  • Page 1 ThinkRF P120 Vehicular Power Conditioner User Guide Version 1.1 March 2019 Document no. 75-0034-190306 Copyright © 2019 ThinkRF Corporation, all rights reserved. All product names are trademarks of their respective companies. This document contains information that is proprietary to ThinkRF Corporation.
  • Page 2 ThinkRF’s warranty policy, all costs of repairs and shipping will be charged directly in any form or by any to the Customer. ThinkRF will warrant repaired units for a period of 90 days from means, electronic, date of shipment from ThinkRF to the Customer. If the remaining period on the...

  • Page 3: Table Of Contents

    Setting Up the P120 ....................... 6 Preventing Electrostatic Discharge Damage ................. 6 Unpacking the Box ........................ 7 Getting Familiar with the P120 ....................7 P120 Vehicular Power Conditioner Unit ..................8 Power Input Cables ........................9 4’ Cigarette Lighter Plug to Female MX-LT Connector Cable ............. 9 12’...

  • Page 4: Preface

    Note: This symbol means take note. Notes contain helpful suggestions or references to additional information and material. Caution: This symbol means be careful. In this situation, you might do something that could result in equipment damage or loss of data. ThinkRF P120 Vehicular Power Conditioner - User's Guide 1.1...

  • Page 5: Obtaining The Latest Documentation

    9 AM to 5 PM Eastern Time, Monday to Friday. Please send your technical support request through http://www.thinkrf.com/support/. Before contacting Support, please have the following information available:  P120 serial number and product version, which are located on the product’s identification label. For any other information, contact ThinkRF at: ThinkRF Corporation...

  • Page 6: Overview Of P120

    The P120 outputs a single regulated +12VDC under different input voltages ranging from +8V to +32V, but can easily be modified for different output voltages (contact ThinkRF for alternatives). The inputs and outputs are provided via strain-relieved 16 AWG cables with 2-pin ML-XT Molex connectors.

  • Page 7: Unpacking The Box

    Unpacking the Box The following table lists the items that come with your P120 package. If any of the items in the Purchase Order are missing or damaged, please contact your ThinkRF customer service representative.

  • Page 8: P120 Vehicular Power Conditioner Unit

    ML-XT plug connector at the Power Output cable end;  a label on the P120 box that provides a clear indication of the input and output, along with the serial number (S/N) needed for support service should that be required.

  • Page 9: Power Input Cables

    Setting Up the P120 Power Input Cables On the power input end of the P120, there are two cable options as mentioned below. Follow Connecting P120 and Cables section for the proper instructions on putting together the cables. 4’ Cigarette Lighter Plug to Female MX-LT Connector Cable The 4’...

  • Page 10: Power Output Cables

    The 4’ male MX-LT connector to LEMO 2B plug 14 AWG cable connects the Power Output of the P120 unit to electrical equipment, such as ThinkRF R5700, that has a LEMO receptacle as its Power Input port. The push-pull self-latching LEMO plug of type 2B provides a secure connection to its mating connector against vibration, shock or pull on the cable.

  • Page 11: 4' Male Mx-Lt Connector To Barrel-Type Plug Cable

    4’ Male MX-LT Connector to Barrel-Type Plug Cable The 4’ male MX-LT connector to Barrel-type plug 14 AWG cable connects the Power Output of the P120 unit to electrical equipment with Barrel-type receptacle Power Input port, such as ThinkRF RTSA products.

  • Page 12: Connecting P120 And Cables

    Setting Up the P120 Connecting P120 and Cables Follow the steps in this section to connect the P120 and the cables. The diagram bellow illustrates the setup steps, starting from right to left. The circled numbers shown in the diagram refer to the particular steps of the setup instruction.

  • Page 13: Operation Consideration And Maintenance

    Caution: If the Power Input cable with loose leads is used, first remove the red lead, follow by the black lead. Again, this disconnection order is important. The next figure is an example setup of the P120 with loose lead stranded at the input end and LEMO connector at the output.

  • Page 14: Hardware Reference

    Hardware Reference This section provides physical and electrical specifications, and connectors reference for the P120. P120 Specifications The following table outlines the physical and electrical specifications for the P120 unit only, with no other cables attached. Description Design Specification Dimensions (W x L x H) 5.16 x 2.44 x 1.34 in.

  • Page 15: Document Revision History

    Document Revision History Document Revision History This section summarizes document revision history. Document Release Revisions and Notes Version Date v1.0 May 15, 2018 First release V1.1 Mar 6, 2019 Typo Correction ThinkRF P120 Vehicular Power Conditioner - User's Guide v1.1...
