iLyn SF-403EX Operation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Operation manual
Model: SF-403EX
Welcome
Thank you very much for the purchase of mini-compact digital audio
player iLyn.
iLyn digital audio player is not only designed and manufactured to fit our
company's quality standard and International Specification standard, but
also is manufactured after conducting strict quality-test.
We are certain that SF-403EX digital audio player, after being
manufactured through such procedures, will bring you a high satisfaction.
We truly appreciate your purchase of iLyn and we hope that you will
have great life with SF-403EX.
Since Sodiff E&T Co., Ltd. have the ownership of copyright of this
product, the use of this product's operation manual, pictures, software,
and other related documents will require permission to use from Sodiff
E&T Co., Ltd. Authorization and Commercial use without permission will
end up in legal punishment.
• The content of the operation manual and function of the
product can vary depending on the circumstances.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SF-403EX and is the answer not in the manual?

Questions and answers

Summary of Contents for iLyn SF-403EX

  • Page 1 Thank you very much for the purchase of mini-compact digital audio player iLyn. iLyn digital audio player is not only designed and manufactured to fit our company's quality standard and International Specification standard, but also is manufactured after conducting strict quality-test.
  • Page 2 Ⅰ. Getting ready 1. Welcome 2.Warning 3.Special features 4.Components check 5.Name of the components II. Connecting to your computer 1. Connecting to computer 2. Installing UMS driver to Windows 98 3. Using portable disk - file download, upload -disconnecting USB cable- Formatting 4.
  • Page 3 VII. Customer Service It is not broken Product features Quality Certificate □ Caution Please be cautious with following circumstances in order to use your player safely 1. Do not let it get shocked or impacted. This player will not have any trouble during walking and running, but being dropped or getting hit by heavy object will cause damage.
  • Page 4 7. Keeping your rechargeable lithium ion battery should take the cautions written below. - Battery functioning temperature: -40C ~ +80C - USB Recharging temperature: 0C ~ +45C - Usable period: -20C ~ +35C (More than 6 months) -20C ~ +45C (within a month) ※...
  • Page 5 -. Voice recording function With high quality WMA format, users can record maximum of 18:40 hour (256M, with 32 Bit-Rate standard). -. Various play modes One, RPT One, DIR One, RPT DIR, DIR Random, ALL One, RPT ALL, ALL Random RP, Intro, A-B section play -.
  • Page 6 -. Firmware Upgrade By Utilizing Firmware download function, this functions can be upgraded. -. Resume function to the unit of second When the power was turned off while playing, the song will automatically start from where it ended, when power is turned on. -.

