Summary of Contents for Shenzhen Sinjoe AWC-608
- Page 1 Shenzhen Sinjoe Laser Technology Co.,Ltd Better life since you join us!
- Page 2 Shenzhen Sinjoe Laser Technology Co.,Ltd User Manual Version No: SJ 5.90 Product Name: Sinjoe Laser Controller AWC-608 Supplier: Shenzhen Sinjoe Laser Technology Co.,Ltd Copyright (c) Shenzhen Sinjoe Laser Technology Co., Limited All Rights Reserved...
-
Page 3: Table Of Contents
Shenzhen Sinjoe Laser Technology Co.,Ltd Contents List 1. Preview…………………………………………………………………………………5 2. Product list………………………………………………………………..6-7 3. Connection and interface………………………………………………….8 3.1 Main Board Overview……………………………………………………………8 3.2 POW…………………………………………………………………………9 3.3 Output Interface1 and 2………………………………………………………..10 3.4 Laser 1 and laser 2…………………………………………………11 3.5 X/Y/Z/U Axis…………………………………………………12 3.6 X/Y Limit Switch……………………………………………………12 3.7 Z/U Limit Switch………………………………………………..13... - Page 4 Shenzhen Sinjoe Laser Technology Co.,Ltd 4.6 Files system..................... 36 5. How to Update the controller?............37 6. How to feedback your opinions to us?............38 7. Ending…………………………………………….38...
-
Page 5: Preview
Shenzhen Sinjoe Laser Technology Co.,Ltd 1. Preview Thank you for purchasing Sinjoe Laser products! Shenzhen Sinjoe Laser Technology Co., Limited, as a professional industrial laser supplier, started our business in Shenzhen in year 2009. With the new season of 2013 coming, overseas market has become our new target. -
Page 6: Product List
Shenzhen Sinjoe Laser Technology Co.,Ltd 2. Product list………………………………………………………………………….. - Page 7 Shenzhen Sinjoe Laser Technology Co.,Ltd...
-
Page 8: Connection And Interface
Shenzhen Sinjoe Laser Technology Co.,Ltd Connection and interface…………………………………………………. 3.1 Main Board Overview... -
Page 9: Pow
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.2 POW Definition +24V, Power supply Anode GND,... -
Page 10: Output Interface1 And 2
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.3 Output Interface1 and 2 Definition DC24V, Power(Output) OUT1,Air blowing signal (The whole process of blowing) When machine idle ， Main board OUT1 in high level； When machine work ， Main board OUT1 in low level . -
Page 11: Laser 1 And Laser 2
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.4 Laser 1 and Laser 2 Laser 2 Definition DC5V, Power(OUT) PROTECT, Water protection input signal PWM, Laser power Frequency TTL, Laser switch signal GND, Power ground(OUT) Laser 1:the same. The connection between Laser interface and the normal laser power supply is as follow:... -
Page 12: X/Y/Z/U Axis
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.5 X/Y/Z/U Axis Definition DC5V, Power(OUT) PUL, Pulse signal DIR, Direction signals The connection of this interface and drivers is as follow: 3.6 X/Y Limit Switch Interface Definition DC24V, Power(OUT) ELY+; the upper limit of Y-axis... -
Page 13: Z/U Limit Switch
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.7 Z/U limit Switch Interface Definition DC24V, Power(OUT) ELU+; the upper limit of U-axis the axis movement to the sensor signal input signal at the maximum coordinate limit ELZ+ the upper limit of Z-axis the axis movement to the sensor signal input signal at the maximum coordinate limit ELU-;... -
Page 14: Input Interface
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.8 Input Interface 9.IN (IN1,IN2) Definition DC24V, Power(OUT) IN1, Cap protection signal (input), active low IN2, The footswitch signal (input), active low GND Power ground(OUT) 10.IN(IN 3,IN4) Definition DC24V, Power(OUT) IN3, Input signal (reserved) Input signal (reserved) -
Page 15: Internet, U-Disk, Lcd Panel, Power Supplier Interface
Shenzhen Sinjoe Laser Technology Co.,Ltd 3.9 Internet, U-disk, LCD Panel, Power supplier Interface………….. - Page 16 Shenzhen Sinjoe Laser Technology Co.,Ltd...
- Page 17 Shenzhen Sinjoe Laser Technology Co.,Ltd...
