INSTALLATION & OPERATING
BAYCO AIR INTERLOCK ELECTRICAL
5000S..................... Air Interlock Electrical Switch Kit
5000AISW ............. Air Interlock W/ Electrical Switch Attached
U S A:
Dixon Bayco USA
Chestertown, Maryland
Phone: 410-778-2000
Fax: 410-778-4702
Toll Free: 800-355-1991
INSTRUCTIONS
SWITCH
Model Numbers
For Sales & Service Contact
Dixon Bayco
A DIXON COMPANY
CANADA:
Dixon Bayco Limited
Barrie, Ontario
Phone: 705-436-1125
Fax: 705-436-6251
Toll Free: 866-436-1125
40070PA Rev Oct 2003
1
Advertisement
Table of Contents
Summary of Contents for Dixon 5000S
-
Page 1: Model Numbers
INSTALLATION & OPERATING INSTRUCTIONS BAYCO AIR INTERLOCK ELECTRICAL SWITCH Model Numbers 5000S..... Air Interlock Electrical Switch Kit 5000AISW ..... Air Interlock W/ Electrical Switch Attached For Sales & Service Contact Dixon Bayco A DIXON COMPANY U S A: CANADA: Dixon Bayco USA... - Page 2 40070PA Rev Oct 2003...
- Page 3 Tools required for installation and part replacement 14mm open end wrench 3/4" open end wrench INSTALLATION CAUTION! SAFETY GLASSES MUST BE WORN DURING INSTALLATION AND SERVICE. CAUTION! BRASS END PLUG IS RESTRAINING A COMPRESSION SPRING. ENSURE THAT YOU HAVE A FIRM GRIP ON THE BRASS END PLUG BEFORE REMOVING 40070PA Rev Oct 2003...
- Page 4 ASSEMBLY 1. Using the 3/4" open-end wrench, remove the brass end plug from the existing Dixon Bayco Air interlock valve. Hold the end plug firmly to prevent the spring from ejecting the plug from your hand. 2. Leave the main spring installed inside the plunger. You may discard the brass end plug.
