Summary of Contents for Eurotherm 394

  • Page 1 E U ROT H E R M User Guide...
  • Page 2 Major Functional items Controller A Controller B Operator interface (option) (option) Door catch Print head Configuration transfer port Chart retainer (three places) Platen release Chart clamp Time Memory reference card eject Consumables Print cartridge Charts 24-hours/rev GDTW0394Uxxx LA250280 7-days/rev GDSV0394Uxxx xxx = n of divisions from centre to edge = 050, 060, 070, 080, 100, 150 Other items Attenuator (100:1)...
  • Page 3 ε E U R O T H E R M Declaration of Conformity Manufacturer's name: Eurotherm Limited Manufacturer's address Faraday Close, Worthing, West Sussex, BN13 3PL, United Kingdom. Product type: Industrial chart recorder Model: (Status level B2 or higher) Safety specification:...

  • Page 5: Table Of Contents

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE CIRCULAR CHART RECORDER USER GUIDE LIST OF CONTENTS Section Page STATIC ELECTRICITY ..............9 TERMINOLOGY ............... 9 SAFETY NOTES ................ 10 SYMBOLS USED ON THE RECORDER LABELLING ......10 1 INSTALLATION ............11 1.1 UNPACKING THE RECORDER ..........11 1.2 INSTALLATION ..............

  • Page 6: Section Page

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE List of contents (Cont.) Section Page 3 OPERATOR MENUS ............. 27 3.1 INTRODUCTION ..............27 3.2 TOP LEVEL OPERATOR MENUS ........... 27 3.3 CHART SUBMENU ............. 27 3.3.1 Chart on/off ................. 28 CHART ALIGN ..............28 3.3.2 Logs ..................
  • Page 7 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE List of contents (Cont.) Section Page 4.5 CHANNEL CONFIGURATION ..........43 4.5.1 Range configuration ............... 43 INPUT TYPE ..............43 INPUT RANGE ..............43 SHUNT VALUE ..............43 INPUT UNITS ..............43 LINEARISATION TYPE ............44 CJC TYPE ................
  • Page 8 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE List of contents (Cont.) Section Page 5 RELAY OUTPUT OPTION ..........63 5.1 INTRODUCTION ..............63 5.1.1 Configuration ................ 63 JOBS ................63 5.1.2 Relay specification ..............63 5.2 RELAY WIRING ..............64 5.2.1 Six change-over (also called Form C or SPDT) relays board ..64 6 ANALOG OUTPUT (RETRANSMISSION) OPTION ...
  • Page 9 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE List of contents (Cont.) Section Page 7.2.2 LEVEL 2 EQUATIONS (CONT.) HIGH SELECT ..............78 LOW SELECT ..............78 STOPWATCH ..............78 TIME STAMP ..............79 OXYGEN (O2) CORRECTION ........... 79 PERCENTILE ..............80 7.3 CONFIGURATION ............. 81 MATHS PACK UNIQUE PARAMETERS ........
  • Page 10 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE List of contents (Cont.) Section Page 10 CUSTOM LINEARISATION OPTION ......95 10.1 INTRODUCTION .............. 95 10.2 CONFIGURATION PAGES ..........95 11 SERIAL COMMUNICATIONS OPTION ......96 11.1 INTRODUCTION .............. 96 11.1.1 Safety isolation specification ..........96 11.2 WIRING................
  • Page 11 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE List of contents (Cont.) Section Page 13 TRANSMITTER POWER SUPPLY OPTION ..... 116 13.1 INTRODUCTION .............. 116 13.1.1 Fuses ................. 116 13.1.2 Safety isolation specification ..........116 13.2 SIGNAL WIRING ............. 117 14 REFERENCE ............... 119 14.1 COSHH ................
  • Page 12 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 8 Issue 7 Nov 06...

  • Page 13: Static Electricity

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE STATIC ELECTRICITY TERMINOLOGY HA250385 Issue 7 Nov 06 Page 9...

  • Page 14: Safety Notes

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE SAFETY NOTES SYMBOLS USED ON THE RECORDER LABELLING Refer to the Manual for instructions Protective Earth This recorder for ac supply only This recorder for dc supply only. This recorder for either ac or dc supply Risk of electric shock HA250385 Page 10...

  • Page 15: Installation

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 1 INSTALLATION 1.1 UNPACKING THE RECORDER 1.2 INSTALLATION 1.2.1 Mechanical installation PANEL MOUNTING PIPE MOUNTING 1.2.2 Electrical installation CONFIGURATION TRANSFER WIRING Recorder 1 Recorder 2 Inner: Terminal transmit Receive Receive Inner Inner Outer: 0 Volts Transmit Transmit Centre...
  • Page 16 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 345 mm 22.5 12.5 mm Note: Bezel and panel cutout are offset from one another horizontally Top view Max. panel thickness = 25.4 mm Door opens Front view Lift latch to operate Configuration Right side Port 148 mm 380 mm...
  • Page 17 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 1.2.2 ELECRICAL INSTALLATION (Cont.) Controller A Controller B Transmitter power supply Nº2 2A 2B 3A3B V- V+ VI 1B 2A 2B 3A3B V- V+ VI O/P 1 O/P 2 Alarm Input O/P 1 O/P 2 Alarm Input Transmitter power supply Nº1...

  • Page 18: Supply Voltage (Mains) Wiring

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 1.2.2 ELECTRICAL INSTALLATION (Cont.) SUPPLY VOLTAGE (MAINS) WIRING Leave the Earth lead longer than the others, so it would be the last to become disconnected should the cable be pulled out of the connector. Blue Brown Grn/Ylw (White)

  • Page 19: Signal Wiring

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 1.2.2 ELECTRICAL INSTALLATION (Cont.) SIGNAL WIRING V+ V- V+ V- V+ V- Shunt Attenuator assembly assembly – – – DC V (-2V<Vin<10V) DC V DC mA DC mV (– 20 to +100V) Thermocouples V+ V- V+ V- V+ V- V+ V-...

