- Page 1 JD60-7-TB-US Wireless Cellular Repeater User’s Manual...
-
Page 2: Table Of Contents
User Manual Wireless Cellular Repeater SAFETY WARNINGS ..............................3 WHY REPEATER................................4 2.1. 1 .................................4 EASON 2.2. 2 .................................4 EASON INTRODUCTION................................6 SYSTEM CHARACTERISTICS ............................7 4.1. ：................................7 EATURES 4.2......................7 PPEARANCE OF THE TRIPLE BAND REPEATERS BLOCK DIAGRAM AND WORK PRINCIPLE........................8 THE REPEATER SYSTEM .............................9 THE TRIPLE BAND REPEATER MAIN TECHNICAL SPECIFICATION..............10 7.1. -
Page 3: Safety Warnings
Wireless Cellular Repeater Preface This user’s manual describes the installation, commissioning and maintenance of JD60-7-TB-US Wireless Cellular Repeater. Please do read the user manual carefully before installing and maintaining the triple band repeater. The information in this manual is subject to change without prior notice Opinions are welcomed about the manual improvement. -
Page 4: Why Repeater
User Manual Wireless Cellular Repeater 2. Why repeater 2.1. Reason 1 1) Blind or weak signal areas are formed if the buildings are too far away from BTS, or the buildings themselves shield or absorb the signals. 2) There are too many complicated signals in the higher part of the buildings, therefore ping-pong switching effect has been formed and the signals fluctuate a lot, there are annoying noises during phone calls and there are dropped phone calls accordingly. - Page 5 The maximum power level of JD60-7-TB-US is 0.01~0.1W, and it decreases to be maximum 0.003W when reaching server antenna. And since the server antenna is installed over the ceiling or onto the wall, there are usually more than 3 meter away from the human body, 3meter away means at least 40dB propagation loss, or 10000 times less, 0.0000003W, therefore it is too weak to influence human bodies though it is still a very good...
-
Page 6: Introduction
5D-FB cable to a JD60-7-TB-US repeater to be amplified significantly, then the output signals are divided into three signals by a 8dB coupler and a 2way splitter, sent to three indoor omni antennas and finally transmitted into the coverage area. -
Page 7: System Characteristics
User Manual Wireless Cellular Repeater 4. System Characteristics 4.1. Features： CE Certified Streamline shape Excellent out of band rejection. Wide power supply range and low power consumption High-integration (One board to contain low-noise amplifier, band pass filter, power amplifier module, both uplink and downlink one for all) Wide band repeater to support all signals within three systems. -
Page 8: Block Diagram And Work Principle
User Manual Wireless Cellular Repeater 5. Block diagram and work principle The triple band repeater is a bi-directional repeater that consists of three mobile systems, the three systems are combined together by a combiner, and each system gets their independent uplink and downlink power amplifying system, and each link consists of duplexer, LNA, Filter and PA. -
Page 9: The Repeater System
User Manual Wireless Cellular Repeater 6. The repeater system Donor Antenna： 5~7dbi outdoor panel or 7~9dBi wide band Yagi are recommended as donor antenna. Function: Pick up donor signals from the BTS and send to the repeater by cable; the received signals’... -
Page 10: The Triple Band Repeater Main Technical Specification
User Manual Wireless Cellular Repeater Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for uncontrolled environment .This equipment should be installed and operated with minimum distance 400cm between the radiator&... -
Page 11: Rf Technical Specification
User Manual Wireless Cellular Repeater 7.3. RF technical specification NO： Uplink Test Project Test Condition Index Require 824～849MHz（GSM/CDMA） Frequency Range 1850～1910MHz（PCS/CDMA） 1710～1755MHz（AWS） GSM/CDMA：25MHz, PCS/CDMA：60MHz, AWS： Band Width 45MHz Max .Gain Testing in working band(without control) 63±1dB ALC Output Center frequency（deep control 10dB） 10±10dBm Center frequency(deep control 1～20dB) |△|≤2.0dB... -
Page 12: Requirements For Adapters
User Manual Wireless Cellular Repeater GSM/CDMA：25MHz, PCS/CDMA：60MHz, AWS： Band Width 45MHz Max .Gain Testing in working band(without control) 67±1dB ALC Output Center frequency（deep control 10dB） 15±10dBm Center frequency, deep control 1～20dB |△|≤2.0dB deep control 1～5dB Orange Center frequency deep control 15～20dB red and shut off CDMA ≤8dB... -
Page 13: Repeater Model List
User Manual Wireless Cellular Repeater 7.5. Repeater Model List MODEL NO：JD60-7-TB-US -GDW Device Type System code Power rating Device Type F: Wide band consumer repeater 10: downlink output power is 10dBm Power rating 15: downlink output power is 15dBm 20: downlink output power is 20dBm... -
Page 14: Installation
User Manual Wireless Cellular Repeater 8. Installation The triple band repeater micro repeater should be used to cover the area indoor and the humidity and temperature of working can affect the reliability of repeater. So, temperature, humidity, dust, interference, power, space requirements and other factors should be considered during installation of repeater. - Page 15 User Manual Wireless Cellular Repeater recommended the donor antenna to be installed in an attic. Testing the signal strength received from donor antenna mounted in site by mobile phone: Please select the top of the building to install the donor antenna if the total floors are less than 7, and must select a place like balcony or platform lower than 7th floor for the donor antenna if the buildings are over 7 floors.
