Summary of Contents for Magnum Industrial MI-52100
- Page 1 MODEL NO.: MI-52100 OPERATING MANUAL...
- Page 2 RULES for SAFE OPERATION MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD To help ensure safe operation, please take a moment to learn the how to operate the machine and understand its applications and limitations, as well as potential hazards. KMS Tools and Equipment disclaims any real or implied warranty and holds itself harmless for any injury that may result from the improper use of its equipment.
- Page 3 MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD The Magnum Industrial 10" overarm blade cover features a telescoping boom design that fits most table saws easily. It is compatible with saws equipped with riving knives and it connects to your dust collection system for efficient dust collection at the source.
- Page 4 TOOL OVERVIEW MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD IDENTIFICATION OF MAIN COMPONENTS FIGURE 1: FRONT VIEW MAIN COMPONENTS (A) DUST HOSE (B) SWING ARM (C) BOOM ASSEMBLY (D) HOOD FRAME (E) LENSES (F) DIAGONAL BRACES (G) BUMPER HANDLE (H) BOOM MOUNT CHANNEL...
- Page 5 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD • Before you assemble your blade guard, review the parts breakdown and keep it ready for reference. • Start by removing the parts from the packaging. • Carefully check the packaging for small pieces before you continue.
- Page 6 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD BASIC FUNCTIONS The MI-52100 is a blade cover and dust collection hood. It's intended for use on 10" table saws and is compatible with saws equipped with riving knives. Minimum: 3"...
- Page 7 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD ASSEMBLING DIAGONAL BRACES To assemble the diagonal braces, follow these steps: Spin a 1/4" HEX NUT (B) onto each EYEBOLT (A). See Figure 9. FIGURE 9: THREADING HEX NUT ONTO EYEBOLT Pass one EYEBOLT through the hole in the bent end of each DIAGONAL BRACE (C).
- Page 8 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD INSTALLING THE BOOM MOUNT CHANNEL Set the boom mount channel against the edge of your extension table, lining up the MOUNTING PIN (A) on the boom mount with the centre of the BLADE (B). See Figure 15.
- Page 9 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD ATTACHING THE BOOM TO THE BOOM MOUNT CHANNEL Place the boom and hood assembly on the pivot pins located on the boom mount channel. See Figures 19 and 20. Swing the arm over the table.
- Page 10 ADJUSTING THE ASSEMBLY MAGNUM INDUSTRIAL MI-52100 10" OVERARM BLADE GUARD ADJUSTING THE BLADE GUARD ASSEMBLY You can adjust the resistance or balance of the swing arm assembly by turning the SPRING KNOB (A) located at the rear of the swing arm assembly. See Figure 27.
- Page 12 PARTS LIST MI-52100 & MI-52150 PART NO. DESCRIPTION SPECIFICATION MI-52100-1 HOSE 3"*720MM MI-52100-2 HOSE CLAMP 3.5" MI-52100-3 LOCK NUT 1/4"*5MM MI-52100-4 LOCK NUT MI-52100-5 CARRIAGE BOLT 1/4"*2-1/4" MI-52100-6 PLASTIC WASHER MI-52100-7 SWING ARM MI-52100-8 HEX.HEAD BOLT M5*45MM MI-52100-9 HEX.HEAD BOLT 1/4"*1/2"...
- Page 13 PARTS LIST MI-52100 & MI-52150 PART NO. DESCRIPTION SPECIFICATION MI-52100-43 HEX.HEAD BOLT 1/4"*1-1/2" MI-52100-44 BOOM MOUNT CHANNEL MI-52100-45 CARRIAGE BOLT 1/4"*4" MI-52100-46 OUTER BOOM MI-52100-47 WASHER M5*16*1.0T MI-52100-48-1 BUTTON HEAD BOLT M5*25MM MI-52100-48 BUTTON HEAD BOLT M5*12MM MI-52100-49 5/16"*5/16"*710MM MI-52100-50...
