3R system K Series User Manual

Series

Package Contents and Installation of the parts

Mainboard supporter - Use this only where required, and assemble
Paper Washer ‒ Use this with 3.5 screws and mainboard supporter
for electrical insulation.
Screw 3.5 - Use this to secure Mainboard and PSU.
* How to assemble the Screw: Be sure to
install the paper washer between
the Mainboard and the Screw(3.5 )
to prevent a short circuit.
Screw 3 - Use this to secure CD-ROM, FDD and various PCI slot
cards.
Screw(HDD) - Use this to secure HDD.
PC Speaker - This is installed in mainboard and calls
User Manual
using Paper Washer(Red Washer).
메인보드
the condition of the system.

How to connect cables

POWER LED : Refer to the manual and install it while obeying
+ +
POWER LED POWER LED
- -
HDD LED : Refer to the manual and install it while obeying
+ +
H.D.D LED H.D.D LED
- -
the polarities.
* In case of LED connector, the terminal with the ▲ mark is + .
POWER SW(Switch) : This switch has no polarity.
POWER SW POWER SW
RESET SW(Switch) : This switch has no polarity.
RESET RESET SW SW
USB AUDIO
▶ Specifications and improvements in the design of our PC case are subject
to change without any prior notice.
▶ *Warranty voids when damage is caused by user s abuse, misuse or
by a natural disaster.
*Warranty voids when damage is caused by modifying the product or
by using the product in improper application.
▶ For the detailed A/S and support, please visit our website.
(http://www.3rsys.com)
TEL : 82 2 2027 2555 Fax : 82 2 2027 2088
the polarities, If a 4-pin connector is supported,
then connect it to the power supply.
It doesn t matter which place you
connect this to the mainboard.
It doesn t matter which place you
connect this to the mainboard.
: Connect it to the terminals on the Mainboard.
e-mail : support@3rsys.com
