   Summary of Contents for Asus WiCast EW2000

  • Page 2 User Manual Model No.:EW2000 Model name: WHDI transmitter module Version: v0.1 Date: July-12, 2010...
  • Page 3 20cm between the radiator & your body.    This module is intended for OEM integrator only and limited to host with ASUS WiCast model: EW2000; EW2000TX. The OEM integrator is still responsible for the FCC compliance requirement of the end product, which integrates this module. ...
  • Page 4: Table Of Contents

    This Class [B] digital apparatus complies with Canadian ICES-003.  Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada. Contents Revision History ....................3 Related Documents ....................3 Overview ....................... 4 3.1. Scope ......................4 3.2.
  • Page 5: Overview

    Overview 3.1. Scope The EW2000 wireless transmitter module, together with the EW2000 wireless receiver module, presents the ultimate solution for converting any High Definition (HD) system into a wireless one. This add-on module enables wireless A/V applications that easily fit into the living room and eliminate traditional A/V wiring.
  • Page 6: Specification

    3.3. Specification Interface Digital Video:30-bit RGB or YCrCb Digital audio: I2S and SPDIF Two-Wire serial bus slave interface One interrupt line Network Standard 5GHz unlicensed band Modulation OFDM Technique Proprietary 5.18GHz to 5.875GHz Operating Frequency Operating Channels USA/Canada: 36/40/44/48/149/153/157/161/165 Japan: 36/40/44/48 EU/AUS/NZ: 36/40/44/48 RF Output Power Antenna...
  • Page 7: Mechanical Characteristics

    3.4. Mechanical Characteristics...
  • Page 8: Module Function Block Diagram

    3.5. Module function Block Diagram 3.6. RoHS Compliant HM510 is fully compliant to RoHS requirement. 3.7. EMI EMC certifications HM510 is fully compliant with FCC regulatory requirements.
  • Page 9: Engineering Sheets

    4. Engineering sheets Pins Out and Pin Descriptions : WHDI_DCLK WHDI_H_SYNC WHDI_V_SYNC WHDI_DE WHDI_D34 WHDI_D35 WHDI_D32 WHDI_D33 WHDI_D30 WHDI_D31 WHDI_D28 WHDI_D29 WHDI_D26 WHDI_D27 WHDI_D22 WHDI_D23 WHDI_D20 WHDI_D21 WHDI_D18 WHDI_D19 WHDI_D16 WHDI_D17 WHDI_APP_DEBUG1_D14 WHDI_APP_DEBUG2_D15 WHDI_D10 WHDI_D11 WHDI_D8 WHDI_D9 WHDI_D6 WHDI_D7 WHDI_D4 WHDI_D5 WHDI_D2 WHDI_D3...
  • Page 10 WHDI_M_SDA WHDI_RESET_IN WHDI_INT_OUT_PE WHDI_HDMI_RESET_OUT WHDI_HDMI_INT_IN WHDI_GPIO0 WHDI_PWM0 WHDI_GPIO1 WHDI_PWM1 WHDI_GPIO2...
