Summary of Contents for AMTelecom MiFi LTE AMR510
-
Page 1: Quick Start Guide
MiFi LTE Quick start guide Ver1.0 © Copyright 2012 AMTelecom Co., Ltd. All right reserved... - Page 2 Quick start guide Manual Version Date Contents Remarks 2012.01.19 Manual Cover Page...
-
Page 3: Cautions For Safety
Quick start guide Cautions for Safety This is for how to use the product safely and normally in order to protect the user and user’s properties. Please read user guide carefully and put it near to you. Warning Misusage of the product may harm you severely Please keep it to room temperature all the time It may cause defect or explosion of battery when you put the device and its battery to high temperature or humid place, in the car under direct sun light for a long time. - Page 4 Quick start guide Warning Misusage of the product may harm you severely Please use its original battery and accessories all the time and do not try to change its SW If you use non-genuine battery and accessories, it may shorten the product life and explode. If you try illegal SW, it may cause defect.
- Page 5 Quick start guide Caution Misusage of the product may harm you or cause defect Other electric appliances may interfere each other Electric appliance’s electromagnetic may interfere each other, it may cause malfunction Please do not modify or disassemble or repair it by yourself It may cause defect, damage, electric shock, fire.
-
Page 6: Basic Package
Quick start guide Basic Package < Power Adapter > < USB Cable > < AMR510> < Battery> < Quick Start Guide> Actual product may look different from above images or changed Name of each parts Power Button WPS Button Charging Port... - Page 7 Quick start guide How to remove and assemble battery How to remove battery cover Please use your finger tip to lift up the battery cover. You can use batter cover lift hole at bottom side How to remove battery Please remove battery as shown on the photo How to assemble battery back in Please put battery connecting port first to...
- Page 8 Quick start guide How to insert USIM Card Open battery cover and battery Please open battery cover and battery first Insert USIM card Insert USIM card to its slot. Please insert USIM by IC chip side to bottom How to remove USIM card Please use your finger tip to push it out from its socket ...
-
Page 9: How To Recharge The Battery
Quick start guide How to recharge the Battery Recharging can be done through the connection to PC by USB cable or power adapter by AC adaptor by USB cable to PC When USB cable is connected correctly, 3 LED are blinking for 2 seconds in white color ... -
Page 10: Power On/Off
Quick start guide Power on / off Power on Please press power button When power is on, 3 LED are blinking in a turn of “Red-Blue-White” Power off Please press long the power button Power button LED Indications LED Color ... - Page 11 Quick start guide How to connect WiFi enabled devices You can connect PC, Game devices or tablet PC Please connect SSID of MiFi LTE from your Wireless LAN enabled device Please enter SSID of MiFi LTE Enter now for pairing ...
- Page 12 Quick start guide Web CM Home You can set advanced setting of Router • Basic Information • APN Setting • Router Setting • Wi-Fi Setting • Firewall Setting • Device Information...
- Page 13 Quick start guide How to change SSID Home > Wi-Fi Setting > Select default setting Type new SSID and apply How to change Encryption setting Home > Wi-Fi Setting > Select Encryption setting Set as desired encryption setting ...
-
Page 14: Specifications And Features
Quick start guide Specifications and Features MTiFi LTE WCDMA(HSDPA,HSUPA) TX: 824 ~ 849MHz, 1850 ~ 1910MHz RX: 869 ~ 894MHz,1930 ~ 1990MHz Frequency Range TX: 1710MHz ~ 1755MHz RX: 2110MHz ~ 2155MHz WCDMA: within ±0.1 PPM Frequency Accuracy LTE: within ±0.1 PPM + 15Hz WCDMA: 0.25W... -
Page 15: Warranty Policy
Quick start guide Warranty Warranty service shall be provided free of charge when defect is caused by product itself ▶ Warranty Period Device and Adapter : 1 year Battery : 6 months Serial Number Customer Name Address Phone Shop Name Purchasing Day * Please complete this form when you purchase the product and keep it together with warranty policy paper in order to be served well on warranty service... - Page 16 Quick start guide FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
