Summary of Contents for H.K. Forever Technology CK-606A
- Page 2 Index ............Introduction .
- Page 3 Index ............Voice dialing .
- Page 4 Introduction CK-606A use the Blue tooth technology to communicate wirelessly in certain distance CK-606A system let you communicate freely and safely when driving Double lines LCD displayer One line for current status and indication message the other line will show the number of the coming call...
- Page 5 Installation guide 2 Push the bracket smoothly into the slot of Insert the bracket into the slot at the back of main unit main unit and the direction showas 4 Take off the protection film in cupula Accomplish the installation of bracket and Main unit...
- Page 6 Installation guide Adhere the cupula on the glass tightly after clean the glass According to the arrow showed in picture Press the cupula hardly...
-
Page 7: Charger Led
Control Panel Introduction CHARGER LED LED is bright all the time when charging and go out when Fully charged LCD display two lines as below First line: show the current status and Indication message The second line: Show the number of the coming call and the menu information... - Page 8 Control Panel Introduction During communication Press the button to decrease the volume Check the record when the device is free During communication , press the button for two seconds and change to Silence When the device is free, Press the button for two seconds and the device Will dial the last dialed telephone number automatically...
- Page 9 Control Panel Introduction When have coming call press the button to answer the phone Under record checking situation press the button to dial the chosen telephone number Under the language choice situation press the button to confirm the chosen telephone When the device is free Press the button shortly to trigger the voice...
- Page 10 LCD Introduction Answer the coming call Indication for the coming call Hang off The indication of the signal intensity The indication of the connection for mobile telephone The indication of the power...
- Page 11 Operation Instruction Power On When power off press the button The LCD display the following pictures Press the button two seconds The LCD disply the following pictures...
- Page 12 Operation Instruction Press the button for two seconds and realease the buttton LCD display the Following pictures Successful connection LCD display the following pictures SGH-D808...
- Page 13 Operation Instruction Unsuccessful connection LCD display the following pictures Power off When power on Press the button for 4 seconds to power off The LCD display The pricures as below...
- Page 14 If matching is overtime or fail The LCD will show the pictures as below If match successfully,Some phone could connect automatically,some phone should make the connection by hands Please refer to the manual for the mobile telephone When connection for matching the type for device is CK-606A and Password is: 0000...
- Page 15 Operation Instruction During connection The LCD show the pictures as below When Connection successful The LCD show the pictures as below...
- Page 16 Operation Instruction When connection unsuccessful The LCD show the pictures as below No operation situation Lcd will display the following pictures after the successful connection...
- Page 17 Operation Instruction Display the number of coming call When there is a coming call Lcd display the following pictures Answer the phone When there is a coming call press the button to answer The LCD show the Picture as below...
- Page 18 Operation Instruction Call Transfer Under communication situation Press the button for two seconds to transfer The coming call There are voice indication when transferring When transfer to Mobile telephone The LCD show the pictures as below Then press the button again for two seconds to transfer back The LCD show the pictures as below...
- Page 19 Operation Instruction Silence function When communication press the button for 2 seconds to transfer into silence After transferring to silence The voice indication will be given an indication Every five seconds LCD show the pictures as below Press the button for two seconds could turn back communicating status show the pictures as below...
- Page 20 Operation Instruction Voice dialing When the device is free after connection Press the button shortly to trigger the voice dialing function,After hear the indication, Using the language set by Mobile Telephone to command the voice dialing LCD display the following pictures Redialing When the device is free after connection press the button for two...
- Page 21 Operation Instruction Check the number of coming call and dial the number of coming call When the device is free press the button shortly to check the number of Coming call downwards When the device is free press the button shortly to check the number of Coming call upwards he max for storage number is 20 LCD display the following pictures When checking the record Press the[...
- Page 22 Operation Instruction When checking the number press the button to dial the number chosen LCD display the following pictures When checking the record If don't have any operation in 5 seconds Return to standard status Increase volume When communication press the[ ]button to add the volume (One press to add one degree ) LCD show the pictures as below...
- Page 23 Language Update CK-606A support the language update function (Germany,Italy,Spanish,French)and factory default language is [Englis] When the device is free press the [L] button to Choose the language press the[L]or[+]to choose the language showed before and...
- Page 24 Operation Instruction Dialing or cancel the dialing There are several ways to dial When the device is free press the[ or[ ] buttoner for two seconds Dial Telephone number that is called at the last time hen checking the phone book press the[ button to dial the Checking Number directly When the device is free press the[...
- Page 25 Operation Instruction Finish the communication When communication press the to end the communiction Backlight indication When there is coming call or press any button The backlight will be bright automically If no coming call or any operation on the button within 8 seconds The backlight will go out automatically Shortage power indication...
- Page 26 Operation Instruction Charge the battery When charging The LED is bright all the time and go out when full charged The LCD show the pictures for 3 seconds every 10 seconds as below Privacy Protection When there are other passengers Insert the earphone Speaker keep silent automatically Then passengers could not hear the communications to protect personal privacy...
- Page 27 Technical specification Technical standard BLUETOOTH 2.0 Version C S R B C 0 4 Bluetooth Chip Wireless Frequency 2 . 4 G H z Output Power 4 4 d b m 1 0 m Transmission Distance Sensitivity for receiver 8 0 d b m ower for charger + 1 2 V + 3 .
-
Page 29: Rf Exposure Compliance
RF exposure Compliance To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Use only the supplied antenna. FCC Caution: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
