INGEGNERIA DEI SISTEMI S.p.A.
DETECTOR DUO
USER MANUAL
Config.: DETECTOR DUO-PRCS-OUT-MN
DETECTOR
User manual
Pisa, 12/02/2010
- P RO/010/M1 Rev 4 -
Rev. 1.1
N°doc: MN/2009/028
DUO
SYSTEM –
Tot pag. N°. = 74

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DETECTOR DUO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for INGEGNERIA DEI SISTEMI S.p.A. DETECTOR DUO

  • Page 1 - P RO/010/M1 Rev 4 - INGEGNERIA DEI SISTEMI S.p.A. Rev. 1.1 N°doc: MN/2009/028 Config.: DETECTOR DUO-PRCS-OUT-MN DETECTOR DUO USER MANUAL DETECTOR SYSTEM – User manual Pisa, 12/02/2010 Tot pag. N°. = 74...
  • Page 2 KEY WORDS GEORADAR, DETECTOR DUO, ANTENNA S UMMARY This manual contains a complete description of the Detector Duo radar system, detailing the assembly procedure, the correct use of the data acquisition software, the work procedure and the general operating procedures of the system.
  • Page 3 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual DISCLAIMER IDS WILL NOT BE HELD RESPONSIBLE FOR THE CONSEQUENCES OF AN IMPROPER USE OF THE EQUIPM ENT AND/OR THE SOFTWARE. THIS SOFTWARE MAY INCLUDE AUTOMATED DATA PROCESSING AND ANALYSIS TOOLS.
  • Page 4 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual CONFORMITY TO EUROPEAN REGULATIONS The equipment conforms to the following requirements set by EC regulations, including subsequent modifications, and to the legis lation set...
  • Page 5 Wait until the equipment is totally dry before reconnecting the cables. The Detector Duo should be cleaned periodically using a damp cloth. Do not use solvents or abrasive detergents.
  • Page 6 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual BATTERIES REMOVAL INFORMATION Laptop Batteries: Manufacturer: PANASONIC Type: Li-ion Ni Characteristics: 10.65V 5.7Ah Removal instructions: 1. turn off the laptop; 2. open the drawer with the symbol of the batteries;...
  • Page 7 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual RECICLYING The crossed out wheeled bin symbol shown on the equipment indicates that the product must be recycled separately from other waste at the end of its useful life.
  • Page 8 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual WARRANTY CERTIFICATE CONDITIONS 1) IDS Ingegn eria d ei Sistemi S.p.A, hereinafter referred to as IDS, warrants hardware/so ftware products fo r a period of 12 months from the delivery date to the original customer;...
  • Page 9 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual IMPORTANT NOTE FOR THE US CUS TOMERS FCC ID: UFW-DETDUO-FW This device complies with part 15 of the FCC Rules: Operation is subject to the following conditions: 1.

  • Page 10: Table Of Contents

    2.2 Background knowledge required................16 3. Use r guide ........................17 3.1 Description of the hardware ...................17 3.1.1 The Detector Duo Control Unit ............... 18 3.1.2 The antenna box................... 21 3.1.3 Power supply....................21 3.1.3.1 Charge level and battery replacem ent ............22 4.
  • Page 11 Appendix B - The te chnical maps ..................73 Appendix C - Opening manholes ..................74 FIGURES INDEX FIG. 3.1 – OVERVIEW OF THE DETECTOR DUO AND ITS COMPONENTS....... 17 FIG. 3.2 – THE CONTROL UNIT..................... 18 FIG. 3.3 – THE ANTENNA-CONTROL UNIT CONNECTION CABLE ......... 18 FIG.
  • Page 12 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual FIG. 5.11 – INITIALIZING WINDOW ..................42 FIG. 5.12 – GAIN CALIBRATION UNDERWAY............... 43 FIG. 5.13 –ADVANCED SETTINGS WINDOW ................. 44 FIG. 5.14 –ACQUISITION SELECTION WINDOW ..............46 FIG.

  • Page 13: Introduction

    N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 1. INTRODUCTION The Detector Duo is an innovative system capable of detecting tubes and both metallic and non metallic cables buried underground. Following standard radar principles, the Detector Duo uses a high performance electromagnetic sensor equipped with e.m.

  • Page 14: Scope

    Professional. For details on the required characteristics of the notebook PC, see Paragraph 5.1. From an operative point of view, the Detector Duo can perfectly adapt to all applications for pipe and cable detection in a typical roadworks environment, both over smooth and rough ground.
  • Page 15 Transmitter: part of the antenna dedicated to emitting the radar signals. It is lodged in the same container as the receiver. Utilities: the objects the Detector Duo searches for, i.e. pipes supplying gas and water, electricity cables, etc. All information contained in this document is property of IDS. All rights reserved...

