Summary of Contents for Silver Spring Bridges NIC 42
- Page 1 Bridges NIC 42 User Guide Silver Spring Networks 555 Broadway Street Redwood City, CA 94063 www.silverspringnet.com Bridges NIC 42 User Guide 18 March 2013 Silver Spring Networks 1...
- Page 2 Bridges NIC 42 User Guide Confidential Information of Silver Spring Networks, Inc., provided under nondisclosure obligations. Copyright © 2013 Silver Spring Networks, Inc. All rights reserved. ® ® The Silver Spring Networks logo, UtilityIQ , and UtilOS are registered trademarks of Silver Spring Networks, Inc.
-
Page 3: Table Of Contents
Bridges NIC 42 User Guide Contents Contents 1. About Bridges ............4 Related Documents . -
Page 4: About Bridges
Bridges NIC 42 User Guide 1 About Bridges About Bridges A Silver Spring bridge provides high‐performance, reliable, and secure DNP3 transport between remote terminal units (RTUs) and data centers. The Silver Spring Networks Bridge family includes Bridge 4.0, eBridges, and sBridges. Bridges are manufactured to perform one of two roles: Master or Remote. A Master Bridge provides the connection or take‐out point for the Remote Bridges to the SCADA system. The Remote Bridges connect to the RTUs to provide connectivity back to the Master. For details and ordering information about these and other Silver Spring devices, refer to the Silver Spring Networks Infrastructure Hardware Guide. Related Documents You can find all Silver Spring Networks product documentation at https://springboard.silverspringnet.com in the Documentation & Release Notes section. You may also refer to the following documentation: • Bridge Configurator User Guide v2.2 or higher for information on configuring the Bridge with the Bridge Configurator and a Field Service Unit (FSU) • Silver Spring Networks Infrastructure Hardware Guide for site planning and ordering information • Distribution Automation Design and Implementation Guide for general information on Bridge implementation Verifying the Packing List Make sure your Bridge assembly includes: • Bridge components in a corrugated carton, including: •... -
Page 5: Bridge 4.0
Bridges NIC 42 User Guide 1 About Bridges Bridge 4.0 The following figures show the interfaces for Bridge 4.0. Figure 1. Bridge 4.0 front and back panels Front Back SMA female RF connector Grounding lug Serial ports Ethernet GPIO ports Power Specifications for Bridge 4.0 Bridge 4.0 hardware specifications are listed in Table 1. Table 1. -
Page 6: Assembling Bridge 4.0
3. Connect an antenna to the SMA female connector. a. If you are connecting the Bridge to the RTU’s antenna, make that connection. CAUTION: Do not operate Bridges (or any Silver Spring RF devices such as Relays or APs), without an antenna connected. Circuit damage can occur if the unit is powered and the antenna connector is not properly terminated. -
Page 7: European Union Compliance
Bridges NIC 42 User Guide 1 About Bridges Note: For Distribution Automation deployments, a high gain antenna is recommended for use with all Bridges. We recommend using the 6dBi omnidirectional antenna (catalog number 201-000002). 4. Connect the grounding wire to the grounding lug on the back of the Bridge and connect the wire to ground. 5. Connect the power to a suitable AC or DC outlet. 6. DC polarity on the Bridges is important. To ensure the proper polarity, the DC power cord plugs into the Bridge only one way. The red cable must then be connected to the... -
Page 8: Declaration Of Conformity For Rf Exposure
Radio: ETSI EN 300 220‐1 v2.3.1 (2010‐02), ETSI EN 300 220‐2 v2.3.1 (2009‐12), The conformity assessment procedure referred to in Article 10 and detailed in Annex IV of Directive 1999/5/EC has been followed. Note: This equipment is intended to be used in Luxembourg, United Kingdom, and Portugal in conjunction with licenses. For more details, contact Silver Spring Networks Compliance. The product carries the CE Mark: A copy of the Declaration of Conformity may be obtained with formal request to: Silver Spring Networks, c/o Hardware Engineering 555 Broadway Street Redwood City, CA 94063, USA Declaration of Conformity for RF Exposure This system has been evaluated for RF exposure for Humans in reference to EN 62311(2008) ... -
Page 9: Fcc And Government Guidelines
Bridges NIC 42 User Guide 2 FCC and Government Guidelines FCC and Government Guidelines Silver Spring Networks NIC FCC ID: OWS-NIC42 IC: 5975A-NIC42 M/N: NIC42 The NIC is REQUIRED to be professionally installed by a properly trained technician. Improper installation could void the userʹs authority to operate the equipment. The device complies with Part 15 of the FCC rules, and with Industry Canada license‐exempt RSS standard(s). Operation is subject to the following two conditions: 1. The device may not cause harmful interference. 2. The device must accept any interference received, including interference that may cause undesired operation. The antenna of this transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. The device should be installed so that people will not come within 20 cm (8 in.) of the antenna. This equipment has been tested and found to comply with Part 15 of the FCC Rules. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and ... -
