Summary of Contents for ISC RP280
- Page 1 Solutions in Metal RP280 Rope Wrench climb. work. rescue. RP280 series: Issue B - March 2018...
- Page 2 Improper orientation of installation will cause the device not to function. Read and follow all of these instructions before using the device. Serial number.: Date of manufacture: RP280 series: Issue B - March 2018 RP280 series: Issue A - May 2015...
-
Page 3: Table Of Contents
Limb-Walking with the Rope Wrench Equipment Maintenance and Inspections Dynamic Inspections Post-Climb Inspections General Maintenance SRT and DdRT Standards Testing To view a translated copy of this manual scan this QR code Product Record or visit iscwales.com RP280 series: Issue B - March 2018... - Page 4 Pictoram Informing User To Read Instructions MBS - Minimum Breaking Strength [10] Manufacturers Identification Wheel [11] Part Number CE Logo Followed By Notified Body [12] Maximum Rope Diameter Number Responsible For Article 11B RP280 series: Issue B - March 2018...
- Page 5 Rubber Grommet Tether Label MMMYY climb. work. rescue. Serial # XXXX RT270XX Inspect Daily Use As Designed Store Properly MBS: 5,400lbs complies with ANSI Z133.3 Tether Combinations RP280XX RP280XX + RT270C1 RP280XX + RT270B1 RP280 series: Issue B - March 2018...
-
Page 6: Intent And Purpose
Wheel and the Slic Pin. The climbing rope may still pass through the Rope Wrench, but the Slic Pin and Wheel apply friction that slows it down. Fig 1b Fig 1a Engaged Gear Neutral Gear RP280 series: Issue B - March 2018... -
Page 7: Equipment Checklist
Tether Friction Hitch Pulley Karabiner Harness Attachment Climbing rope Point Note: Attach harness to end of karabiner. If desired, Ascenders could attach to the climbing rope above or below the system. RP280 series: Issue B - March 2018... -
Page 8: Equipment Requirements
Equipment Requirements Rope Wrench Always use the original Rope Wrench manufactured by ISC. Do not attempt to use a “home-made” Rope Wrench. Climbing Rope It is recommended that a 11mm to 13mm diameter, 16 or 24 strand rope made of nylon, polyester, polypropylene or kernmantle and that is approved for arboriculture be used with the Rope Wrench system. - Page 9 Be secured such that no loading or interference with the gate will occur. (The ISC HMS Karabiner is an example of an acceptable Karabiner). Harness The harness selected for use with the Rope Wrench system must be adjusted to best fit the climber’s body.
- Page 10 Always remember that the Rope Wrench is not a life support device and even a system using ascenders in conjunction with the Rope Wrench requires a properly tied and functioning friction hitch. Failure to do so can result in serious injuries or death. RP280 series: Issue B - March 2018...
-
Page 11: Standard Set-Up Instructions
This is particularly important if the climber intends to move from branch to branch within the tree. Failure to supply sufficient rope can result in serious injuries or death. RP280 series: Issue B - March 2018... -
Page 12: Rope Wrench Set-Up Instructions
2. Place the free end of the tether between the Side Plates at the Tether Attachment Point. 3. It is recommended that a reversible thread-locking fluid be applied to the bolt to prevent loosening. 4. Reinsert the bolt. 5. Make sure the bolt is screwed in all the way. RP280 series: Issue B - March 2018... - Page 13 Note: When installed correctly and pulled down, the Rope Wrench should bend the climbing rope into an S-shape. Step 3. Repeat Bounce Test. With the Rope Wrench installed, repeat the test described in Step 6 of the previous section. RP280 series: Issue B - March 2018...
-
Page 14: Climbing Using The Rope Wrench System
The friction from the engaged Rope Wrench and partially engaged friction hitch will allow the climber to descend at a smooth, controlled rate. At no point during descent does the Rope Wrench need to be touched. RP280 series: Issue B - March 2018... -
Page 15: Limb-Walking With The Rope Wrench
If the climber clips the tail of their climbing line through a pulley fixed to the working part of the line, the system can be converted from a 1:1 climbing system to a 3:1 climbing system. RP280 series: Issue B - March 2018... -
Page 16: Equipment Maintenance And Inspections
(or acceptable environment per the manufacturer’s specifications). Leaving a rope in adverse environment for longer than the time required to perform the necessary tree work could cause it to be invisbly weakened and should not be used. RP280 series: Issue B - March 2018... -
Page 17: Dynamic Inspections
[ S ]harp objects. Burrs and sharp edges in the system or in the tree can damage the rope and must be avoided. [ TREES ] Inspect all parts of the tree supporting any part of the body weight to ensure they are not cracking, creaking, or overly bent. RP280 series: Issue B - March 2018... -
Page 18: Post-Climb Inspections
The moving parts of the Rope Wrench may be oiled if desired. Wipe away any excess oil before use. Ensure the oil type will not degrade any rope used in the Rope Wrench System. RP280 series: Issue B - March 2018... -
Page 19: Srt And Ddrt
Test Report to confirm that the system is fully compliant with the relevant EN Standard. ISC are aware that the industry uses a huge variety of hitch combinations, and it is the hitch that dictates the effectiveness of the whole system. The Rope Wrench itself is not a fall arrest device, it is a friction management device. - Page 20 Page reserved for a copy of the SATRA test report RP280 series: Issue B - March 2018...
- Page 21 Product Record 1.Item 2.Date of first use 3.Year of manufacture 4.Purchased from 5.Purchased date 6.Name of Manufacturer, 7.Date of first use 8.Inspection date 9.Reason 10.Conform 11.Comments 12.Signature RP280 series: Issue B - March 2018...
- Page 22 Solutions in Metal International Safety Components Ltd. Unit 1, Plot 2 Llandygai Industrial Estate Bangor Gwynedd LL57 4YH United Kingdom T> +44 (0) 1248 363 125 F> +44 (0) 1248 363 118 sales@iscwales.com www.iscwales.com RP280 series: Issue B - March 2018...
