Section 3 - MAINTENANCE
3.4 ANNUALLY (END OF EACH SEASON)
Perform all maintenance as described in the maintenance
schedule.

3.4.1. Engine

Refer to engine
instructions.

3.4.2. Spark Plug

Refer to engine
instructions.

3.5 STORAGE PROCEDURE

Refer to the Engine Owner's Manual for directions
regarding engine storage preparations. Prepare the snow
thrower for "end of season" storage as follows:
1. Drain fuel from fuel tank and let engine run until
all fuel is out of the carburetor.
2. Disconnect and remove the spark plug wire
away from spark
preparations are made!
3. Tape all openings closed to prevent spraying
water into exhaust or air intakes during washing.
4. Tilt snow thrower up on its wheels and
thoroughly clean the underside of the auger.
5. Lubricate all exposed metal with a light coating
of oil to prevent corrosion.
6. Store the machine in a shed or other dry area,
protected from weather.

3.6 MAINTENANCE and SERVICE PARTS

Auger Drive Belt (Tecumseh Engines)
Wheel Drive Belt (5.5 HP Engines)
Wheel Drive Belt (7 HP Engines)
Scraper Blade (22" Width Auger)
Scraper Blade (24" Width Auger)
Rubber Drive Tire
Shear Bolts - 1/4-20 x 1-1/2"
Hex Nuts - 1/4-20
Parts Manual for Intermediate Frame Snow Thrower - Series 3 & 4
Domestic Models: I4223, I5223, I55223, I6223, I7243, I55224, I7244
European Models: EI5223, EI55223, EI55224, EI7243, EI7244
owner's manual for
owner's manual for
plug before any other
MAINTENANCE and SERVICE PARTS
service
service
11
1-5152
4-5214
4-5214
3-3298
3-6163
2-3364
1-5257
7-6978
#06068
