Handpiece Lubricating System
LUB909
Operation Manual
NINGBO JIANGBEI WOSON MEDICAL INSTRUMENT CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUB909 and is the answer not in the manual?

Questions and answers

Summary of Contents for Woson LUB909

  • Page 1 Handpiece Lubricating System LUB909 Operation Manual NINGBO JIANGBEI WOSON MEDICAL INSTRUMENT CO., LTD.
  • Page 2: Table Of Contents

    Handpiece Lubricating System Content Ⅰ Basic Features ................3 Ⅱ Parameters ................. 3 Ⅲ Structure of Handpiece Lubricating System ........ 3 IV Installation Components ............4 Ⅴ Operation Procedure ..............5 Ⅵ Disassembling and Installation of Front Door Cover ....8 Ⅶ...
  • Page 3: Ⅰ Basic Features

    2. Can serve three handpieces at the same time . 3. The rotation gear of LUB909 can make effective cleaning and oiling for the handpiece in different angles. 4. Press “Air” button after cleaning and oiling to remove residual oil.
  • Page 4: Iv Installation Components

    Handpiece Lubricating System All the products are provided with accessories. Please contact your distributor if any of the accessories is missed as detailed in Table 1. Table 1 Name Unit Remark Power Line line Maintenance Oil Kettle Oil Hopper Piece Mist Filter Cotton Piece Air Pipe...
  • Page 5: Ⅴ Operation Procedure

    Handpiece Lubricating System 3. Check whether the hopper is clean before inject the oil, place the oiling cap to oiling hopper. Fill the maintenance oil till its “Full”. Tighten the oil cap to right position (As shown in Pic 4) Oil Hopper Pic 4 4.
  • Page 6 Handpiece Lubricating System locked tight (As shown in Pic 6) Close the door cover carefully. Type-E coupling head Straight Handle Handpiece Pic 6 Corner Handle Handpiece ① Remove the drill bit from the handpiece ② Open the door cover, install the Drill Bit Jack handpiece into type-E coupling head till the handpiece and the joint is...
  • Page 7 Handpiece Lubricating System 2) Select “1”, “2” or “3” according to the corresponding handpiece installed on the coupling heads. Press once for “S” short mode; press twice for “L” long mode and press thrice for “E” Extremely long mode . 3) Select the correct mode for each handpiece if the amount is two or more.
  • Page 8: Ⅵ Disassembling And Installation Of Front Door Cover

    Handpiece Lubricating System Press Fastening Button Pull Downwards to remove the handpiece Pic 10 Ⅵ Disassembling and Installation of Front Door Cover First insert the fixed pin to the left pin hole of the front door cover and then press tight the moving pin. When pushing the front door cover from right to left, knot the moving pin into the right pin hole.
  • Page 9 Handpiece Lubricating System Filter Cotton Front Door Cover Pic 12 2. Replacement of O-type Ring Take the old O-type ring with thumb and put new one in the slot, as shown in Pic 13. O-type Ring Pic 13 3. Replacement of air filter 1) Take out the air pipe from the quick coupling to the left and right as shown in Pic 14 and 15 .
  • Page 10: Ⅷ Failure Recovery

    Handpiece Lubricating System Pic 16 4. Drainage of Air Filter Press the water drainage button upwards to drain the water, as shown in Pic 17 5. Replacement of Fuse As shown in Pic 18 to 21. Power Line Fuse Box Jack Screwdriver Drainage...
  • Page 11: Ⅸ Precautions

    Handpiece Lubricating System Phenomenon Possible Causes Solutions The power line is not connected with outer Connect the power line with outer circuit circuit The power line is not inserted into the Insert the power line i into the power No Power power source joint source joint Whether the Power switch is on...
  • Page 12 Handpiece Lubricating System close the power supply and push back the plug immediately and contact the distributor. If the equipment will be left unused for long terms, take out the air pipe and power line and lay the machine on level plain to avoid dropping. Wait for five seconds if oiling cap is needed to be removed in operation or abnormal stopping (e.g.
