SERVICE MANUAL Colour Television
Specifications
Power Source . . . . . . . . .AC220V, 50Hz / 60Hz
Receiving System . . . . . .PAL (M/M, N/N), NTSC (M/M)
Channel Coverage
Antenna mode VHF: CH02-CH13, UHF: CH14-CH69
CATV mode
VHF band: CH01-CH13, Mid band: CH14-CH22
Super band: CH23-CH36, Hyper band: CH37-CH64
Ultra band: CH65-CH94 and CH100-CH125
Low mid band: CH95-CH99
Video IF . . . . . . . . . . . . . 45.75MHz
Aerial Input Impedance . . 75Ω
Ext. Terminals
Video inputs: Phono jack
Audio inputs: Phono jack
Headphone Jack (Mono)
Sound Output (RMS) . . . . 2W
Speakers . . . . . . . . . . . 5 cm x 9 cm x 1 pc.
Dimensions . . . . . . . . . 380 (W)
Weight . . . . . . . . . . . . . approx. 8.7 Kg
Specifications subject to change without notice.
F3AT
2 (1Vp - p, 75Ω)
2 (436mVrms, more than 40KΩ)
1
356 (H)
383.5 (D)mm
Panoramic
FILE NO.
Model No. TVP-1405AM
Service Ref. No. TVP-1405AM-00
JXMRR
Product Code: 111325815
Original Version
Chassis Series: LA5-A
Give complete "SERVICE REF. NO." for parts
order or servicing. It is shown on the rating
plate at the cabinet back of the unit.
This T.V. receiver will not work properly in
foreign countries where the television trans-
mission system and power source differ from
the design specifications. Refer to the specifi-
cation table.
