
Carving stamp defines a pat-
tern of needle penetrations in
a fill. There are three different
ways to stamp— use a de-
sign, use a built-in stamp, or
create a custom stamp.
Any of the selection tools be
used to select the object that
will be used as a stamp.
Select part of the object by
drawing the bounding box
around part of the design or
by using Polygon Select
(remember to first ungroup).
Add stamps to selected back-
ground objects or choose to
not pre-select an object and
add the stamp to other ob-
Follow the prompts on the
lower left corner of the screen
for information on setting the
