Summary of Contents for BMZ Drive Systems V7

  • Page 1 BMZ Drive Systems V7 Operating Instructions...
  • Page 2 Product BMZ Drive Systems V7 comprising: identification Motor (#23084),  New-Style Display (#27937) or Sportive Display (#27938),  Rechargeable battery V7 (#29600 or #30900)  Country of origin: Germany Code: CE Customer service BMZ Service Center Am Sportplatz 15-17 63791 Karlstein am Main...
  • Page 3: Table Of Contents

    Contents Contents Motor Safety guidelines Intended use Explanation of the figure Operation Cycling and advice Maintenance and cleaning Inspection Transport Waste Disposal 1.10 Technical data Display Safety guidelines Intended use Explanation of the figures Description 2.4.1 Variants 2.4.2 Explanation of symbol 2.4.3 Charging status display 2.4.4...
  • Page 4 Waste Disposal 2.10 Technical data Rechargeable battery Safety guidelines Intended use Explanation of the figures Assembly 3.4.1 Insertion and removal of the rechargeable battery 3.4.2 Locking and unlocking the rechargeable battery latch Commissioning 3.5.1 Check the rechargeable battery before using it for the first time 3.5.2 Charging the rechargeable battery...
  • Page 5: Motor

    1 Motor Motor Safety guidelines WARNING There is a risk of danger, if the safety instructions are not observed. Non-observance of safety information and instructions can lead to an electrical shock, fire and/or serious injuries.  Please observe all safety information and instructions both in these and in all other instructions included with the E-Bike.
  • Page 6: Explanation Of The Figure

    1 Motor Explanation of the figure The illustrations are outlines only and details may vary on your E-Bike. Figure 1 Motor with design cover and mounted cranks Operation For more information about using the E-Bike, please refer to chapter 2.7. NOTE: The E-Bike system is only functional when the display is mounted.
  • Page 7: Maintenance And Cleaning

    1 Motor Support level: the higher the support level, the lower the range.  Switching behaviour  Type of tyres  Tyre pressure  Age, care and charging status of the rechargeable battery  The route profile (gradients) and quality (surface) ...
  • Page 8: Technical Data

    1 Motor 1.10 Technical data Table 1 Motor Technical data motor Art. No. #23084 Dimensions (mm) 213 x 150 x 128 Weight 3,400 g Rated voltage 36 V DC Type of protection: IP56 Max. torque 90 N m Continuous rated power 250 W Support up to 25 km/h...
  • Page 9: Display

    2 Display Display Safety guidelines WARNING There is a risk of danger, if the safety instructions are not observed. Non-observance of safety information and instructions can lead to an electrical shock, fire and/or serious injuries.  Please observe all safety information and instructions both in these and in all other instructions included with the E-Bike.
  • Page 10: Charging Status Display

    2 Display Figure 2 Symbols Display symbols new Pushing mode style (left) and: Sportive (right) Lighting Warning Charging status (2.4.3) Speed Unit (km/h, mph) Support level (2.4.4) Performance ratio cyclist Performance ratio motor 10 Multifunctional display (2.4.5) 2.4.3 Charging status display The charging status of the rechargeable battery (4) is shown in five segments on the display.
  • Page 11: Multifunctional Display

    2 Display 2.4.5 Multifunctional display Table 4 Key functions. In order to… Unit Multifunctional display Time (Time of Day) hh:mm (24 h or 12 h am/pm) Tour dist. (Trip Distance) km | mi Tour kcal (Trip Calories) kcal Tour time (Trip Time) hh:mm Ø...
  • Page 12: Remove New-Style Display

    2 Display Allen 2.5 mm  Tools Allen 3 mm  Intermediate cable  Figure 5 18 New-Style Display Mount the New-Style 19 Display bracket display Instructions Mount the control unit within reach on the handlebars. (allen 2.5 mm) Mount the display bracket in the centre of the handlebar (allen 3 mm). Place the New-Style display into the bracket at an angle of 45°...
  • Page 13: Operation

    2 Display It is only fully functional if the speed sensor and the cables have been mounted NOTE: correctly and the rechargeable battery is adequately charged. Operation 2.7.1 Switching on the E-Bike system Press the LED button on the rechargeable battery. ...
  • Page 14: Switchover The Multifunctional Display

    2 Display 2.7.6 Switchover the multifunctional display Instructions Menu Touch the touch field  2.7.7 Change the settings on the New-Style Display Overview You can make the following settings: Table 5 Range Value Settings New-Style Reset trip Reset all values for driving time, calorie Display consumption, average speed to 0 Reset all...
  • Page 15: Waste Disposal

