Summary of Contents for Vanderbilt CMTC2315
- Page 1 CMTC2315 TFT-LED Monitor User Manual...
- Page 2 Liefermöglichkeiten und technische Änderungen vorbehalten. Data and design subject to change without notice. / Supply subject to availability. © 2016 Copyright by Vanderbilt Wir behalten uns alle Rechte an diesem Dokument und an dem in ihm dargestellten Gegenstand vor. Der Empfänger erkennt diese Rechte an und wird dieses Dokument nicht ohne unsere vorgängige schriftliche Ermächtigung ganz oder teilweise Dritten zugänglich machen oder...
-
Page 3: Table Of Contents
Power management ..................18 Mounting ...................... 19 Setting the OSD screen ................20 11.1 Custom ......................20 11.2 Image and sound................... 21 11.3 Picture in Picture (PiP) .................. 23 11.4 Setup ......................25 Troubleshooting ..................27 Disposal ....................... 28 © Vanderbilt 2016... -
Page 4: About This Document
[-> 3] Cross-reference Save Button <Ctrl> Tips and information Contact If you have questions or suggestions regarding the product or this documentation, please contact our Technical Competence Center. Internet: service.vanderbiltindustries.com Vanderbilt provides training courses for all products. © Vanderbilt 2016... -
Page 5: Safety
Danger of electrical shock when the device casing is open. Only qualified personnel should open the unit. Transport Damage during transport Keep the packaging material for future transportation. Do not expose the device to mechanical vibrations or shocks. © Vanderbilt 2016... -
Page 6: Installation
Danger of explosion or burn hazard if the battery is improperly installed When inserting new batteries make sure the battery poles are correctly positioned. Do not expose the battery to fire or high temperatures. Discard used batteries according to local regulations. © Vanderbilt 2016... -
Page 7: Service And Maintenance
Do not attempt to service or modify this device yourself. Refer this work to qualified service personnel. Danger of electrical shock while cleaning the device Do not use liquid cleaners or sprays that contain alcohol, spirit or ammonia. © Vanderbilt 2016... -
Page 8: Eu Directives
Emitted interference: EN 61000-3-2 EN 61000-3-3 EN 55022 Kl. A Interference resistance: EN 50130-4 European Directive 2006/95/EEC “Low-Voltage Directive” Compliance with the European Directive 2006/95/EEC has been proven by testing according to the following standards: Safety: EN 60950-1 © Vanderbilt 2016... -
Page 9: Product Description
Product description Product description The CMTC2315 is part of the new wide screen monitor range of Vanderbilt. The high-resolution TFT monitor has been specifically designed for CCTV applications and is ideally suited for use with digital video recorders (DVR) and PC applications. -
Page 10: Technical Data
548 x 330 x 55 mm (without base) Package dimensions (W x H x D) 600 x 460 x 160 mm Material ABS plastic Weight Net weight: 4,4 kg Gross weight: 6,6 kg Environmental operating temperature 0 – 40 °C © Vanderbilt 2016... - Page 11 Technical data Storage temperature -20 to +60 °C Relative humidity Max. 80%, non-condensing Wall mount VESA 100 Approved battery type AAA / 1.5 V Approval © Vanderbilt 2016...