  • Page 16: Overview

    N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 2. OVERVIEW 2.1 How to use this manual This Detector Duo user manual is subdivided as follows: • Chap. 1: Introduction. • Chap. 2: Overview. • Chap. 3: User guide.

  • Page 17: User Guide

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 3. USER GUIDE 3.1 Description of the hardware The Detector consists of the following parts (see Fig. 3.1): • DAD DECT DUO Control unit(1).

  • Page 18: The Detector Duo Control Unit

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 3.1.1 The Detector Duo Control Unit The control unit has the following main functions: To communicate with the antenna. To communicate with the notebook computer.

  • Page 19: Fig. 3.4 – The Inverted Network Cable

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Network port (2): a inverted network cable (Fig. 3.4) connects the control unit to the notebook PC. This port is marked LAN. Fig. 3.4 – The inve rte d network cable Power supply port (1): this connects the battery to the Control Unit using the power supply cable (Fig.

  • Page 20: Tab. 3.1 – Control Unit Characteristics

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 3.6 – Battery cable connection for the note book PC and the DAD, switch on button (re d) Press the red button to switch on the DAD control unit (Fig. 3.6). This button has to be kept pressed until the blue on switch lights up.

  • Page 21: The Antenna Box

    N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 3.1.2 The antenna box The detector duo system can be used with the box containing two antennas, one with a frequency of 700MHz and the other with 250 MHz (see Fig. 3.7): Fig.

  • Page 22: Charge Level And Battery Replacem Ent

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 3.1.3.1 Charge level and battery replacement When the spy light is lit next to the power supply port on the radar, this indicates that the system is powered: if it is not lit, this means that either the cable is not connected correctly or that the battery is flat (less than 10V).

  • Page 23: Assembly Proce Dure

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 4. ASSEMBLY PROCEDURE 4.1 How to assemble the trolley Follow the procedure below to assemble the trolley: Remove the trolley from its bag (Fig. 4.1).

  • Page 24: Fig. 4.2 – Opening The Trolley

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual PINS SUPPORTS Fig. 4.2 – Opening the trolle y Unlock the two unblocking levers by rotating them outwards (2 and 3) and pull the handle (4) upwards (1), regulating it as required (Fig.

  • Page 25: Connecting The Cables

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 4.2 Connecting the cables 4.2.1 Connecting the battery BASE PLATE IN PVC Fig. 4.4 – Battery and cabling support Place the battery in its yellow bag (Fig. 4.4).

  • Page 26: Fig. 4.5 – Fixing The Antenna Box

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 4.5 – Fixing the antenna box ANT.1 Fig. 4.6 –Antenna-radar conne ction Under the battery plate you can find the antenna-trolley locking system (see Fig.

  • Page 27: Mounting The Pc Notebook And The Sunshade

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Lockin g system Lever Fig. 4.7 – Trolle y-antenna locking system 4.2.3 Mounting the PC notebook and the sunshade The upper base plate on the trolley(2) is used to fix the notebook PC (1) with four Velcro strips (A, B, C, D), as shown in Fig.

  • Page 28: Fig. 4.9 – Assembling The Sunshade

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual A sunshade can be applied to the notebook (see Fig. 4.9). Fix the lateral guides of the sunshade to the lateral sides of the notebook screen.

  • Page 29: Connecting The Position Sensor

    The system position sensor is situated inside one of the trolley wheels and turns in unison with it (Fig. 4.11). The sensor measures all movements of the Detector Duo from its starting point, which coincides with the system centerpoint (which is the center of the antenna).

  • Page 30: Fig. 4.12 – Removing The Trolley Wheels

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 4.12 – Removing the trolley wheels Remember to disconnect all the cables before putting the trolley back into its storage bag (posit ion sensor cable, antenna-DAD cable, netw ork and pow er supply cable).

  • Page 31: The Acquisition Software

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 5. THE ACQUISIT ION SOFTWARE 5.1 The Notebook Computer DETECTORDUO Notebook acquisit ion SW is installed on a Computer. This SW is dedicated to the specific phases of setting up, acquiring and saving radar data.

  • Page 32: Fig. 5.1 – Hammerhead Rugged Tablet Pc

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.1 – Hamme rhead rugge d table t PC Audio • AC97 2.1 sound standard • Integrated speaker Expansion / Integration •...
  • Page 33 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual storage. Store batteries in a cool, dry p lace. Do not leave batteries in d irect sunlight during the summer months or any other unusually hot location. Do not expose b attery terminals to metal objects or moisture, w hich may short- circuit your battery.

  • Page 34: Panasonic Toughbook Rugged Tablet Pc

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual • Low Voltage D irective 73/23/EEC, EN 60950, CE Warranty • 1 year comprehensive w arranty 5.1.2 Panasonic Toughbook rugged tablet PC The Panasonic Toughbook CF-19 PC (Fig. 5.2), has the follow ing characteristics: •...