-
Page 18: Introduction Of Awc-608
Shenzhen Sinjoe Laser Technology Co.,Ltd 4. Introduction of AWC-608... -
Page 19: Function Introduction To Each Key
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.1 Function introduction to each key “Reset” Key: Press this key, machine can enter into the state of reset under circumstances, and then go back to “Original point” “Laser” Key: Be applied to test Optical path. Press it to flash. -
Page 20: Interface Of Starting Computer
Shenzhen Sinjoe Laser Technology Co.,Ltd axis. 4.2 Interface of starting computer Interface of starting computer shown as below: After initialization, it enters into main interface shown as below: 【file】 ：show serial number of files. 【Num】 ：show times of current diagram after adding one by one. -
Page 21: Function Introduction To Main Interface
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.3 Function introduction to main interface View 4-3 Under the main interface, press , cursor will appear on one item selected show as below: When there is no cursor, system is in state of “Key moving“; when there is cursor, system is in state of “parameter alteration”. -
Page 22: Check The Properties Of Current File
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.3.1.1 Check the properties of current file Press , cursor appears on main interface, press move cursor onto item【file】: Press to enter into properties sub interface of file: View 4-3-1-1 4.3.1.2 Alter the properties of current file Take altering the 【... -
Page 23: Clear Total Working Times Of File (Refer To View 4-3)
Shenzhen Sinjoe Laser Technology Co.,Ltd the number After alteration, press to finish the alteration of 【Repeat count】. 4.3.2 Clear total working times of file (refer to view 4-3) Press cursor appears main interface, then press to move cursor onto item【Num】:... -
Page 24: Switch Between "Power 1"&"Power 2" (Refer To View 4-3)
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.3.3 Switch between “Power 1”&“Power 2” (refer to view 4-3) Press , cursor appears on main interface, press move cursor onto item【power】: Press to enter into sub interface: Press to move cursor onto item【Laser 2】，then press... -
Page 25: Change Speed, Maximum Power, Minimum Power (Refer To View 4-3)
Shenzhen Sinjoe Laser Technology Co.,Ltd Similar operation can also switch “power 2” to “power 1”。 4.3.4 Change speed, Maximum power, Minimum power (refer to view 4-3) Press cursor appears main interface, press to move cursor onto item【speed】: Press to enter into sub interface:... -
Page 26: Main Menu Function
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.4 Main menu function Press to enter into main menu interface. View 4-4 Under the main menu interface, press to move cursor onto one item. 4.4.1 UDisk file (Refer to View 4-4) This UDisk file system only support FAT32. -
Page 27: Work File (Refer To View 4-5)
Shenzhen Sinjoe Laser Technology Co.,Ltd into 【Disk file】interface (User must insert U-disk into U-disk interface in control board of AWC608) View 4-5 4.4.1.1 Work file (refer to view 4-5) Under the 【UDisk file】, press to move cursor onto item【work’ files】, press to enter into 【work’... -
Page 28: System Upgrade File (Refer To Graphic 4-5)
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.4.1.3 System upgrade file (refer to graphic 4-5) Under【UDisk file】interface, press to move cursor onto item【Upgrade’ files】.After pressing to enter into【Upgrade’ files】,move cursor to select one upgrade file, and then press , system will upgrade according to upgrade file. -
Page 29: Origin Manage
Shenzhen Sinjoe Laser Technology Co.,Ltd interface, and then press to modify the value. Then press to finish the modification of this parameter. 4.4.3 Origin manage (Refer to view 4-4) Under the main menu interface, press to move cursor onto item 【Origin manage】, then press to enter into【Origin manage】interface:... -
Page 30: Origin Mode
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.4.4 Origin Mode (Refer to view 4-4) Under the main menu interface, press to move cursor onto item【Origin mode】, then press to enter into【Origin mode】interface: 【Key origin】 ：Take the original point selected by of LCD panel as beginning. -
Page 31: Memory Management
Shenzhen Sinjoe Laser Technology Co.,Ltd 【LCD Panel params】：Using the parameter set in the main interface of LCD panel to deal with graphic and data. (Including: speed, maximum power and minimum power of laser 1, maximum power and minimum power of laser 2)(Regarding the instruction to the main interface of LCD Panel, please refer to 7.3 function instruction of main interface. -
Page 32: Inching Control
Shenzhen Sinjoe Laser Technology Co.,Ltd 【Z axis reset】：Z-axis starts to move to reset 【Z Origin:2.0mm】：the mobile distance of Z-axis in opposition direction after reaching limit. 【U axis reset】; U-axis starts to move to reset. U-axis can’t reset when U-axis is feeding axis (Regarding the function and configuration of U-axis, please refer to 3.3.2.4 Function and configuration) -
Page 33: Cut Box
Shenzhen Sinjoe Laser Technology Co.,Ltd When select item【 Z/U inching 】, press to move laser head with the length of【 inching distance】 in the U direction, press to move laser head with the length of 【inching distance】 in the Z direction. -
Page 34: Network Config
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.4.10 Network Config (refer to view 4-4) Under the main menu interface, press to move cursor onto item【 Network config】 , and then press to enter into 【 network config】 interface: Press to move cursor onto one item, then press... -
Page 35: System Version
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.4.12 System Version (refer to view 4-4) Under the main menu interface, press to move cursor onto item 【system version】, press to enter into 【system version】interface: Version of 【 Main Board】 can be upgraded by【 UDisk file】 to the newest one. （ Refer to 4.4.1.3 System upgrade file）... -
Page 36: Files System
Shenzhen Sinjoe Laser Technology Co.,Ltd 4.6 Files system Under the main interface, press to enter into 【file】interface: In【file】 interface, it will show all working files saved in the memory of control board. Press to move cursor on one item and then press... -
Page 37: How To Update The Controller
Shenzhen Sinjoe Laser Technology Co.,Ltd 5. How to Update the controller?............1) Copy the update files you download and don’t forget the files name. 2) Input the update files into Your U-disk ATTENTION: Considered the different features of U-disk in the global market, we... -
Page 38: How To Feedback Your Opinions To Us
Shenzhen Sinjoe Laser Technology Co.,Ltd 6. How to feedback your opinions to us?............Our feedback page welcome you send any question and improving suggestions. If our product good, please let your friend know about it; if our product not good, please let us know.
