Bernard Cable Connectors Specification Sheet

Manual Products
Cable Connectors, Lugs, Splicers
Bernard Manual Welding
Products
Bernard
®
An Illinois Tool Works Company
449 West Corning Road, Box 667
Beecher, Illinois 60401 USA
Phone: 800-946-2281 708-946-2281
(US Only)
Fax: 708-946-6726
For more information, visit us at BernardWelds.com
Issued July 2007 • SPEC MP-1.3
Time Tested Performance.
Our Manual Welding Products provide
high quality with a wide range of
styles, sizes and capacities to enhance
your welding applications.
Cable Connectors
•
•
•
•
Positive Lock Terminal Lugs
•
•
•
•
Hammer-on Cable Lugs & Splicers
•
•
•
•
Solder Type Lugs
•
•
•
(Outside US)
Heavy-duty ball-point set screw cable
connection
Fully insulated covers for maximum safety
Interchangeable with most popular models
Connector locking screw designed for
longer life and superior electrical
connection
Lug screw designed for enhanced field
repairability
Composite copper alloys for superior
conductivity
Increased cable depth for better
connections
Fully insulated covers are heat, oil and
abrasion resistant
Simple as driving a nail to attach
No soldering, no bolting, no set screws, no
crimping tools required
Twice as heavy as most crimp-type
connectors
Same conductivity as the cable they
connect
Copper alloy for excellent electrical
conductivity
Flared end for easy cable access
Stud hole size 17/32
USA
Made with
Pride and without
Compromise in the