  • Page 20: Changing The Chart

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 1.3 CHANGING THE CHART Op:Display Op: Display Op:Chart Op: Chart ↵ for Fast Chart Off ↵ to Align Chart ↵ for Chart On ↵ to Park WITHOUT YET LOWERING THE LOCKING TAB ↵ to align Chart locked Chart...

  • Page 21: Changing The Cartridge

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 1.4 CHANGING THE CARTRIDGE ↵ for Chart On Lift arm Remove cartridge Figure 1.4 Changing the cartridge HA250385 Issue 7 Nov 06 Page 17...

  • Page 22: Basic Operation

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2 BASIC OPERATION 2.1 POWER UP 09:15 29/02/96 12 Hour Chart 29/02/96 7 Day Chart 2.2 BACKGROUND DISPLAY (Measuring channel) 01 1.2345 Units (Derived (maths) channel) D01 1.2345 Units (Totaliser) T1 123456789 Units (Counter) C1 12345678 Units 01 586.03 Deg C Furnace 1 temp A Alarms: 1...

  • Page 23: Alarm Indication

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.3 ALARM INDICATION 2.4 KEY/DISPLAY FUNCTIONS Channel alarms Channel alarms Global 20 Character Display Channel alarm Edit/Hold Enter Alarm Page up Page down Cursor Scroll up Scroll down Cancel acknowledge Figure 2.4 Operator interface 2.4.1 Keys ALARM ACKNOWLEDGE PAGE UP/DOWN CURSOR...

  • Page 24: Scroll Up / Down Keys

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.4.1 KEYS (Cont.) SCROLL UP / DOWN KEYS CANCEL ENTER Op:Display 2.4.2 Indicators CHANNEL ALARMS GLOBAL ALARM EDIT/HOLD HA250385 Page 20 Issue 7 Nov 06...

  • Page 25: Configuration Example

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.5 CONFIGURATION EXAMPLE 2.5.1 Channel inputs/outputs 2.5.2 Entering configuration Op: Display Op:Chart Op:Alarm Summary Op:Channel 1 Alarm 1 Op: Action Op:Clock Op:System Error Op:Configuration Password 00000 HA250385 Issue 7 Nov 06 Page 21...

  • Page 26: Channel Configuration

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.5.2 Entering Configuration (Cont.) Password 00000 Password 00000 Password 00000 Password 00000 Password 00010 2.5.3 Channel configuration Conf: Instrument Conf:Chart Conf:Channel 1 Conf:Channel 2 Channel : Range I/P Type Off I/P type T/C I/P Range Lo 0.00 I/P Range Hi 0.00...

  • Page 27: Temperature Units

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.5.3 CHANNEL CONFIGURATION (Cont.) TEMPERATURE UNITS I/P Units ˚C Lin Type Type B Lin Type Type C LINEARIZATION TYPE Lin Type Type E Lin Type Type J CJC TYPE CJC Type Off CJC Type Internal SCALE PAGE Unscaled VALUE FORMAT...

  • Page 28: Input Break Response

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.5.3 CHANNEL CONFIGURATION (Cont.) INPUT BREAK RESPONSE Damping None Brk Rsp None OFFSET Brk Rsp Drive Hi Offset 0.00 Tag: Channel 1 Tag: Furnace1 tempA Tag: Furnace1 tempA Channel : Range ALARM TYPE Channel :Range Channel : Alarm 1 Channel : Alarm Alarm : Setpoint...

  • Page 29: Alarm Threshold (Setpoint)

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.5.3 CHANNEL CONFIGURATION (Cont.) Type Absolute High ALARM THRESHOLD (SETPOINT) Threshold 0.00 Threshold 780.00 Threshold 780.00 Alarm : Setpoint Alarm : Setpoint Alarm : Job 1 ALARM JOBS No Action Chart Online Chart span B Ch 1 Chart Span B for All Disable all alarms Ack all alarms...

  • Page 30: Checking That The Trace Is On

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 2.5.3 CHANNEL CONFIGURATION (Cont.) Channel : Trace CHECKING THAT THE TRACE IS ON Trace Off Trace On Trace On Channel : Trace Conf:Channel 2 Op: Configuration OP:Display 02 > Range deg C 02 < Range deg C HA250385 Page 26...

  • Page 31: Operator Menus

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3 OPERATOR MENUS 3.1 INTRODUCTION 3.2 TOP LEVEL OPERATOR MENUS Op:Display Op:Chart Op:Alarm Summary Cancel key Op:Alarm setup OP:Action Op:Clock Page up key Op:System error Op:Configuration Page down key OP:Calibrate chart 3.3 CHART SUBMENU HA250385 Issue 7 Nov 06 Page 27...

  • Page 32: Chart On/Off

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3.3 CHART SUBMENU (Cont.) Op:Chart for Fast Chart Off for Chart Off Please wait Speed is HHH hour Please wait for Chart On to Send Log 1 to Send Log 2 Printhead parks to Park to Dump Scales to Align Chart Chart advances 0.2mm per...

  • Page 33: Logs

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3.3.2 Logs OPERATOR INITIATION ↵ to Send Log N JOB INITIATION AUTOMATIC LOGGING 3.3.3 Scale print (Dump Scales) ↵ to Dump Scales 3.4 ALARM SUMMARY PAGE Op:Alarm Summary Figure 3.4 Alarm summary page HA250385 Issue 7 Nov 06 Page 29...