  • Page 35: Basic Characteristics Of The Notebook Pc

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.2 – Panasonic Toughbook CF-19 No communication softw are of the type Firew all, WiF i or Ant iv irus protection may be installed on the computer;...

  • Page 36: Software Installation And Configuration

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 5.3 Software installation and configuration Launch the icon of DetectorDuo setup file (Fig. 5.3). Fig. 5.3 – De te ctor Duo se tup icon Click “Next”...

  • Page 37: Fig. 5.5 – Setup Type Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.5 – Setup type window Fig. 5.6 – Pre -installation window All information contained in this document is property of IDS. All rights reserved...

  • Page 38: Fig. 5.7 – Installation Completed Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.7 – Installation complete d window DetectorDuo.exe Automat ically a shortcut of the w ill be created on to desktop. The softw are w ill be...

  • Page 39: Fig. 5.8 – Selecting The Ethernet Card (Tcp/Ip)

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.8 – Selecting the Ethe rnet card (TCP/IP) Internet Protocol (TCP/IP) from the list of components Select (in the general menu) w ith the left mouse button (see Fig. 5.8).

  • Page 40: Fig. 5.9 – Changing The Ip Address

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.9 – Changing the IP address To guarantee the correct functioning of the DetectorDuo Regional and Language Options SW, launch the icon on...

  • Page 41: The Operational Phases

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 5.4 The operational phases 5.4.1 Running the software The DetectorDuo softw are permits data to be acquired, saved and view ed d irectly in the f ield. Once the notebook h as been sw itched on, DetectorDuo.exe...

  • Page 42: Pre-Acquisition Commands

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.11 – Initializing window 5.4.2 Pre-acquisition commands Pressing the button activates the calibrat ion procedure of the processing parameters used on the acquired data.

  • Page 43: Fig. 5.12 – Gain Calibration Underway

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual UPPER GREY Fig. 5.12 – Gain calibration unde rway By pressing the button, you can avo id p erforming the gain calculat ions, but in this w ay you can only view pre- existing radar maps.

  • Page 44: Fig. 5.13 –Advanced Settings Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual You can zoom in on the maps up to a magnification of 4 by selecting one of these buttons Press the button to shut dow n the softw are, then...
  • Page 45 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Wheel setting here you can set the acquisit ion mode of the system, w hich can be either Wheel driven field selected, in th is mode, the radar acquisition is set using the position sensor b.

  • Page 46: Commands Used During Acquisition

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 5.4.3 Commands used during acquisition Data acquisition is started using the w indow show n in Fig. 5.14. Fig. 5.14 –ACQ UISITIO N SELEC TIO N window...

  • Page 47: Fig. 5.15 –New Acquisition Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.15 –NEW ACQ UISITIO N window Once a name has been given to a new survey, a file is automatically created w ith the selected name in the...

  • Page 48: Acquisition For On-Site Detection

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual At this point you have tw o options: perform radar scans w ithout setting reference coordinates simply to locally ident ify any bur ied ut ilit ies on- site;...

  • Page 49: Fig. 5.16 – Radar Map During The Acquisition Phase

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.16 – Radar map during the acquisition phase During the acquisit ion, the user can also change the contrast value in real tim e, through the function edit ing the number in the side textbox, as show n in Fig.

  • Page 50: Fig. 5.17 – Identifying A Target

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual RADAR ANO MALY Fig. 5.17 – Identifying a target This vertical lin e perm its you to pos ition the tro lley on the ax is...

  • Page 51: Fig. 5.19 –Up/Down Functions

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Use the buttons to position the horizontal cursor on the peak of the chosen hyperbola (see Fig. 5.19). HO RIZO NTAL CURSOR Fig. 5.19 –UP/DOWN functions In particular, during the acquisit ion phase, both the radar maps can be view ed (Fig.

  • Page 52: Fig. 5.20 –Dual Display During Acquisition

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.20 –DUAL display during acquisition button permits the typ e of p ipe and its posit ion to b e marked on the chosen point of the radar map. The w indow show n in Fig.

  • Page 53: Acquisition For Mapping

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.21 – Icons for types of pipes and cables By pressing the button, you can remove a previously selected marker. The system can’t identify the types of pip e or cable. Th is information can be found from other sources, such as opening manho le covers or consulting technical maps.

  • Page 54: Fig. 5.22 – Diagram Of The T-L Cartesian Reference System

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Transverse L -Axis Scan REFERENCE GRID Longitudinal Scan Origin 0 - 0 T axis Fig. 5.22 – Diagram of the T-L carte sian refe rence system •...
  • Page 55 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual • Longitud inal; • 2 in the Coord value field; • 2 in the Coord. Step field. Once the scan is finished, the coordinate of the L value is automatically posit ioned on the value 4.

