Powering The Module; Introduction; Panel Overview; Channel's Inputs - Befaco STMIX User Manual

S T M I X
P O W E R I N G T H E
M O D U L E
Disconnect your cabinet from the mains
1 .
Triple check the power cord polarity
2.
(pin number one) is the -1 2V rail.
3. If you plug the module backwards you might burn it out and
unfortunately this is not covered by the warranty.
4. If you have any questions about this product please send them to:
befacosynth@gmail.com
I N T R O D U C T I O N
STMix is a four channel stereo mixer in 6hp. It can work independently or as expansion of our Hexmix module
via the six pin connector located in the back. The module includes an extra stereo input (Aux) without
attenuation that goes directly to the output.
M O D U L E
R E F E R E N C E
.1
U S E R M A N U A L
T H A N K S F O R P U R C H A S I N G A M O D U L E F R O M B E F A C O
B E F O R E Y O U P L U G T H I S M O D U L E I N . . .
The coloured line on the cable
S T M I X
P A N E L O V E R V I E W
P O W E R & I N T R O
1
Channel s Inputs
Stereo input of each channel. Use the Left input
of each channel for Mono signals. All the inputs
are DC Coupled so the module can also be used
for mix CV.
2

Aux Input

This input is technically equal to channel's inputs
but doesn't have attenuation control, it goes
directly to the output.
3 Channel s knobs
Manual attenuation controls of each channel
input.
4

Output

Main stereo output of the module. When Mono
signals are present on the channels, a duplicate
of those signals will be present on the Right
output