  • Page 34: Display Interpretation

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3.4.1 Display interpretation 3.5 ALARM SETUP PAGE Use up/down arrows and cursor to select Op:Channel 1 Alarm1 channel number and alarm number. View alarm type: Abs high/low, ROC rise/fall or Deviation in/out. Dev in Ref 10.00 Edit setpoint if necessary using arrow up/down keys.

  • Page 35: Back-Up Battery

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3.7.1 Back-up battery 3.8 SYSTEM ERROR 3.9 CONFIGURATION Op:Configuration Password 00000 Conf:Instrument To further config pages Figure 3.9 Entry to configuration HA250385 Issue 7 Nov 06 Page 31...

  • Page 36: Calibrate Chart

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3.10 CALIBRATE CHART Op:Calibrate Chart Paper zero. Use / Paper span. Use / Figure 3.10a Chart calibration pages Use up/down keys to adjust trace position (Effects shown much exaggerated for clarity) Adjust zero first. Up arrow moves trace right; Down arrow moves trace left Figure 3.10b Zero and Span adjustments (simulated chart sample) HA250385...

  • Page 37: Operator Menu Summary

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 3.11 OPERATOR MENU SUMMARY Background Process Variable (PV) display Use 'Page' keys to move from page to page. 1 568.37 Deg C Use 'Cancel' key to enter Operator menus Use 'Enter' key to enter 'Page', to confirm changes or to return to PV display.
  • Page 38 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 34 Issue 7 Nov 06...

  • Page 39: Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4 CONFIGURATION 4.1 INTRODUCTION 4.1.1 Password Setting the password to a 00000 sub- sequently allows direct access from the operator menu without further need for a password. 4.1.2 Text entry CHARACTER SET β Σ µ Ω δ ❝...
  • Page 40 MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.1 INTRODUCTION (Cont.) Parameter etc. to be edited Configuration page name Where to look Adaptive recording Chart Section 4.4.5 Adjust input Adjust Section 4.14 Alarm Jobs Channel: Alarm: Jobs Section 4.5.2 Alarm Parameters Channel : Alarm : Setpoint Section 4.5.2 Break response Channel : Range...

  • Page 41: Options

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.1.3 Options 4.1.4 Logs 1 and 2 4.1.5 Jobs HA250385 Issue 7 Nov 06 Page 37...
  • Page 42 MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.1.5 JOBS (Cont.) No Action Chart online N = Channel number (use up/down arrow keys) While Active Chart Span B Ch N While Inactive Chart Span B for All While UnAck'ed Disable all alarms Ack All Alarms Log 1 to chart On Going Active Log 2 to chart...

  • Page 43: Configuration Techniques

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.2 CONFIGURATION TECHNIQUES Characters shown underlined flash on and off when available for edit. Conf : Channel 1 Channel : Range Alarm : Setpoint Alarm : Job 1 Channel : Alarm 1 Channel : Trace Enable off Enable Unlatched Use page keys to move...

  • Page 44: Instrument Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.3 INSTRUMENT CONFIGURATION Conf:Instrument Use Cursor and arrow keys to enter new Set Password: 00010 password. Language: English Scrolls through English, French, German Scrolls through Enabled, Disabled Remote CJ Disabled Use Arrow keys to enter channel number Remote CJ Channel: 1 Scrolls through C, F, K, R Remote CJ units...

  • Page 45: Chart Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.4 CHART CONFIGURATION Conf:Chart Scrolls through 48 hour, 72 hour, 7 day, Speed: 24 hr User, 12 hour, 24 hour. Use up/down arrows and cursor to enter User Speed: 24 hour chart speed between 1 and 960 hours/rev. Scroll through Stop after 1 rev: no yes/no...

  • Page 46: Stop After One Revolution

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.4.3 Stop After One Revolution 4.4.4 Log intervals A and B 4.4.5 Printing TIME/DATE/CHART SPEED SCALE MESSAGES 4.4.6 Adaptive recording HA250385 Page 42 Issue 7 Nov 06...

  • Page 47: Channel Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5 CHANNEL CONFIGURATION 4.5.1 Range configuration Ω INPUT TYPE INPUT RANGE SHUNT VALUE Ω Ω INPUT UNITS HA250385 Issue 7 Nov 06 Page 43...

  • Page 48: Linearisation Type

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.1 RANGE CONFIGURATION (Cont.) LINEARISATION TYPE Conf:Channel 1 Channel : Alarm 1 Channel : Range Channel : Trace Scrolls through T/C, mV, V, mA, RTD, I/P type Off I/P type T/C Ohms, Dig, Comms (if fitted), Cont1 (if fitted), Cont2 (if fitted), Test.

  • Page 49: Cjc Type

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.1 RANGE CONFIGURATION (Cont.) CJC TYPE SCALED VALUE FORMAT Input DAMPING Recorder response Damping BREAK RESPONSE HA250385 Issue 7 Nov 06 Page 45...

  • Page 50: Open / Closed

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.1 RANGE CONFIGURATION (Cont.) OPEN / CLOSED __-__ _____ TEST WAVEFORMS HA250385 Page 46 Issue 7 Nov 06...

  • Page 51: Alarm Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.2 Alarm configuration SETPOINT CONFIGURATION Use arrow keys to select channel Conf:Channel 1 Use arrow keys to select alarm 1 to 4 Channel : Alarm 1 Channel : Range Channel : Trace Alarm : Job 1 Alarm : Setpoint Scrolls through Enable Off...
  • Page 52 MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.2 ALARM CONFIGURATION (Cont.) Latest part of chart Absolute High Absolute Low setpoint setpoint Measured Absolute Low value alarm active Absolute High alarm active setpoint - hysteresis Hysteresis Hysteresis Earliest part of chart setpoint + hysteresis Figure 4.5.2b Absolute alarm definition Reference + Deviation Reference + deviation...

