C R U Z B I K E S 4 0
G E T T I N G S T A R T E D
Thank you for choosing the Cruzbike S40! This frame is as versatile as it is beautiful.
The Cruzbike S40 is a recumbent bike frame designed to be built up as a fast road bike,
endurance bike, a sleek and sophisticated tourer or the ultimate commuter.
We recommend you and your mechanic work together to source a component set that
fits your cycling needs.
Note: If you are unsure about compatibility, a qualified bicycle mechanic will be able to
help you design a great build. You can also email support@cruzbike.com.
C R U Z B I K E S 4 0 R E S O U R C E S
Watch at www.cruzbike.com/s40
S 4 0 V I D E O S |
S40 Frame Assembly | S40 Complete Assembly | S40 Fit and Adjustment | S40 Features and Accessories
S 4 0 A S S E M B L Y A N D F I T N O T E S |
Q U E S T I O N S ? C A L L U S 8 8 8 - 2 2 6 - 2 7 8 9 O R E M A I L S U P P O R T @ C R U Z B I K E . C O M
See next page
E X A M P L E C O M P O N E N T S E T L I S T :
S 4 0 F A S T R O A D B I K E S E T U P
1-Handlebar: Included custom lightweight
wide grip handlebar for control, fast
climbing and knee clearance.
2-Shifters and Cassette: Road levers and
wide range cassette
3-Brakes: Road lever compatible disc brakes
160mm front and rear
4-Derailleur: Brand compatible long cage rear
derailleur, braze on front derailleur
5-Bottom Bracket and Cranks: 68mm English
thread, compact double
6-Wheels: 700c with disc brake hubs
7-Tires: 700c x 32c

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S40 and is the answer not in the manual?

Questions and answers

Summary of Contents for CRUZBIKE S40

  • Page 1 Thank you for choosing the Cruzbike S40! This frame is as versatile as it is beautiful. The Cruzbike S40 is a recumbent bike frame designed to be built up as a fast road bike, endurance bike, a sleek and sophisticated tourer or the ultimate commuter.
  • Page 2 Cruzbike sells a rear rack and an under seat rack that are designed to work perfectly with the S40 frame. If using another rack, use two 15 mm spacers to achieve the proper width for lower rack stays.