  • Page 56: Fig. 5.23 –Acquisition Parameters Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual VIRT UAL KEYBOARD Fig. 5.23 –Acquisition parame ters window There are three boxes in a grey bar above the acquired radar maps (Fig. 5.16) (see below ) these show the follow ing...

  • Page 57: Depth Calibration

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 5.4.4 Depth calibration Pressing the button produces a box w here you can w rite the exact depth of the pipe or cable if it know n from...

  • Page 58: Post-Acquisition Commands

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual In both cases, you have to select one of the icons show n in Fig. 5.21 to confirm the depth of the identified p ipe. This...

  • Page 59: Fig. 5.24 – Deleting A Survey

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Any of the surveys saved on the computer can be deleted by pressing the button; select the survey name and press the delete button, the softw are requests you to confirm your choice (Fig.

  • Page 60: Fig. 5.25 – How To Rename A Survey

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.25 – How to rename a survey By pressing the button, the last survey can be reloaded so as to continue performing further scans in it.

  • Page 61: Fig. 5.26 – Insertion Of A Marker During The Review Phase

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual CIRCLE VERTICAL LINE Fig. 5.26 – Insertion of a Marker during the re vie w phase Further hyperbolas can be selected or previously inserted information can be reloaded using th e mouse or the buttons on the low er tool bar.

  • Page 62: Fig. 5.27 – Print Function

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual the low er tool bar can also be used to select and reload: • previous scans by selecting the button, • subsequent scans by pressing the button.

  • Page 63: Fig. 5.28 – Final Printout Of A Radar Map

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 5.28 – Final printout of a radar map press the button to close the program. The w indow show n in Fig. 5.29 reminds you to disconnect the pow er supply cable from the Control Un it to avo id w asting battery charge.

  • Page 64: Error Messages

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 5.5 Error messages Error messages found in the program are listed below (in it alics) follow ed by their solutions: Network error. Retry or check hardware! Check that the netw ork cable is connected properly to the PC and the Detector Control Unit.

  • Page 65: Work Proce Dure Flowchart

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 6. WORK PROCEDURE FLOWCHART TECHNICAL MAPS INSPECTION OPEN PRINT MANHOLES REVIEW ACQUIRED MAPS ASSEMBLE (SHALOW/DEEP) DET ECT OR EST IMATE PROPAGAT ION SWIT CH ON...

  • Page 66: How To Use The Detector

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 7. HOW TO USE THE DETECTOR The main targets w hen performing ut ilities invest igat ions w ith the DetectorDuo consist of either extended structures (such as an interface betw een layers, pipes parallel to the invest igat ion d irection etc.) or...
  • Page 67 IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual As the propagation speed in the med ium increases ( ), the ratio betw een the flight t ime of the outw ards and return signal relat ive to echoes originat ing from lateral points and the relat ing to the top surface of the target decreases.

  • Page 68: Fig. 7.3 – Example Of Map Interpretation

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual As can be seen in Fig. 7.2, the echo of a target do esn’t simple consist of a single dark band, it consists of alternate dark and light bands.

  • Page 69: On Line Assistance

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual 8. ON LINE ASSISTANCE 8.1 Remote assistance using Webex Support Center Webex Support Cent er is a service that allow s the activation of a tw o host session, making an applicat ion, or the desktop availab le to the other user or letting you capture another remote desktop.

  • Page 70: Fig. 8.2 – Client Data Insertion Form

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 8.2 – Client data inse rtion form Submit, Once you have clicked the follow ing page w ill appear show ing a dow nloading b ar. The session starts as soon as the dow nload is complete.

  • Page 71: Fig. 8.4 – Welcome To Webex Support Center Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 8.4 – Welcome to We bex Support Center window At this point, IDS Customer Care can perform a range of operations on your desktop: •...

  • Page 72: Fig. 8.5 – Command Acceptance Window

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual Fig. 8.5 – Command acce ptance window All information contained in this document is property of IDS. All rights reserved...

  • Page 73: Appendix A - The Preliminary Inve Stigation

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual APPENDIX A - THE PRELIMINARY INVEST IGAT ION The first fundamental phase for any field survey consists in the prelimin ary inv estigat ion : its scope is to acquire all the necessary information for the log istics of the operation, taking into account the objectives to be performed.

  • Page 74: Appendix C - Opening Manholes

    IDS Ingegneria Dei Sistemi S.p.A. N doc: MN/2009/028 - Rev. 1.1 DETECTOR DUO SYSTEM – User manual The most important types of utilities (w hich may be managed by different agencies) to be considered are: Public Street Light ing Low , Medium and High Vo ltage Electricity Cab les...
