Installation Guide
Xwire
Universal SmartAdapter for
TM
Communications-Enabled Appliances
Xwire
SmartBezel Adapter for Process Controllers
TM
Xwire
SmartGateway PC Adapter
TM
SmartBezel
SAVE these instructions
for future reference.
www.MySCK.com
Direct, Inc.
SmartGateway
24/7 Toll-Free Technical Support
1-866-840-4271
(from the U.S., Canada and the Caribbean)
SmartAdapter
Advertisement
Summary of Contents for SCK Direct, Inc. Xwire SmartAdapter
- Page 1 Direct, Inc. Installation Guide Xwire Universal SmartAdapter for Communications-Enabled Appliances Xwire SmartBezel Adapter for Process Controllers Xwire SmartGateway PC Adapter SmartAdapter SmartBezel SmartGateway SAVE these instructions for future reference. 24/7 Toll-Free Technical Support 1-866-840-4271 www.MySCK.com (from the U.S., Canada and the Caribbean)
-
Page 2: Tools Required For Installation
Xwire Direct, Inc. NOTICES Changes or modifications not expressly approved by SCK Direct, Inc. could void the SCK Direct, Inc. is not liable for any use of product not in accor- dance with SCK Direct, Inc.’s installation and operation manufacturer’s warranty and the user's instructions. - Page 3 installation guide STEP 1 The SmartGateway should be installed first. Xwire Wireless SmartGateway Adapter REQUIRED PARTS Xwire Wireless SmartGateway Adapter SCK Part No. 231-60207-01 USB Cable, 5M SCK Part No. 141-15734 INSTALLATION Connect USB cable to the communication port on the SmartGateway. Power off the PC and connect the SmartGateway to an available USB port using the USB cable.
- Page 4 Xwire Direct, Inc. STEP 2 Clamp self-tapping connector to these wires to provide a 24VAC output for the SmartBezel. The SmartBezel Adapter Xwire SmartBezel Adapter for FAST VC-210 & FAST EM-99 CONTROLLERS Connect the two spade terminals to the pair coming from the SmartBezel.
- Page 5 installation guide STEP 3 Xwire Universal SmartAdapter for FRYERS AND OVENS The Universal SmartAdapters Xwire Universal SmartAdapter for (FAST.)® TRACKER TIMERS REQUIRED PARTS (A) Xwire Universal SmartAdapter for Fryers and Ovens SCK Part No. 231-60208-01 (B) Self-tapping Connectors (included) SCK Part No. 141-51026 REQUIRED PARTS Qty.
- Page 6 Xwire Direct, Inc. Light Bars and Status LED The SCK Xwire status indicator consists of three colors (Green, Red and Orange) to visually indicate transmission strength and operating status to the operator. See the charts below for details. SIGNAL STRENGTH INDICATORS LIGHT BARS How Do I Know if It’s Working? STRONG Under normal operating conditions, the status LED will be solid...
- Page 7 installation guide TROUBLESHOOTING / LED CODES LED Action Description Solution All LEDs blink on and Device has detected a multiple SCK address 1. Verify that all enabled controls are set to a off simultaneously conflict and is waiting for resolution (cur- different SCK address.
-
Page 8: Troubleshooting
Troubleshooting Should you experience problems installing your SCK Xwire prod- ucts, or any aspect of your SCK Direct, Inc. services, please contact the SCK HelpDesk toll-free at 1.866.840.4271. Optional SCK System Components SCK has a variety of optional accessories to help you complete your kitchen automation: SCK Kitchen Advisor Information Server SCK Remote Input Device...
