The WaveMark SmartWand SW1500 Portable RFID/Barcode Reader Kit comprises the following
components:
1. WaveMark SmartWand (WaveMark 01-0029-R)
2. Power Supply/charger (WaveMark 90-0094-R)
3. International Plug kit for Power Supply (WaveMark 90-0095-R)
4. Tether strap (WaveMark 90-0096-R)
5. Software (please see your WaveMark representative for appropriate software applications)
WaveMark SmartWand
Tether
The WaveMark SmartWand is a battery-operated RFID/Barcode reader and is equipped with a
rechargeable battery pack that is capable of running the reader for one 8-hour shift (50% RFID
duty-cycle) on a full charge. The battery pack is based upon Lithium Ion cells, nominally 7.4VDC.
The SmartWand battery pack is shipped to the customer pre-installed in the WaveMark
SmartWand and is partially charged when shipped.
The WaveMark SmartWand has a power slide switch on the back.
WaveMark Document 97-0009 Rev B
WaveMark SmartWand SW1500 RFID/Barcode Reader
Plug Kit
Power Supply
Power slide switch
Advertisement
Table of Contents
Summary of Contents for WaveMark SmartWand SW1500
- Page 1 Power Supply Tether The WaveMark SmartWand is a battery-operated RFID/Barcode reader and is equipped with a rechargeable battery pack that is capable of running the reader for one 8-hour shift (50% RFID duty-cycle) on a full charge. The battery pack is based upon Lithium Ion cells, nominally 7.4VDC.
- Page 2 When the switch is in the left position, the WaveMark SmartWand is off. Slide the switch to the right to turn it on. A green or orange power light on the control panel will light if the device is on: Power Light ...
- Page 3 When charging, the power light will be flashing green. When fully charged, the power light will be solid green. Do not use the WaveMark SmartWand to read RFID tags or Barcodes while it is charging. A full charge will take approximately 6 hours, but shorter charging cycles will provide a partial charge.
- Page 4 The WaveMark SmartWand has a USB-mini-B port adjacent to the charging port. This USB port is not currently supported for any user accessible purpose. It also will not successfully charge the battery in the WaveMark SmartWand. Do not plug a USB cable into this port.
- Page 5 Charging Current: 0.5 A Max RFID Tag Types Supported: HF, ISO 15693, 13.56 MHz Maximum Read Speed: 50 RFID tags/second Bluetooth: Smart Ready, Bluetooth® 4.0 Maximum Bluetooth Pairing Range: 50 meters Barcode Reader: 1-D + 2-D Imager WaveMark Document 97-0009 Rev B...
- Page 6 Changes or modifications not expressly approved by WaveMark, Inc. could void the user’s authority to operate the equipment.
