- Page 1 Edition 2, From serial no. 105901- Publ. no 4870323-00 OM 4110, 2012-01 Orwak 4110 Orwak 4110 OPERATING INSTRUCTIONS (IN THE ORIGINAL)
-
Page 2: Table Of Contents
English CONTENTS SAFETY Please read the operating instructions BEFORE operating the machine. Safety ....Our Warranty and Product Responsibility require that: • instructions are followed, and that no conversion or modification is Transport ..carried out. Installation ..• original spare parts, and hydraulic oils, lubricants and containers Control panel .. -
Page 3: Transport
English SAFETY FEATURES The machine is equipped with the following safety features: A side limit switch to prevent the machine from being used when the press housing is moved. Guards and covers (incl. the correct container) protect the operator from moving parts of the machine. -
Page 4: Installation
English INSTALLATION Installation, repair and servicing must only be performed by qualified and competent personnel, and in accordance with the installation and servicing instructions. 1. Remove any packaging. 2. Position the machine in the designated place and ensure that it is standing on a level base and with adequate working space around it. - Page 5 English 4. Fit the handle (a), the side guards (b) and the covers (c). b MC6S M8x30 BRB 8,4 c MRX M5x16 4pcs M6M M5 5. Fit the four brackets, the four machine feet and the two floor rails. (The data plate shows the product number for the machine model.) Product No h=20...
- Page 6 English 6. Adjustment of machine feet and container indicator: (The machine feet are supplied separately with the machine to prevent damage during transport, and the container indicator is pre-adjusted at the factory for the intended container but may require fine adjustment for the correct container at the time of installation.) 7a) Adjust the machine feet so that an air gap of approx.
-
Page 7: Control Panel
English CONTROL PANEL Container in position Low press plate / – flashing indicates that the (up arrow) container is correctly positioned – flashes to indicate inside the machine after container that the press plate has replacement/emptying. If the descended with a container symbol flashes in the machine, or that the together with the “low... -
Page 8: Operating Instructions
If a container with a cover is used, the cover should face towards the operator during compacting. Compaction During the first press cycle after replacing/emptying the container, the lift table is raised automatically when the start button is activated. Replacing/emptying the container http://www.orwak.com/~/media/Movies/4110.ashx... -
Page 9: Specifications
English TECHNICAL DIMENSIONAL DRAWINGS SPECIFICATIONS (4904110-00) GENERAL DATA Total weight: ~550 kg 1362 Weight of press unit: 132 kg Transport height: 1900 mm Dimensions (660L): Height: 2459 mm Width: 1396 mm Depth:... -
Page 10: Weekly Inspection And Maintenance
English WEEKLY INSPECTION AND MAINTENANCE NOTE! During inspection and maintenance, service work and the removal of trapped waste, etc: 1. Disconnect the power to the machine by removing the plug from the wall socket. 2. Do not work under the press plate. SAFETY CHECKS - Check the container indicator: the machine must not be capable of starting without the correct container inside the machine. - Page 11 EC DECLARATION OF CONFORMITY AB ORWAK Box 58 S-576 22 Sävsjö, Sweden Tel: 46-382-15700 Fax: 46-382-10607 declare under our sole responsibility that the product model (serial number specified on the first page) 4904110-00 – 4904110-99 4904110-S001 – 4904110-S999 to which this declaration relates is in conformity with the following...