  • Page 53: Alarm Parameters

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.2 ALARM CONFIGURATION (Cont.) Latest part of chart Rate of change - rise alarm active Measured value Rate of change - fall Rate of change - fall alarm active alarm active In this example, both rise and fall alarms are triggered at 200 litres per minute Rate of change - rise...

  • Page 54: Trace Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.3 Trace configuration Trace Colour Line thickening Span A / Span B HA250385 Page 50 Issue 7 Nov 06...
  • Page 55 MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.5.3 TRACE CONFIGURATION (Cont.) Use arrow keys to select channel Conf:Channel 1 Channel : Alarm 1 Channel : Trace Channel : Range Trace Off Scroll through Off, On Scroll through blue, red, green, black, blue/red, green/black Colour Blue Scroll through Off, On Line Thickening Off...

  • Page 56: Group Configuration

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.6 GROUP CONFIGURATION Conf:Group Display Conf:Group Log 1 01 02 03 04 05 06 01 02 03 04 05 06 Conf:Group DV Option PVs (if fitted) Option PVs (if fitted) Conf:Group Log 2 Include item tag yes Note: DV Group appears only if maths option fitted...

  • Page 57: Dv Group

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.6 GROUP CONFIGURATION (Cont.) 4.6.2 DV Group 4.6.3 Display Group 4.7 OPERATOR ACTION CONFIGURATION ↵ Conf:Oper Action Use arrow keys and cursor Label:ACK ALL key to enter text string Latched yes Latched no Figure 4.7 Operator action configuration 4.8 CLOCK CONFIGURATION Conf:Clock Use arrow keys and cursor...

  • Page 58: Format

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.8 CLOCK CONFIGURATION (Cont.) FORMAT 4.9 MESSAGE CONFIGURATION 4.9.1 Embedded sequences ONE PART SEQUENCES TWO PART SEQUENCES HA250385 Page 54 Issue 7 Nov 06...

  • Page 59: Internal Events

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.9.1 EMBEDDED SEQUENCES (Cont.) <TIME><.TA><-PV> <TIME><6.TA><6-PV> 4.10 INTERNAL EVENTS Ch 4 Event 2 Event Job 1 Event 1 Send log 1 S1.S2 Ch 2 to chart S1.S2 4.10.1 Event sources HA250385 Issue 7 Nov 06 Page 55...
  • Page 60 MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.10 EVENT CONFIGURATION (Cont.) Use arrow keys to select event Conf:Events 1 number Event : Job 1 See section 4.1.5 for a list of jobs. Event : Source Event Enabled Event Disabled S1 And S2 S1 Or S2 S1 Only S2:System error...

  • Page 61: Configuration Transfer

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.11 CONFIGURATION TRANSFER Conf:Transfer to Save Config Config Saved to Restore Config Config Restored Scrolls through 150, 300, 600, Baud rate 150 1200, 2400, 4800, 1800, 9600, 19200. Figure 4.11 Configuration transfer pages. ↵ TO SAVE CONFIG ↵...

  • Page 62: Operator Access

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.12 OPERATOR ACCESS Conf:Access Use Arrow keys to scroll Chart On/Offline:yes through no, yes Use Arrow keys to scroll Start Chart log:yes through no, yes Use Arrow keys to scroll Chan Alarm Thold:no through yes, no Figure 4.12 Operator permissions pages HA250385 Page 58...

  • Page 63: Adjust

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.13 ADJUST 4.13.1 Input adjust Conf:Adjust Adjust : Input Adjust : Chart Apply to Ch1..1 Use arrow/cursor keys to enter range of channels Apply known low signal to input(s); Wait for displayed value(s) to stabilise (view other channels using arrow keys) then 'Enter'. Low point ready Enter actual low point value Low Point is...

  • Page 64: Chart Adjust

    MULTI-POINT CIRCULAR-CHART RECORDER: USER GUIDE 4.13.2 Chart adjust 4.14 DEFAULT CONFIGURATION Conf:Default to default config Sure? Please wait Chan 1 Units Figure 4.14 Default config ation HA250385 Page 60 Issue 7 Nov 06...

  • Page 65: Configuration Menu Summary

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 4.15 CONFIGURATION MENU SUMMARY Use page up/page down keys to move from page to page Use 'Enter' key to enter current display page Top level Operator menu or to confirm changes. OP:Configuration Use up and down arrow keys to scroll through a flashing item's menu list.
  • Page 66 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 62 Issue 7 Nov 06...

  • Page 67: Relay Output Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 5 RELAY OUTPUT OPTION 5.1 INTRODUCTION In alarm or power off conditions, the common and normally closed contacts are closed. 5.1.1 Configuration JOBS 5.1.2 Relay specification Number of relays per board two, four or six Estimated life 30,000,000 operations Maximum contact voltage...

  • Page 68: Relay Wiring

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 5.2 RELAY WIRING 5.2.1 Six change-over (also called Form C or SPDT) relays board board 1 board 2 board 3 Lever switch positons for: - board 1 (relays 1 to 6) - board 2 (relays 7 to 12) - board 3 (relays 13 to 18) Relay 1 Relay 6...

  • Page 69: Analog Output (Retransmission) Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 6 ANALOG OUTPUT (RETRANSMISSION) OPTION 6.1 INTRODUCTION 6.2 SPECIFICATION VOLTAGE OUTPUT Voltage:0 to 10 V calibrated (max. current limit 12.3 mA at 11.5 V) Max. linearity error: 2.0 mV Min. resolution: 1.6 mV +/- 2 Ω Max.

