Radiometrix TR2I-464-5-12.5K RF Module Implementation Guide
Purpose: This guide is intended as guidance document to ensure that the radio module
identified is installed implemented in an appropriate manner so as to comply with the conditions
of the original FCC grant and IC certificate.
Applicability: RF module FCC ID.: ITQ-TR2I, IC: 3598A-TR2I
Use of External Antennas: The module was certified for use with the following antennas.
These antennas or antennas of the same design but lower gain may be used in the final
installation.
Antenna Type
¼ Wave Whip
Final assembly antenna connection: The final assembly must have non-standard antenna
connection such as a reverse gender connector or means must be provided for permanent
connection of the antenna to the final assembly. A standard rf connector may not be used.
Final assembly labeling: The final assembly must contain a label notifying the user that the
device contains a certified rf module that is identified by the following product approval numbers:
FCC ID.: ITQ-TR2I
IC: 3598A-TR2I
An example of such a label is shown below.
Gain
Manufacturer's
(dBi)
P/N
0
EXC450SM
Manufacturer
Laird Technologies
Advertisement
Table of Contents
Summary of Contents for Radiometrix TR2I-464-5-12.5K
- Page 1 Radiometrix TR2I-464-5-12.5K RF Module Implementation Guide Purpose: This guide is intended as guidance document to ensure that the radio module identified is installed implemented in an appropriate manner so as to comply with the conditions of the original FCC grant and IC certificate.
- Page 2 The FCC and Industry Canada specific statements below will be modified for these products to indicate these distances. Any future uses of the TR2I-464-5-12.5K radio module in a product intended for use closer than 20 cm to the human body must be tested in that product configuration. These SAR test reports must be submitted as part of a Class II permissive change to the FCC and/or Industry Canada.
- Page 3 used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: ...
- Page 4 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. “Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s).