Page 10: Fcc Guidelines For Devices Containing A Transmitter Module
Bridges NIC 42 User Guide 2 FCC and Government Guidelines CAUTION: Changes or modifications not expressly approved by Silver Spring Networks could void the user's authority to operate the equipment. FCC Guidelines for Devices Containing a Transmitter Module The following is an extract from FCC PART 15 UNLICENSED MODULAR TRANSMITTER APPROVAL, DA 00‐1407, Released: June 26, 2000, Section 6 describing labeling requirements ... -
Page 11: For Transmitters Not Requiring Licenses
Bridges NIC 42 User Guide 2 FCC and Government Guidelines admissible maximal et lʹimpédance requise pour chaque type dʹantenne. Les types dʹantenne non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour lʹexploitation de lʹémetteur. • Antennenid omirectionnelle, 6.0dBi sur 900 MHz et 2,4 GHz sur 3.6dBi Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Conformément à la réglementation dʹIndustrie Canada, le présent émetteur radio peut fonctionner avec une antenne dʹun type et dʹun gain maximal (ou inférieur) approuvé pour lʹémetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à lʹintention des autres utilisateurs, il faut choisir le type dʹantenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas lʹintensité nécessaire à lʹétablissement dʹune communication satisfaisante. For Transmitters Not Requiring Licenses This device complies with Industry Canada licence‐exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR dʹIndustrie Canada applicables aux appareils radio exempts de licence. Lʹexploitation est autorisée aux deux conditions suivantes: (1) lʹappareil ne doit pas produire de brouillage, et (2) lʹutilisateur de lʹappareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible dʹen compromettre le fonctionnement. -
Page 12: General Electrical Safety
Bridges NIC 42 User Guide 2 FCC and Government Guidelines • The information contained in this document is intended to aid qualified personnel, and is not a replacement for the proper training required to make a person qualified. • Silver Spring Networks assumes no liability for the customerʹs failure to follow these safety guidelines. General Electrical Safety • Perform the procedures in this manual in accordance with applicable workplace standards established by the following agencies: — Occupational Safety and Health Act (OSHA). — The National Electrical Code published by the National Fire Protection Association (NFPA‐70). — National Electrical Manufacturers Association (NEMA). — Electronics Industries Association (EIA). — Insulated Power Cable Engineers Association (IPCEA). • American National Standards Institute (ANSI). Whenever possible, de‐energize all circuits or equipment before working on them. • Maintain a minimum clearance of 10 feet (3 meters) between line potential and all unqualified persons at all times. •... -
Page 13: Personal Protective Equipment (Ppe)
Bridges NIC 42 User Guide 2 FCC and Government Guidelines • Handle material carefully. Lift and carry properly. Personal Protective Equipment (PPE) • Always wear Personal Protective Equipment (PPE), in accordance with OSHA and ANSI standards. • Wear eye protection and electrically insulated gloves. Test gloves in accordance with ANSI standards before use. Do not use gloves that do not pass appropriate test procedures. • Wear protective clothing such as long sleeve shirts and long pants made of flame resistant materials. • Remove all jewelry. • Do not pass any objects to or from other persons not protected by insulating platforms or tested, electrically insulated gloves. Fall Protection When performing work at any elevation: • Always use a fall protection system, in accordance with OSHA standards, whenever performing work at any elevation. • Never use conductors, guy wires, pins, or cross‐arm braces, etc. to support your weight. •... -
Page 14: Shock Accident First Aid
Bridges NIC 42 User Guide 2 FCC and Government Guidelines Shock Accident First Aid • Do not touch the victim with your bare hands; use something non‐conductive to separate the victim from the energy source. • Call for emergency medical help immediately. Keep the victim lying down, warm, and comfortable until help arrives. Avoid moving the victim in case of injury to neck or back. Position an unconscious victim on a side to let fluids drain. • Check the victimʹs breathing and heartbeat. If properly trained, apply mouth‐to‐mouth resuscitation and/or CPR if necessary. • Remove constricting items from the victim, such as shoes, belts, jewelry, and tight collars; they could cut off circulation if the victim experiences swelling. • Apply water or saline for a few minutes to any burns until the skin returns to normal temperature. Do not attempt to remove clothing that is stuck to a burn. If possible, elevate burned areas to reduce swelling. • Make sure the victim receives professional medical attention, even if they feel fine. Electric shock can cause heart failure hours after the shock is received. Bridges NIC 42 User Guide 18 March 2013...
