Congratulations on your purchase of an Orion telescope. Your new Observer II 70mm Altazimuth
Refractor is a terrific starter instrument for exploring the exotic wonders of the night sky. Designed to be
compact and easy to use, it will provide many hours of enjoyment for the whole family.
If you have never owned a telescope before, we would like to welcome you to amateur astronomy. Take
some time to familiarize yourself with the night sky. Learn to recognize the patterns of stars in the major
constellations. With a little practice, a little patience, and a reasonably dark sky away from city lights,
you'll find your telescope to be a never-ending source of wonder, exploration, and relaxation.
These instructions will help you set up, properly use, and care for your telescope. Please read them over
thoroughly before getting started.

Table of Contents

1. Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
2. Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
3. Preparing the Telescope for Operation . . . . . . . . . .5
4. Astronomical Observing. . . . . . . . . . . . . . . . . . . . . .6
5. Worthwhile Optional Accessories . . . . . . . . . . . . . .9
6. Telescope Care and Maintenance . . . . . . . . . . . . . .9
7. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
WARNING: Never look directly at the Sun through
your telescope-even for an instant-without a
professionally made solar filter that completely
covers the front of the instrument, or permanent
eye damage could result. Young children should
use this telescope only with adult supervision.
2

1. Parts List

Part
A - Tripod leg
B - Yoke mount
C - Hex head tripod mounting bolt (3"),
with 5/8" washer and wing nut
D - Leg lock thumbscrews
E - Accessory tray
F - Screw with 3/8" washer and wingnut
G - Optical tube
H - Yoke knob
I - Altitude micro-motion rod
J - Micro-motion rod anchor screw
K - Red dot finder scope
L - Mirror star diagonal
M - 25mm Kellner eyepiece
N - 10mm Kellner eyepiece
O - Screwdriver tool
P - Dust cover
Qty
3
1
3
3
1
3
1
2
1
1
1
1
1
1
1
1
