Edision triton T2 Quick Start Manual

Congratulations on purchasing an EDISION triton T2
Please note that this information is valid at the time of publication.
Current information and detailed user manuals can be found on the Internet at: www.edision.gr
1

Unpacking

120mm
Receiver triton T2
Notes: The front is factory fitted with a protective foil which can be removed easily
and with caution.
The scope of delivery may also include parts not listed here
Front Panel
1 Infrared sensor for the reception of remote
control commands.
2 Display LED, displays current information
3
/ USB: port for USB storage devices.
Back Panel
4 ANT IN: Input for connecting the signal from the antenna
5 HDMI: Connection to an HDTV quality TV
6 SCART: For connecting to a TV set,
using SCART cable [not for HD TV]
7 Connection for an adapter (DC 5V / 1,0A)
2

Connecting and switching on

Note: For trouble-free signal reception your antenna
and cable installation should be calibrated
and inspected by a qualified professional with a digital
TV-level-measuring instrument.
• Connect the receiver's HDMI-output to the HDMI-input
of your television set (TV), for HDTV quality.
• Then connect the coaxial cable from the terrestrial
antenna to the ANT IN input of the receiver.
• Insert the batteries into the remote.
Further information you will find at the back
of this instruction manual.
• Connect the receiver to the mains power supply network,
by means of it's power supply unit included in the package.
• The receiver starts with the BOOT-process and will be ready
for you to enjoy in a few minutes.
triton T2
FullHD DVB-T2 Receiver
Remote control with 2 AAA batteries
4
After the first start,
choose your language
ANT IN: coaxial-wire
input from terrestrial
antenna.
ANT IN HDMI
HDMI
kabel
HDMI:
Output receiver
HDMI cable
Documentation
1
6
5
DC 5V/1,0 A
SCART
TV set connection panel
Power socket
Service note
Please contact
your EDISION
specialist dealer
for any further
support
and service.
2
3
7
HDMI in
2
1
m
HD i
kabel
Use an HDMI input!