- Page 16 User Manual Wireless Cellular Repeater following objects. Metal High-voltage line RF antenna High-voltage transformer Repeater is a two-way signal amplifier. So proper isolation between donor antenna and server antenna is necessary in order to avoid self-oscillation. About the definition for self-oscillation, take MIC and loudspeaker for example;...
- Page 17 User Manual Wireless Cellular Repeater Installation of panel antenna as donor antenna Installation of wide directional antenna as donor antenna Installation of YAGI antenna as donor antenna - 17 -...
-
Page 18: Indoor Antenna Installation
User Manual Wireless Cellular Repeater Test the call quality of donor antenna Lightening Test Engineer Phone Fix the donor antenna after selecting the best position, and adjust slightly its height or angles in order to get the signals with suitable input power level and calling Quality System Requirement of GSM or DCS The total input power level shall be around -50dBm, lowest shall be more than –80dBm Test by mobile phone or data card by 3~5 times to make sure the calling quality is good... -
Page 19: Repeater Installation
User Manual Wireless Cellular Repeater It is better to use a directional panel antenna or Yagi when the coverage shape is long and narrow (corridors, long row of houses in two sides, tunnels or elevators or rural open space) 8.6 Repeater Installation 8.7.1. - Page 20 User Manual Wireless Cellular Repeater After installing the repeater as described as above, power on the repeater to check the operation status. - 20 -...
-
Page 21: Repeater's Ports Description
User Manual Wireless Cellular Repeater 8.7.2. Repeater’s ports description Outdoor port: connected with the donor antenna by cable Indoor port: connected with server antenna directly or by cable DC IN: connected with power supply. Outdoor port: Connect the Donor Antenna Indoor port: Connect the Sever Antenna Grounding... -
Page 22: Repeater Settings
User Manual Wireless Cellular Repeater 8.8. Repeater Settings Please check very carefully all cable connections are correct and firm before running operation test and then carry out following tests 8.8.1. Switch on power After power is on, check firstly the alarm and power LEDs. Status and definition of POWER indicators: Status Definition... -
Page 23: Manual Gain Control (Mgc)
User Manual Wireless Cellular Repeater 8.8.2. Manual Gain Control (MGC) DIP Switch attenuation Downlink attenuation Uplink attenuation Note: GSM as example, the rest two system is the same as GSM. DIP switch uplink attenuation setting: Att. Att. 0 dB off 11dB off 22dB off 1 dB off 12dB off... -
Page 24: Gsm & Dcs Band Settings
User Manual Wireless Cellular Repeater 8.8.3. GSM & DCS Band Settings The curve about device working status Output Power Critical stable point input Power linear Green LED Equipment Red LED Orange LED amplification area overload zone Stable work area Output power, input signal and their attenuation curve Output Power Output Power: Input Power... -
Page 25: Wcdma Band Settings
User Manual Wireless Cellular Repeater “edge point” of green and intention of turning orange during engineering. Setting of “edge point”: Switch on the power supply after connection with donor antenna and server antenna, and observe ALARM LED. If it shines “orange”, use 1dB as step to reduce the gain until “green” turns on, then increase the gain 1~3dB attenuation value until “orange”... - Page 26 User Manual Wireless Cellular Repeater =20W*20%=4W=36 dBm node B The effective downlink path loss is as follows: =36- P D-link donor Budgeting Maximum Uplink Low Noise Power Output at Donor Port of Repeater Therefore the repeater UL gain shall be G ≤L –NF , (NF is the repeater Uplink Noise figure) D-link...
-
Page 27: Adjusting System Isolation
User Manual Wireless Cellular Repeater “G +8dB” explanation: The downlink gain can be maximum 8dB higher than uplink noise gain in indoor repeater solutions D. The attenuation should be less than 30 dB when you set the downlink gain of the repeater and it would be the best to attenuate less than 15dB range, and in case more than 15dB attenuation is needed, please use external attenuator. -
Page 28: Detecting Repeater
User Manual Wireless Cellular Repeater c) Tune the azimuth of the transmitting antenna d) Tune the down tilt of the transmitting antenna e) Add isolation net at the back of the antenna 8.8.6. Detecting Repeater When you cannot find the reason why the receiving or transmitting channel is abnormal, you can use a source-scanning spectrum analyzer to detect the repeater. -
Page 29: Repeater Can Not Communicate In Power-On Status
User Manual Wireless Cellular Repeater Test coverage 1) Mobility Service antenna 2) increase the number of service Check the signal antenna strength is fit 3) reduce the attenuation values 4) increase the output power 1) Mobility Service antenna 2) increase the number of service Check call quality antenna 3) reduce the attenuation values... - Page 30 User Manual Wireless Cellular Repeater meters. The following measures can also be tried: Use the roof of the building to enlarge the isolation (Please try to place the donor antenna and server antenna in different floors) Use some obstacles.(Such as wall ) 2) The repeater’s power is on but the phone is not connected into the network and still can not communicate.
