Summary of Contents for Synergy Science Echo H2 MACHINE
- Page 1 Echo H Machine Owner ’s Operation Manual The Premier H Enriched Water Purification System Warning: Incorrect installation and/or operation could void your valuable warranty. Please protect your investment! READ THIS MANUAL CAREFULLY...
-
Page 2: Safety Precautions
Safety precautions If the Echo H Machine is immersed in Always set the voltage of the Echo H water by accident, remove the plug Machine to match the voltage of from the socket and remove the Machine the power supply. from water. - Page 3 Connect the Echo H Machine to the cold Do not splash water on the water source line. Echo H Machine or wash the Machine with water. Connection to the hot water source line may damage the filter It may cause short, electric and /or machine.
-
Page 4: Names And Functions
Names And Functions Front Hydrogen Water Spout Hydrogen Water Selector On/ Off Knob Back Key-hole Slots For Wall Mounting Input Voltage Selector Filter Cover Speaker Master Power Switch Fuse Holder Faucet cable Harness port Source Water Connection... - Page 5 Indicators and controls Filter replace indicator Low water pressure indicator Filter life Indicator Water Flow Indicator "H " button and Indicator Setting indicator Filtered indicator Setting button "Filtered" button Accessories Diverter Qwner’s Source Water Spout Elbow Teflon tape Quick Connect Valve Manual Water Hose...
-
Page 6: How To Use
How to use Initial operation Turn the master power switch on the back of the Echo H Machine to the ON position. When the ON/OFF knob is turned ON, a voice announcement will be heard announcing the water type that is currently flowing, Filter life indicator will track the amount of water flowing and show the remaining filter life left. - Page 7 How to Choose Hydrogen Water Turn on the machine by rotating ON/OFF knob to ON position: the large round Hydrogen button should be illuminated. If not illuminated, press the Hydrogen button and this will initiate hydrogen water production You will hear hydrogen water is dispensed with voice message. (You can use the hydrogen water by pressing the hydrogen water button(H hydrogen water...
-
Page 8: Settings Button
How to use How to turn off water flow Rotate the ON/OFF knob to the OFF position. The LED Display will no longer be illuminated and the machine will go into standby mode. Settings Button The 'Setting function' can be operated only when machine is powered on. It has language and volume settings. - Page 9 2) How to set the volume ※ The default setting is VoL3. ① Touch and hold the Mode button for a few seconds until the ring sound is heard. The screen will appear as follows. <Filter life setting> <Language setting> ②...
- Page 10 Change of genuine filter How to replace the filter When the filter reaches the end of Turn off the power switch on the back its life, the filter life indicator shows of the machine and shut off the water. 0000, the filter replace icon will then light up, and the voice message will say "Replace filter"...
- Page 11 Turn the master power switch to After pressing the filtered button in the ON position, Located on back the standby mode, check for any of machine. leakage by flowing water for 2 ~ 3 minutes, if there are no leaks you can now close the filter cover.
- Page 12 Composition of Filter Composition of the filter <High Performance Filter> (Coconut Husk) (NSF / ANSI 42) (Coconut Husk) (NSF / ANSI 42) Recommended period for changing filter Effective period of filter use may differ greatly depending on season, usage, and environment.
-
Page 13: How To Install
How to Install Above Counter Installation Procedure Warning! Diverter valve Keep order of Dust pre-Filter and Constant flow valve Source water when machine is installed Dust Pre Filter inlet Below Counter Installation Procedure inlet Dust Pre Filter Source water Cold water valve... - Page 14 How to Install Above Counter Installation Procedure Caution Install after stop water supply. [Figure 1] [Figure 2] Diverter valve 1/4” Hose Diverter valve Please assemble the faucet top Connect 1/4” Hose hose to the (water top) and the diverter valve as adaptor in "Figure 2"...
- Page 15 Caution Below Counter Installation Procedure Install after stop water supply. [Figure 1] [Figure 2] 1/4” Hose “T”adapter Cold water valve Loosen the nut of the cold water Connect 1/4” hose to the “T” adapter valve. in "Figure 2" [Figure 4] [Figure 3] inlet Push in and fasten the 1/4”...
-
Page 16: Installation Precautions
Installation Precautions / Wall hanger installation Installation Precautions Install water pump when the water pressure is low. Caution When using the water with high hardness, you may want to - use a water softener. Wall hanger installation Install after closing water supply. Caution Soak the installation Drive the nail in position. -
Page 17: Troubleshooting Guide
Trouble Shooting Guide The Echo H Machine may not operate by improper use or trivial causes, rather than by break-down. Before contacting the Customer Support for repair, please refer to the following: Symptom Check point Troubleshooting There is no display in 1. -
Page 18: Specification
Specification Echo H Machine Specification Device Type Hydrogen water Generator Model Echo H Machine INPUT Voltage AC 120V or 240V, 50Hz~60Hz Power Supply SMPS Power Consumption Max 250W Overall Dimension 10.5 x 15 x 5.3in (270 x 383 x135 mm)(WxHxD) Applicable Water Inflow Pressure 10-71psi (0.7~5kgf/㎠) Applicable Water Temperature... - Page 19 memo...
- Page 20 The Premier H Enriched Water Purification System www.synergyscience.com www.synergyscience.com 800-337-7017 800-337-7017 +1-407-287-5392 +1-407-287-5392 Toll Free Toll Free Local Local 2018.06...