  • Page 70: Wiring

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 6.3 WIRING +V –C +V –C Voltage Current +V -C +I +V -C +I +V -C +I +V -C +I output output CON 1 CHAN 1 connection connection Output 1 Output 2 Output 3 Output 4 Figure 6.3 Retransmission option wiring 6.4 CONFIGURATION PAGES Conf:O/P Channel N...
  • Page 71 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 6.4 CONFIGURATION PAGES (Cont.) THE CHANNEL OUTPUT GOES TO µ –C -1.1 V –C TERMINALS AND TO APPROXIMATELY ACROSS THE TERMINALS HA250385 Issue 7 Nov 06 Page 67...

  • Page 72: Output Adjust

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 6.5 OUTPUT ADJUST Conf:Adjust Adjust:Input Adjust:Output Adjust:Chart Use up/down arrow keys to select channel Use up/down arrow keys to select channel Select required o/p channel Apply to O/P 1 View Adjust O/P 1 Remove from O/P 1 using up/down arrow keys Set required low o/p value Low output LLL.LL...

  • Page 73: Maths Pack Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7 MATHS PACK OPTION 7.1 INTRODUCTION 1.00 Level 2 functions (additional to level 1 functions) Level 1 functions Square root DV group continuous maximum Channel average Constant Third order polynomial DV Group average Copy Relative humidity Rolling average F value Subtract...

  • Page 74: Operator

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.1.3 Operator pages Op Maths 1 ↵ to reset 37.54 Maths channel reset 7.2 EQUATIONS 7.2.1 Level 1 equations CONSTANT Value: 1.00 COPY Copy Ch 1 Add Ch 1 to Ch 1 SUBTRACT Sub Ch 1 from Ch 1 MULTIPLY Mult Ch1 by Ch 1 DIVIDE...

  • Page 75: Level 2 Equations

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 Level 2 equations SQUARE ROOT Square root of Ch 1 CHANNEL AVERAGE Average of Ch 1 Time interval GROUP AVERAGE DV Group average ROLLING AVERAGE Average of Ch 1 Sample Int Num of Points E TO THE POWER ≈...

  • Page 76: Rate Of Change

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) RATE OF CHANGE Rate of Chg of Ch 1 Sample period Sample rate SAMPLE AND HOLD Sample & Hold Ch 1 CHANNEL MINIMUM Minimum of Ch 1 DV GROUP LATCH MIN DV Grp Latch Min DV GROUP CONT MIN DV Grp Cont Min...

  • Page 77: Relative Humidity

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) RELATIVE HUMIDITY Wet temp Ch 1 Dry temp Ch 1 Atm Pressure Ch 1 Psych Const 6.66-4 F VALUE F value Ch 1 Ster. Temp 1.00 ma t et temp ×...

  • Page 78: Mass Flow Linear

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) MASS FLOW LINEAR Independent verification is recommended before this recorder is used for custody transfer. × Flow AbsP × Rg Z Temp × × × (J/kg-K) 287.1 Ammonia 488.2 Carbon dioxide 188.9 Carbon monoxide 296.8...
  • Page 79 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) × ρ ρ Flow Ch 1 Temperature Ch 1 Abs Press Ch 1 Constant 1.00 HA250385 Issue 7 Nov 06 Page 75...

  • Page 80: Mass Flow Square Root

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) MASS FLOW SQUARE ROOT Independent verification is recommended before this recorder is used for custody transfer. × DeltaP AbsP × × Rg Z Temp Const × Rg Z Differ Press Ch 1 Temperature Ch 1 Abs Press Ch 1 Constant...

  • Page 81: Zirconia Probes

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) ZIRCONIA PROBES × Probe temp Ch 1 Probe EMF Ch 1 Reference 1.00 HA250385 Issue 7 Nov 06 Page 77...

  • Page 82: Switch

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) Op = 0.00457 × T × logOp' ′ E = (10.84 × T) + 40mV SWITCH Switch Ch A Ch 1 Switch Ch B Ch 1 HIGH SELECT Higher of Chs 1, 1 LOW SELECT Lower of Chs...

  • Page 83: Time Stamp

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) TIME STAMP OXYGEN (O ) CORRECTION 20.9% - Spec O × Qmt = Meas. gas 20.9% - Meas O less than the actual measured gas value This may not be allowed by some regulatory agencies.

  • Page 84: Percentile

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.2.2 LEVEL 2 EQUATIONS (Cont.) PERCENTILE Fn:Percentile Source Ch 1 Threshold 1.0000 Limit is High Sample int Num of Points HA250385 Page 80 Issue 7 Nov 06...

  • Page 85: Configuration

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 7.3 CONFIGURATION MATHS PACK UNIQUE PARAMETERS HA250385 Issue 7 Nov 06 Page 81...
  • Page 86 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 82 Issue 7 Nov 06...
  • Page 87 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE Level one functions Level two functions Fn:Square Root Square Root of Ch 1 Fn:Channel Average Average of Ch 1 Time Interval Conf:DV 1 Fn:DV Group Average DV : Function Fn:Rolling Average Average of Ch 1 Sample Int Num of Points Fn:Off...
  • Page 88 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 84 Issue 7 Nov 06...

  • Page 89: Totalisers, Counters And Timers

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8 TOTALISERS, COUNTERS AND TIMERS 8.1 INTRODUCTION 8.2 TOTALISERS 8.2.1 Source types 8.2.2 Alarms 8.2.3 Display 8.2.4 Tracing on the chart (maths pack level 1 required) 8.2.5 Operator pages Op:Totalizer 1 ↵ preset nn.nn Ed Preset 0.00 HA250385 Issue 7 Nov 06...

  • Page 90: Totalizer Configuration

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8.2.6 Totalizer configuration Scroll through 1 to 6 Conf:Totalizer 1 Tot : Alarm Tot : Function Scroll through: Alarm : Set Point Function: Disabled Enabled/Disabled Scroll through: Enter Source Ch Thold: 0.00 available sources value Scroll through Units scaler 0.00...