-
Page 12: Details For Ordering
Details for ordering Details for ordering Type Order number Designation Weight (total) CMTC2315 58 cm LED CCTV Monitor 16:9 6,6 kg V54573-C24-A1 © Vanderbilt 2016... -
Page 13: Scope Of Delivery
Scope of delivery Scope of delivery TFT LED monitor External power supply unit Power cable DVI cable HDMI cable VGA cable Audio stereo cable Remote control (incl. batteries) Operation manual © Vanderbilt 2016... -
Page 14: Dimensions
Dimensions Dimensions All dimensions in mm. © Vanderbilt 2016... -
Page 15: Device Description Safety
Pin 4 Update Pin 12 SDA (for DDC) Pin 5 Ground Pin 13 H-SYNC (or H/V SYNC) Pin 6 Red ground Pin 14 V-SYNC Pin 7 Green ground Pin 15 SCL (for DDC) Pin 8 Blue ground © Vanderbilt 2016... -
Page 16: Control Elements
In OSD menu: Adjusts menu settings Turns the power on or off 8 Power LED Indicates the monitor power status (Blue = Power is turned on; Red = Power is turned off) 9 IR sensor Remote control sensor © Vanderbilt 2016... -
Page 17: Remote Control
APC (Auto Picture Control): Selects the image mode ACC (Auto Colour Control): Selects the colour mode S.SET: Selects the sound mode in the main or sub-image PC: Selects the PC mode (PC/DVI/HDMI) AV: Selects the AV mode (AV1/AV2/S-VIDEO) COMP: Selects the COMPONENT mode COMP © Vanderbilt 2016... -
Page 18: Power Management
Power consumption Mode Power consumption < 28W < 0.5W LED indicator The power management function of the monitor includes the following statuses: Mode LED colour Monitor operation Blue Normal mode No operation © Vanderbilt 2016... -
Page 19: Mounting
You must use four M4x10 screws to assemble this monitor and the wall mount bracket. ※ Warning! If user use longer than M4x10mm, it may cause the damage on the unit. Please follow instructed bolt size & length. © Vanderbilt 2016... -
Page 20: Setting The Osd Screen
The OSD menu disappears automatically after no settings are made after a certain time. 11.1 Custom "Custom" menu in video mode; "Custom" menu in RGB-PC or HDMI mode Option Function Values Brightness Adjusts the screen brightness 0 – 100 © Vanderbilt 2016... -
Page 21: 11.2 Image And Sound
NR * Reduces image noise On, Off 3D Comb * Sets the 3D comb filter On, Off PC ** Sets the PC input parameters See table below only in video mode ** only in RGB-PC mode Picture Mode © Vanderbilt 2016... - Page 22 ** not available in RGB-PC Auto Adjust Automatic geometry adjustment Phase Defines the number of horizontal pixels H.Position Defines the horizontal image position V.Position Defines the vertical image position Frequency Defines the vertical image frequency © Vanderbilt 2016...
-
Page 23: Picture In Picture (Pip)
Sub-image Available combinations AV1 or AV2 AV1 or AV2 AV1 or AV2 RGB PC, DVI or HDMI RGB PC, DVI or HDMI AV1 or AV2 Unavailable combination RGB PC, DVI or HDMI RGB PC, DVI or HDMI © Vanderbilt 2016... - Page 24 Side by side (4:3) Main image image PBP2 Full screen, side by side Main image image PIP Size Size1 Small PiP image Size2 Medium PiP image Size3 Large PiP image Position Bottom right Bottom left Top left Top right © Vanderbilt 2016...
-
Page 25: 11.4 Setup
Key Lock Locks all keys of the monitor On, Off Note: To unlock the keys use the remote control Trigger Enables the trigger function See table below Auto Sets the auto-switching settings See table below Switching © Vanderbilt 2016... - Page 26 Auto Switching Activates the Auto Switching feature Input Enable Selects the input sources to include in the Auto Switching cycle Time Selects the time period (3 – 100 s) during which the monitor displays each selected input source © Vanderbilt 2016...
-
Page 27: Troubleshooting
The image in the PC mode is not centered, too Press the "Down" key on the front or the "Auto" small or too large key on the remote control. The image shows vertical or horizontal Set clock and phase in the OSD menu. interferences © Vanderbilt 2016... -
Page 28: Disposal
Detailed information about the disposal of your used devices can be obtained at your municipality, your garbage disposal service or the dealer where you have purchased the product. © Vanderbilt 2016... - Page 29 Disposal © Vanderbilt 2016...
- Page 30 Issued by Vanderbilt © Vanderbilt 2016 Clonshaugh Business and Technology Park Data and design subject to change without notice Clonshaugh Supply subject to availability Dublin 17 Document no.: C-300925 Ireland Document version: 2.0 www.vanderbiltindustries.com Edition: 17/2/20163/3/2016...
