Read all instructions carefully before assembling and using this
article. Retain them for future reference and if you are passing this
product to a third party, always make sure this documentation is
included.
1 Intended use
This wall bracket is designed for wall mounting of flat panel televisions and monitors with a screen
size between 32" to 65". It can be installed on wood stud and solid concrete walls indoors and only
within private households. It is not designed for installation for commercial purposes.
2 Safety Notes
We recommend that this product should only be installed by suitably qualified persons or
persons competent in DIY. If you are unsure of any part of the installation, please contact a
professional installer.
Never leave children unsupervised with this product or its packaging. This article contains small
parts that could pose choking hazard. Packaging materials pose su ocation hazard.
Correct and safe installation is extremely important. Falls are outside the scope of responsibility of
the manufacturer. The supplied kit is designed for installation on solid wood or concrete walls. For
any other types of surfaces, assistance from professional installer is recommended.
Do not install this article in places under which people or animals may stand.
Handle the TV carefully during installation since subjecting it to impact or other forces may cause
product damage.
Carefully read the instructions accompanying optional accessories, and be absolutely sure to take
steps to prevent the TV from falling o .
Always read the section of instruction manual that came with your TV related to wall mounting as
some TV might require special fittings or installation requirements such as distance from wall.
Take care when fixing wall brackets to the wall. Always ensure that there are no electrical
cables or pipes in the wall before hanging bracket.
Before installing this article, ensure the wall is capable of supporting the combined weight of
television and bracket. Never exceed bracket's maximum load of 35kg. Exceeding the weight
load may cause product failure.
Ensure that wall structure and fixings are capable of supporting the TV set. Check the
strength of the installed wall plate before attaching the TV with brackets onto it.
Product:
Tilting TV Wall Bracket
1
Item Code:
RTVRACK
Advertisement
Table of Contents
Summary of Contents for Wido RTVRACK
- Page 1 Product: Item Code: RTVRACK Tilting TV Wall Bracket Read all instructions carefully before assembling and using this article. Retain them for future reference and if you are passing this product to a third party, always make sure this documentation is included.
- Page 2 3 Identification of parts There are many variants of TV sets on the market requiring di erent types of fitting. Bearing this in mind, the kit supplied with this article might not support the TV you are trying to install. If the bolts required for safe and proper installation of the bracket to your tv are not included, please purchase required fittings from specialist shop.
- Page 3 5 Installation Avoid any live, electrical, utility pipes behind the wall. Before proceeding with installation, ensure you have all parts and tools required for safe and complete installation. Check that included bolts (F) match the TV set you are going to fix. Should the TV set require di erent size bolts to fix bracket arms, postpone the installation until you have a complete set.
- Page 4 Wood stud installation Identify where the studs are using a Stud Finder. Position the bracket against the wall in chosen location, align it using the spirit level included with Select suitable wall mounting height. We the bracket. Mark four holes with a pencil. recommend positioning the TV set on the eye level from seating position in front of the TV.
- Page 5 Attaching the bracket arms Locate the VESA mounting holes on the back of your TV set. Align the brackets to the holes on back of the TV set. Secure the bracket rail using suitable size bolt, washer. Use extension washers (E) in front of round washer if the bolts provided are too long for the depth of the fixing holes.
- Page 6 Attaching the bracket arms Complete this final step with a help of another person. Lift the TV set with brackets attached to the back of it, hook with the bracket over the wall plate. Tighten the bolt (H) on each of the brackets to secure it to the plate. Maintenance Inspect the wall bracket regularly (at least every two months) to check that bolts and screws have not loosened and your TV is securely fixed to the bracket and wall.