  • Page 91: Alarm Pages

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8.2.6 TOTALIZER CONFIGURATION (Cont.) Except as (*) below, the period scaler is ALWAYS the number of seconds ALARM PAGES ≥ ≤ HA250385 Issue 7 Nov 06 Page 87...

  • Page 92: Totalizer Counter Output

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8.3 TOTALIZER COUNTER OUTPUT O/P (output)factor: 8.4 COUNTERS 8.4.1 Introduction ≥ ≤ 8.4.2 Tracing on the chart (maths pack level 1 required) 8.4.3 Display 8.4.3 Operator pages Op:Counter 1 ↵ preset nn.nn Ed Preset 0.00 HA250385 Page 88 Issue 7 Nov 06...

  • Page 93: Configuration

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8.4.4 Configuration Scroll through 1 to 6 Conf:Counter 1 Counter : Alarm Counter : Function Alarm : Set Point Preset Val Enter preset value Enter Units: 5char Thold: value Enter text string Scroll through Scroll through Glb Reset:disable Limit is High high/low...

  • Page 94: Timers

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8.5 TIMERS 8.5.1 Introduction Op:Timer 1 8.5.2 Operator pages Rpt in 0d 0h 0m 0s ↵ to Start ↵ to Reset 8.5.3 Configuration Scroll through Conf:Timer 1 1 to 6 Scroll through Timer : Function Timer : Job 1 1 to 2 Scroll through...

  • Page 95: Jobs Pages

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 8.5.3 TIMER CONFIGURATION (Cont.) JOBS PAGES 8.5.4 Timer examples Start XX/01/XX 12:00 Start 31/12/XX 12:30 Repeat 1h 0m 0s HA250385 Issue 7 Nov 06 Page 91...

  • Page 96: Controllers Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 9 CONTROLLERS OPTION 9.1 INTRODUCTION can be can not Controllers can not be fitted on dc powered recorders. Channel alarms 150.2 Edit/Hold MAN HOLD MAN HOLD Controller 1 Controller 2 Figure 9.1 Controller locations 9.2 VIEWING ON RECORDER CHANNEL 9.3 WIRING 9.3.1 Output and PV data 9.3.2 User input (T/C, RTD, mA, volts or mV)
  • Page 97 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 9.3 WIRING (Cont.) Option Board Power Supply Board Option Board Power Supply Board Micro Board The number and mix of the boards varies according to the options fitted. Option Boards Input Board Option Boards Controller 1 Output Controller 2 Output 1A 1B 2A 2B 3A 3B 1A 1B 2A 2B 3A 3B...

  • Page 98: Specification

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 9.4 SPECIFICATION Inputs ±100 mV and 0 - 10 V dc (auto ranging) Range Sample rate 9 Hz (110 ms) 0.25% of reading, ±1 LSD, ±1˚C/F Calibration accuracy <1 µV for 100 mV range, <0.2 mV for 10 V dc range Resolution Linearisation accuracy <0.1% of reading...

  • Page 99: Custom Linearisation Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 10 CUSTOM LINEARISATION OPTION 10.1 INTRODUCTION 10.2 CONFIGURATION PAGES Conf:Lin Table Scroll to 15 for this example. Do not press 'Enter' Use First 2 Values until all X-Y values have been entered. 1 X: -5.00 Y: -125.0 9 X: 1.00 Y: 1.00 2 X: -4.00 Y: -64.00...

  • Page 100: Serial Communications Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11 SERIAL COMMUNICATIONS OPTION 11.1 INTRODUCTION 11.1.1 Safety isolation specification 11.2 WIRING 11.2.1 Pinout Ω TxA CMN RxB RxA Figure 11.2.1 Communications option pinout single HA250385 Page 96 Issue 7 Nov 06...

  • Page 101: Termination And Biasing

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11.2.2 Termination and Biasing Ω 5 Volts 100k 220R 100k Transmit lines from host 0 Volts Recorder B (Final recorder) 5 Volts 100k resistors built into circuit board. For the sake of clarity, only Host transmit lines shown. 0 Volts Recorder A Figure 11.2.2a System termination and biasing...

  • Page 102: Configuration

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11.2.2 TERMINATION AND BIASING (Cont.) 5 Volts 5 Volts 470R Host receiver Host receiver Transmit lines from Transmit lines from recorder recorder 470R 0 Volts 0 Volts a. Host with external bias resistors b. Host with external bias resistors providing termination.

  • Page 103: Gould Modicon Modbus Protocol

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11.4 GOULD MODICON MODBUS PROTOCOL 11.4.1 Introduction 11.4.2 Channel addressing ALARM TYPE PARAMETER DEFINITION Absolute A1 to A4 Not used Absolute SP1 to SP4 Setpoint values Deviation A1 to A4 Deviation Values Deviation SP1 to SP4 Setpoint values Rate A1 to A4...

  • Page 104: Function Codes

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11.4.4 Function codes Table 11.4.4 Modbus implementation channel addresses (Sheet 1: codes 01 to 03) HA250385 Page 100 Issue 7 Nov 06...
  • Page 105 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11.4.4 FUNCTION CODES (Cont.) Table 11.4.4 Modbus implementation channel addresses (Sheet 2) HA250385 Issue 7 Nov 06 Page 101...

  • Page 106: Xmodem Transfer

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 11.4.4 FUNCTION CODES (Cont.) Table 11.4.4 Modbus implementation channel addresses (Sheet 3) 11.5 XMODEM TRANSFER Recorder PC Serial Port (9-pin) Receive Receive RS422 to Transmit Transmit RS232 Converter 0 Volts 0 Volts Figure 11.5 Recorder to PC wiring for transfer using configuration program HA250385 Page 102 Issue 7 Nov 06...

