Subject: MTP Technical documentation
TECHNICAL DOCUMENTATION FOR USERS OF AIR HEATERS
MTP, MTPAL, MTP-V
Contents:
Page:
2
3
5
11
17
17
18
Approved by:
Warranty card
Certificate of product quality and completeness. (Unit test report)
Technical conditions
Installation, operating and maintenance instructions
Related documents
List of warranty and post-warranty repair services
Optional equipment
Warranty card
Do Žlábku 733, 514 01 Jilemnice
Page No./No. of pages:
1/20
Date: 12. 2. 2018
Advertisement
Table of Contents
Summary of Contents for Jinova MTP
-
Page 1: Warranty Card
Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 1/20 TECHNICAL DOCUMENTATION FOR USERS OF AIR HEATERS MTP, MTPAL, MTP-V Contents: Page: Warranty card Certificate of product quality and completeness. (Unit test report) Technical conditions... - Page 2 Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 2/20 The manufacturer is responsible for defects in the product that have been proven to be incurred in the warranty period by a faulty construction or faulty design.
- Page 3 TO BE FILLED IN BY A QUALIFIED WORKER OF THE ASSEMBLY COMPANY Ser. No.: TYPE: Compliance with all installation conditions according to this “MTP Technical documentation” has been checked. Installation instructions (installation, safety distances, connection of the air-conditioning circuit, smoke flue connection including condensate drainage, assembly of burner and electrical installation).
- Page 4 Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 4/20 Certificate of product quality and completeness Unit test report By this certificate the manufacturer confirms that the properties of the product, name: AIR HEATER type/design: MTP serial number: ..........
- Page 5 2. Function description The basis of the heaters MTP, MTPAL, MTP-V is a closed air-flue gas exchanger which consists of a combustion chamber and a tube heat exchanger. The air-conditioning and combustion circuit of the air heater are therefore separated. The heater heats the air conveyed by the fan that is or is not part of the heater (depending on the type).
- Page 6 According to the size, heat exchanger is made as a three-tier (up to MTP 400) and four-tier for larger sizes. The combustion chamber is reversing, for the heat exchangers of P1 and P2 type, it is a one-way chamber.
- Page 7 Page No./No. of pages: 7/20 The basis of the MTP-V heater is always the BK heat exchanger selected according to the required output; the required output is then the nominal output of the heater. The heat exchanger table is below. The heat exchanger may be extended or shortened according to the spatial disposition.
- Page 8 “Certificate of product quality and completeness” and on the nameplate. MTP air heaters can be equipped by the manufacturer with an electrical switchboard located on the heater or designed for a stand-alone installation that provides control of the burner, engine protection and start up and triple thermostat safety functions.
- Page 9 MTPAL can be equipped with a wide range of accessories such as e.g. blind shutters, filters, recuperators, cooling exchangers, elastic connections etc. that do not affect the function of the gas heater. Table of MTP technical parameters parameters/type max. output [KW] max.
- Page 10 Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 10/20 - the outdoor design with IP 43 electrical protection is designed for outdoor environment. The burner and the triple thermostat are provided with appropriate covers to protect these devices against atmospheric precipitation.
-
Page 11: Instructions For Installation
Brno, test room 202, Hudcova 56b, 621 00 Brno. Production tests These tests are carried out at production plant JINOVA s.r.o., Do Žlábku 733, Jilemnice on each produced heat exchanger unit. The following tests and checks are carried out in terms of production tests:... -
Page 12: Safety Distances
Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 12/20 For the outdoor design when placed on the roof of the building, the installation company is obliged to provide the heater with a lightning conductor in accordance with ČSN EN 62 305. -
Page 13: Condensate Drainage
Subject: MTP Technical documentation Page No./No. of pages: 13/20 The necessity for all designs of MTP heaters is to ensure condensate drainage from the chimney flue. Condensate drainage If the heater contains condensate drainage, it is advisable to ensure condensate drainage from the heater. -
Page 14: Operating Instructions
Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 14/20 Do not install any elements that make it difficult to dismantle the panel covering the tube plate cover. The ESD3J safety thermostat is not designed to regulate the required temperature. It is placed in the heated air behind the heat exchanger, in its upper part max. - Page 15 Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 15/20 T1 - safety - switches the burner off by disconnecting its supply voltage and it is blocked in its off state. To enable a new automatic start of the burner, it is necessary to press the button on the triple thermostat.
-
Page 16: Maintenance Instructions
Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 16/20 MAINTENANCE INSTRUCTIONS The maintenance of the heater is always carried out while it is out of service. Maintenance service must be in accordance with the operating instructions. -
Page 17: List Of Accessories And Spare Parts
Lubrication of fan bearings - applies only to some fans, e.g. fans with bearings for high temperatures (of ADH-RDH K / K2 type). Note: for MTP (MTPAL) standard sets, maintenance-free bearings with permanent grease filling are used. Defects: a) Overheating of heat exchanger, failure of safety thermostat T1 - check whether the suction and discharge spaces (piping, ...) are passable... -
Page 18: Related Documents
Final protocol No. 40-11101 SZU Brno LIST OF WARRANTY AND POST-WARRANTY REPAIR SERVICES Warranty and post-warranty service of MTP air heaters is provided by our company: JINOVA s.r.o. , Do Žlábku 733, 514 01 Jilemnice tel.: 481 541 518, 481 549 351, e-mail: servis@jinova.com In case of use of Weishaupt burners, the warranty and post-warranty service is provided by Weishaupt company;... -
Page 19: Optional Equipment
Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 19/20 Alternatively, they recommend one of the contractual mechanics from the immediate vicinity. OPTIONAL EQUIPMENT The air heater can be supplemented by additional, optional accessories, especially those stated below, according to the wishes and requirements of the customer. - Page 20 Do Žlábku 733, 514 01 Jilemnice Subject: MTP Technical documentation Page No./No. of pages: 20/20 environment are covered with grids, in units for outdoor use they can be complemented by weather-proof blinds. Valves with a small hole designed for connection of air-conditioning piping are, as a standard, supplied with an elastic cuff.
