Host Requirements
Wireless USB connectivity can be achieved between
Windows -based hosts and common peripheral devices.
Package Contents
The Microtune MT0760-CF30 USB "CableFree USB"
Kit should contain the following items:
•
MT0760-UD2P USB Slave Dongle with "A"
type connector
•
MT0760-UM2P USB Master Dongle with "B"
type connector and 5V power jack
•
PS5-USB-NA 5V Regulated Wall Adapter
North American Power Supply
•
C-USB-A/B Receptacle Adapter
The Microtune MT0760-CF100 USB "CableFree
USB" Kit should contain the following items:
•
MT0760-UD1P USB Slave Dongle with "A"
type connector
•
MT0760-UM1P USB Master Dongle with "B"
type connector and 5V power jack
•
PS5-USB-NA 5V Regulated Wall Adapter
North American Power Supply
•
C-USB-A/B Receptacle Adapter
Instructions
Installation
•
Connect the MT0760-UD1P/MT0760-
UD2P slave dongle to the PC at an
available USB port
•
Connect the MT0760-UM1P/MT0760-
UM2P master dongle to the peripheral's
USB port
•
Attach power supply to port on MT0760-
UM1P/MT0760-UM2P master dongle
and plug into wall socket
Usage
•
Use peripheral in accordance with usage
of a standard USB cable.
•
The MT0760-CF30 will allow wireless
connectivity up to a range of 30 feet, the
MT0760-CF100 will extend to 100 feet.
Microtune, Inc.
"CableFree USB" Kit
User Manual
MT0760-CF30 • MT0760-CF100
Patent Pending
USB Dongle Specifications
Standard
Frequency Range
Radio Type
Range
Data Throughput
USB Standard
USB Connector Type
USB Power Input Requirement
USB Master Power Output
Master Power Connector
Dongle Operation Indication
Dongle Temperature Range
Certification & Regulatory
Interoperability & USB Device
Conformance
DRAFT
Bluetooth Wireless Connection Specification
Class 2 (MT0760-CF30)
Class 1 (MT0760-CF100)
USB Connection Specifications
USB Male Type "A" (Slave)
USB Male Type "B" (Master)
5V (to Peripheral with use of PS)
Dongle General Specifications
(5V +/-5% External Supply Required)
Printers – Most HP, Cannon
Scanners – Most HP, Cannon
Cameras – PTP Conformance
Bluetooth version 1.1
2.400 to 2.4835 GHz
30 ft (MT0760-CF30)
100 ft (MT0760-CF100)
100 Kbps
USB version 1.1
5V (From Host or PS)
1.3mm Jack Connector
Green LED
-20 to +50C
USB1.1, BT1.1, FCC, CE