  • Page 107: Memory Card Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12 MEMORY CARD OPTION 12.1 INTRODUCTION 12.2 MEMORY CARD INSERTION right Card eject button Figure 12.2a Memory card insertion HA250385 Issue 7 Nov 06 Page 103...
  • Page 108 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12 MEMORY CARD (Cont.) Background Display Furnace 1 Temp Deg C Op:Display Op:Chart Op:Alarm Summary MC:Directory Op:Alarm thresholds MC:Delete Op:DV alarm t'holds MC:Status Op:Action MC:Offline Op:Clock MC:Save Config Op:System error MC:Restore Config Op:Configuration MC:Format Op:DV reset MC:Archive 1 Op:Totaliser MC Archive 2...

  • Page 109: Card Formatting

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.2.1 Card formatting ↵ MC:Directory MC:Delete MC:Status CHANGE CARD WHEN OFFLINE MC:Offline MC:Save Config Card is Offline MC:Restore Config 'Format' deletes all data on the card MC:Format Format type SRAM MC:Archive 1 MC:Archive 2 to Format Please Wait Figure 12.2.1 Card format and off-line menus 12.2.2 Changing cards...

  • Page 110: Configuration Save And Restore

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.3 CONFIGURATION SAVE AND RESTORE MC:Directory 12.3.1 Save MC:Delete MC:Status MC:Offline MC:Save Config Save to:CONFIG .CFG Enter 8-character (max.) filename to Overwrite Filename already in use Filename not previously used with this card Overwrite Do not overwrite Saving config Config save complete Figure 12.3.1...

  • Page 111: Data Logging (Archive)

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.4 DATA LOGGING (ARCHIVE) MC:Directory 12.4.1 Archive Configuration MC:Delete MC:Status MC:Offline MC:Save Config MC:Restore Config MC:Format MC:Archive to Send Log 1 to Send Log 2 Figure 12.4.1 Operator Log initiation “XXXXA”, ,”1",”3" “XXXXA”, ,”2",”3" “DD/MM/YY”,”HH:MM:SS”,”˚C”,”Bar” “Log”,, “Log”,,”TempVes1",”PresVes1"...

  • Page 112: Jobs

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.4.1 ARCHIVE CONFIGURATION (Cont.) Table 12.4.2 JOBS HA250385 Page 108 Issue 7 Nov 06...
  • Page 113 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.4.1 ARCHIVE CONFIGURATION (Cont.) Conf:Memory Card MC:Directory MC:Delete MC:Status MC:Offline MC:Save Config N--N in filenames = Editable characters YY = Year number MM = Month number MC:Restore Config DD = Day number HH = Hour number MC:Format CCCCCCCC = Value of counter N MC:Archive 2...

  • Page 114: Archive Interval

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.4.2 Archive interval 12.5 OPERATOR ACCESS Conf:Access Chart Speed:yes Dashed box = This page appears only if ChartOn/Offline:yes the associated option is present. Edit/Print Text:no Send Chart Log:yes MC Conf Save:no Chan Alarm Thold:no MC Conf Restore:no DV Alarm Thold:no MC Format:no MC Status/Dir:yes...

  • Page 115: Memory Card General Functions

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.6 MEMORY CARD GENERAL FUNCTIONS 12.6.1 Directory MC:Directory RN080502.ASC 05/08/97 10:39:38 RICHAERT.CFG 5636 06/08/97 10:05:52 RN080610.ASC 06/08/97 10:42:00 CONFIG .CFG 7936 ZN080611.ASC Figure 12.6.1 Directory function display pages 12.6.2 Delete ↵ MC:Delete Erase RN080502.ASC Sure? RN031802.ASC Erase REICHERT.CFG Please wait Erase RN080610.ASC...

  • Page 116: Card Status

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.6.3 Card status MC:Status Usage: 128K Write Protected: no Figure 12.6.3 Status display pages 12.6.4 Automatic file deletion Existing configuration files (.CFG) are not deleted. 12.7 ARCHIVE FILES MC:Archive 1 Filename formats for ASCII files (extension = .ASC). PACKED names identical except extension = .PKD File type ASCII Use cursor key then up/down...

  • Page 117: Text File Names

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.7.1 Text file names 12.7.2 Hourly file names 12.7.3 Daily file names 12.7.4 Counter file names 12.7.5 File name extensions HA250385 Issue 7 Nov 06 Page 113...

  • Page 118: Rules For Creation Of Files

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.7.6 Rules for creation of files 12.8 OTHER INFORMATION 12.8.1 Event sources 12.8.2 System errors 12.8.3 Error messages HA250385 Page 114 Issue 7 Nov 06...

  • Page 119: Memory Card Configuration Menu Overview

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 12.9 MEMORY CARD CONFIGURATION MENU OVERVIEW Operator menus Op:Configuration Conf:Instrument Conf:Chart Conf:Channel 1 MC:Directory Conf:Group Display MC:Delete Conf:Oper Action MC:Status Conf:Clock MC:Offline Conf:Message 1 MC:Save Config Conf:Alarm Messages MC:Restore Config Conf:Event 1 MC:Format Conf:DV MC:Archive 1 Conf:Totalizer 1 MC:Archive 2 Conf:Counter 1...

  • Page 120: Transmitter Power Supply Option

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 13 TRANSMITTER POWER SUPPLY OPTION 13.1 INTRODUCTION Link for 115Vac Remove for 230V ac Remove for 115Vac Link for 230V ac Output 3 Shunt Link for 115Vac boards on Remove for 230V ac channel Output 2 inputs Output 1 Fuse type = 20mm slow-blow...