    2 Display Waste Disposal Motor, display, rechargeable battery, speed sensor, accessories and packaging should be disposed of in an environmentally-compatible manner. Do not dispose of your E- Bike and its components in the household waste system. Only for EU countries In compliance with the European Directive 2012/19/EU electrical devices that are no longer serviceable, and in compliance with the European Directive 2006/66/EG faulty or spent rechargeable batteries/batteries, must be collected separately and disposed...
  • Page 16: Rechargeable Battery

    3 Rechargeable battery Rechargeable battery Safety guidelines WARNING There is a risk of danger, if the safety instructions are not observed. Non-observance of safety information and instructions can lead to an electrical shock, fire and/or serious injuries. Injuries or damage is also possible as a result of dangerous reactions of chemical substances that leak from the rechargeable battery resulting from non-observance of the safety instructions.
  • Page 17: Intended Use

    3 Rechargeable battery Only use the rechargeable battery in conjunction with E-Bikes with the  original BMZ E-Bike system. This is the only way to protect the rechargeable battery from dangerous overloading. Risk of injury or risk if other rechargeable batteries are used: only use ...
  • Page 18: Assembly

    3 Rechargeable battery Assembly 3.4.1 Insertion and removal of the rechargeable battery Figure 7 Insertion of the rechargeable battery The BMZ E-Bike system can be combined with a number of different rechargeable battery variants. The assembly and removal of the rechargeable battery depends on the rechargeable battery model used.
  • Page 19: Commissioning

    3 Rechargeable battery and unlocking the rechargeable battery from your cycle manufacturer and your bicycle dealer. Commissioning 3.5.1 Check the rechargeable battery before using it for the first time The rechargeable battery is partially charged when delivered. Therefore, test the rechargeable battery before you charge it for the first time or use it with your E-Bike.
  • Page 20: Charging Status Display

    3 Rechargeable battery The LED status display of the charger should now be active (see  4.5.3). Rechargeable battery not on the E-Bike Connect the charger connector to the charging socket of the  rechargeable battery. Charging begins.  NOTE: Some rechargeable batteries may have two charging connections.
  • Page 21: Operation

    3 Rechargeable battery corresponds to about 20% of the capacity. The flashing LED shows the charging of the next 20 %. During the charging process, the charging status display is presented as follows: Table 8 LEDs Charging status Charging status display 0-19 % ...
  • Page 22: Transport

    3 Rechargeable battery The service life of the rechargeable battery can be extended if it is maintained and, in Service life particular, stored in the right conditions. Temperature: 18-23°C  Air humidity: 0-80 %  Charging status: approx. 50 % ...
  • Page 23: Charger

    4 Charger Charger Safety guidelines WARNING There is a risk of danger, if the safety instructions are not observed. Non-observance of safety information and instructions can lead to an electrical shock, fire and/or serious injuries.  Please observe all safety information and instructions both in these and in all other instructions included with the E-Bike.
  • Page 24: Intended Use

    4 Charger Intended use The charger may only be used to charge the rechargeable batteries supplied with the E-Bike. Explanation of the figures All illustrations are outlines only and serve as examples. The details may vary from your own E-Bike because the BMZ E-Bike system can be combined with a number of different chargers.
  • Page 25: Charging Process

    4 Charger Insert the charging connector of the charger into a matching charging slot on the rechargeable battery. Charging begins.  Rechargeable battery Charging the rechargeable battery on the E-Bike on the E-Bike See Figure 9, page 19. Switch off rechargeable battery Insert the charger connector into the free charging slot.
  • Page 26: Maintenance And Cleaning

    4 Charger 4-A charger trickle charging Error green and red LED flash Maintenance and cleaning If the charger fails, please contact an authorised dealer. Use a soft dry cloth to clean the charger. Do not use water or other cleaning fluids! Waste Disposal The charger, accessories and packaging should be disposed of in an environmentally- compatible manner.
  • Page 27: Other Lists/Indices

    5 Other lists/indices Other lists/indices List of figures Figure 1 Motor with design cover and mounted cranks ..........6 Figure 2 Display symbols new style (left) and: Sportive (right) ........10 Figure 3 Control elements....................11 Figure 4 Rear side of Sportive Display ................11 Figure 5 Mount the New-Style display .................
  • Page 28 © 2017 BMZ GmbH. Subject to change. BMZ assumes no liability for technical or editorial errors. BMZ France S.A.R.L. BMZ GmbH Am Sportplatz 28 45 boulevard Vincent Auriol 63791 Karlstein am Main 75013 Paris Germany France Phone +49 61 88–9956–0 Phone +33 (0) 9 51 00 7579 Fax +49 61 88–9956–900 jean-marc.brunet@bmz-group.com...