  • Page 7: Usb Cable

    - You can buy or exchange your accessories that can be purchased at the iLyn customer's center. □ Names of each components...
  • Page 8 Recommended PC environment : - USB 1.1 supportable port - Over Pentium 133MHz - OS : Win 98SE/ME/2000/XP/MAC 9.2, 10.2 □ Connecting to the computer ※ If you have Windows 98 you need to install USB driver separately. Refer to "Installing UMS DRIVER to Windows 98" if you want more detailed install process.
  • Page 9 4. Ways to check connection of USB driver - Windows 98/ME : My computer(explorer) -> Control panel -> System -> device manager - Windows 2000 : My computer(explorer) -> Control panel -> System -> Hardware -> device manager - Windows XP : My computer(explorer) ->...
  • Page 10 3. Choose driver tap and start driver update 4. Choose list or specific location install. 5. Click 'Next' 6. Including the area of search : Input 클릭 C:₩windows₩inf. <* have 2000 C:₩winnt₩inf> 7. Searching 8. When everything completed, you can check large capacity hold device, as it is shown in the left picture.
  • Page 11 WIN98MASS.ZIP file from www.iLyn.co.kr archive. 1. From iLyn Explorer CD double-click the WIN98MASS folder and run SETUP file. - After you click OK button, the computer will be restarted and Window 98 Drivers installation will be finished.
  • Page 14 □ Portable Disk Usage - File Download and Upload 1. Connect MP3 Player's USB cable to the computer. 2. Open 'My Computer' or 'Windows Explorer'. 3. DRAG & DROP the file that you want to download to the portable disk. 4.
  • Page 15 1-2. Click on the message and click the "OK" button and disconnect your MP3 player from the computer. Second Way) Disconnect your MP3 player just as it is shown in the pictures below. □ Logo Convert Usage The image should be in 128x64 Pixel, 'Black and White Bit-Map'(.bmp) file.
  • Page 16 Click on the ILYNLOGO.BMP file that you created and click again on the edited Bit-Map file. Then, the chosen image will show up in the window. The display will show color file in color and black and white file in black and white. 3.
  • Page 17 　 □ Battery Charge 1. While the computer is on, connect the MP3 player to the USB plug. 2. While it is on charge, the blue LED on MP3 player will be turned on. When it is finished the LED will automatically turns off. - The charging time is three hours.
  • Page 18 - While playing, press jog button left/right for long to fast forward/reverse. If you moved to start or end of the track, the player will start the same track from the first. 　 Adjusting volume Press ╋ /━ button to adjust the volume from 0 to 40 level.
  • Page 19 1. S art recording : Press recording button ( ⊙ ) on Music mode or Voice mode to record and the player will automatically change to recording mode. 2. Pause recording : Press Play button ( ▶▶l l ) for short to pause recording.
  • Page 20 Press FM button for long to change to Line mode. 1. Connect the line in cable to the jack of the player. 2. Connect the line out cable to the jack of the external equipment (CDP, MD, Walkman, audio and etc) 3.
  • Page 21 2.Stop recording : Press record button ( ⊙ ) to stop recording Play button ( ▶▶l l ) will be on pause. - The method for starting record, pausing and stopping are same with recording voice. - It will be recorded as WMA file and saved as V001, V002 … in sequential order.
  • Page 22 S e a r c h m o d e ( A u t o m a t i c f r e q u e n c y f i n d a n d s a v e ) 1 .
  • Page 23 Ⅳ. Additional functions 　　 Setting up interval repeat A. If you press ⊙ button while playing music you will see ‘A-‘ mark on the top of the player LCD screen and that point will be the start of interval repeat. B.
  • Page 24 ▶ ▶ : Move to subordinate folder ╋ /━ : Navigate the file and folder within the same folder Play, ▶ ▶ : Play the selected file - While on pause or on play, press the job( ) button for while, then the menu will show up.
  • Page 25 MEMORY Memory capacity check CHECK File name, Language selection for the lyrics indication. LANGUAGE SVAE FONT : font upgrade LOGO Select user LOGO * extansion(.ALG) SELECT Encoding Setting 1. From menu select ‘2. REC SETUP’ 2. For Recording VOICE, LINE, FM, use +,- key in order to change to desire function and then select with jog( ) button.
  • Page 26 Play control setting 1. Select ‘3. PLAY CONTROL’ from the menu. 2. Press jog( ) button shortly after using +, - key to change EQ, SPEED, REPEAT to desired function. ※ It automatically goes into ‘PLAY CONTROL’ by pressing FM Button for a while during playing.
  • Page 27 Set Up Play Mode ONE(Play one track), RPT ONE(Repeat one track), DIR ONE(Play one folder), RPT DIR(Repeat folder), DIR RANDOM(Random folder play), ALL RANDOM(All Random Play), INTRO(Play first 10sec. Of the track) Delete/Formate File 1. Delete File : Delete file/folder and Delete All file 2.
  • Page 28 Setting Display 1. SETUP LCD (CONTRAST Set up and Time Set up) - CONTRAST(1~10), TIME(5.10.15.20.ON) - Select jog( ) button after using +,- key to set up. - ◀◀ key does not set up and moves to the previous step. 1.
  • Page 29 SAVE FONT: click on this when you want to upgrade the font. <Refer to page… in“advanced section” for Font Upgrade> User’s Logo setting DEFAULT : Basic iLyn picture USER: Choose, user-made, ILYNLOGO.ALG picture <Refer ‘Logo CONVERT section’ in page… for making user logo>...
  • Page 30 Firmware Upgrade consistently posted iLyn Homepage (www.ilyn.co.kr) How to upgrade the firmware: i . Download upgraded firmware from the homepage. ii. While MP3 Player and computer is connected through cable, download firmware upgrade file (iLynfirm.rom) the same way you did for downloading the songs.
  • Page 31 <Font File can be found on CD or iLyn Homepage> 2. Disconnect USB cable from MP3 Player, then go back to menu. 3. After choosing language, click on Save font, then it will upgrade the font. 　　 Mandatory Format 1. When Upgrading Firmware failed, put the hold on while the power is off.
  • Page 32 - No power: Battery trouble, recharge your battery. - Buttons won’t work: check Hold key and then disarm. - MP3 Files will not download/upload: Check the cable connection. - Not enough memory: delete unused files - Does not operate: First, press reset button, and then operate and when it still does not work, refer to ’Mandatory Format’.
  • Page 33 ◎. MP3,WMA File, Songs 128 MB 256 MB 512 MB 1 GB MP3 File Down songs songs songs songs WMA File Down 64 songs 128 songs 256 songs 512 songs 32 songs 64songs 128songs 256songs Rate- Line Recording 130songs 260songs 520songs 1040songs Rate-32...
  • Page 34 The guarantee period will be initiated from the day of the purchase, so make sure to have your date of your purchase written. Guarantee details 1. The compensation standard for equipment repair, exchange, refund follows “Customer protection and compensation law’ set by Economy Planning Committee.
  • Page 36 Distributor : Name of Company : Phone: customer service center: Tel : 82-31-940-6976 Fax : 82-31-940 - 6922 Address : Person in charge: customer service address Customer : Name : Address : [413-850] 678-7, Changmanli, Gwangtanmyun, Paju-si, Gyunggi-do Sodif E&T Co., Ltd. Home page http://www.ilyn.co.kr...