  • Page 121: Signal Wiring

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 13.2 SIGNAL WIRING Transmitter power supply No. 2 Transmitter power supply No. 1 'Micro board' Channel 1 connection to transmitter power supply. Other channels use similar connections. Input board I V+ V- I V+ V- I V+ V- I V+ V- I V+ V-...
  • Page 122 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 118 Issue 7 Nov 06...

  • Page 123: Reference

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14 REFERENCE Product: WATER BASED INKS NOT CONTAINING FORMAMIDE 14.1 COSHH Part numbers: LA248163 LA249556 LA250280 14.1.1 Printheads HAZARDOUS INGREDIENTS Name % Range Toxicological data Acid dye 1 to 4 Not available Not established PHYSICAL DATA 1.05 to 1.1 Boiling point >212 C...

  • Page 124: Batteries

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.1.2 Batteries Product: Rechargeable batteries Part numbers: PA250331 HAZARDOUS INGREDIENTS Name % Range Toxicological data Mischmetal alloy available Highly toxic if ingested Nickel Hydroxide available Potassium hydroxide Highly toxic, Highly corrosive. available PHYSICAL DATA Not applicable Specific gravity Boiling point Not applicable...

  • Page 125: Error Messages

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.2 ERROR MESSAGES 14.2.1 Invalid configuration 14.2.2 Failure to adjust channel (Adj fail on ch NN) 14.2.3 Input adjust not available (I/P Adj n/a on ch NN) 14.2.4 Printer must be off line HA250385 Issue 7 Nov 06 Page 121...

  • Page 126: List Of Effective

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.3 LIST OF EFFECTIVE PAGES HA250385 Page 122 Issue 7 Nov 06...

  • Page 127: Glossary Of Terms

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.4 GLOSSARY OF TERMS input signal job list relay output analogue input derived channel thermocouple configure process variables memory card communications job list job list alarms retransmission HA250385 Issue 7 Nov 06 Page 123...
  • Page 128 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.4 GLOSSARY OF TERMS (Cont.) input channel derived channel math- ematical function job list input signal setpoint alarms Start Alarm without hysteresis Input signal value Al arm off only when value falls below 90. Alarm with hysteresis input signals relay transducers...
  • Page 129 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.4 GLOSSARY OF TERMS (Cont.) Maths functions (Cont.) Constant Square root Log base 10 Latching maximum Switch Copy Channel average Rate of change Continuous maximum High select Group average Sample and hold Polynomial Low select Subtract Rolling average Channel minimum...
  • Page 130 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE 14.4 GLOSSARY OF TERMS (Cont.) process variable linearisation tables job lists thermocouples resistance ther- mometers (RTDs) pens/printheads HA250385 Page 126 Issue 7 Nov 06...

  • Page 131: Annex A Technical Specification

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE ANNEX A TECHNICAL SPECIFICATION HA250385 Issue 7 Nov 06 Page 127...

  • Page 132: A1 Technical Specification (Recorder)

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE A1 TECHNICAL SPECIFICATION (Recorder) Board types (I/O) Universal input board, 6-Changeover relay output board, 4-Channel analog output (retransmision) board Options (See options manual) Host Communications Memory Card Transmitter Power Supply Controllers (see also separate controller manual) Also Case Heater (not described) Environmental Performance Temperature limits...

  • Page 133: A2 Technical Specification (Input Board)

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE A2 TECHNICAL SPECIFICATION (Input board) General Termination Terminal block Maximum number of inputs Six. ±38mV, ±150mV, ±1V, ±10V Input ranges Input types DC Volts, dc millivolts, dc milliamps (with external shunt), thermocouple, 2 / 3-wire resistance temperature detector (RTD), Ohms, Contact closure (not channel 1) (Minimum contact closure = 500msec) Input type mix Freely configurable...
  • Page 134 -50 to + 170 DIN43760:1987 0.01 C Pt100 -200 to + 850 IEC 751 0.01 C Pt100A -200 to + 600 Eurotherm Recorders SA 0.09 C Pt1000 -200 to + 850 IEC 751 0.01 C Thermocouple data Temperature scale ITS90 1.7nA on ±38mV range, 8nA on all other ranges...

  • Page 135: Index

    MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE INDEX Symbols Channel (Cont.) Linearisation types ........... 44 10 to the power (Maths function) ......... 71 Nº of decimal places ..........45 Open/closed text ............46 Scaling ..............45 Absolute alarms ............48 Selection for display ..........53 Adaptive recording ............
  • Page 136 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE Damping ............... 45 Input Data logging ............... 107 Adjust ............... 59 Date Range entry ............. 43 Format ..............53 Type selection ............43 Inclusion in messages ..........54 Units selection ............43 Printing on the chart ..........42 Input board Setting ..............
  • Page 137 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE Open/closed text ............46 Safety notes ..............10 Operation Sample and hold (maths function) ......72 Detailed ............27 to 32 Scale Operator Printing on the chart ..........42 Access to configuration ........... 58 Scaling ................. 45 Menus Serial comunications option ........
  • Page 138 MULTIPOINT CIRCULAR-CHART RECORDER: USER GUIDE This page is deliberately left blank HA250385 Page 134 Issue 7 Nov 06...
  • Page 139 E-mail info.de@eurotherm.com E U ROT H E R M EUROTHERM LIMITED Faraday Close, Durrington, Worthing, West Sussex, BN13 3PL Telephone: +44 (0)1903 268500 Facsimile: +44 (0)1903 265982 e-mail: info.uk@eurotherm.com Website: http://www.eurotherm.co.uk Specification subject to change without notice. ©Eurotherm Limited. HA250385/7 (CN22887)

Table of Contents
