SURE-LITES
Installation Instructions For FBP-2-40H
IMPORTANT SAFEGUARDS
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS
BE OBSERVED INCLUDING THE FOLLOWING:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
2. Do not use outdoors.
3. Do not mount near gas or electric heaters.
4. Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized
personnel.
5. The use of accessory equipment not recommended by Sure-Lites may cause an unsafe condition.
6. Do not use this equipment for other than its intended purpose.
SAVE THESE INSTRUCTIONS
7.
Step 1. To prevent high voltage from being present on the output leads (red and yellow), do not join the battery connector until installation is complete and
AC power is supplied to the emergency ballast.
Step 2. This product is for use with 17W through 215W single and bipin fluorescent lamps, including standard, energy saving, HO, VHO, circline, U-shaped
and rapid-start long compact and 18W through 28W 4-pin compact fluorescent lamp(s) without integral starters.
Step 3. Make sure all connections are in accordance with the National Electrical Code and any local regulations.
Step 4. To reduce the risk of electrical shock, disconnect both normal and emergency power supplies and battery connector of the emergency ballast
before servicing.
Step 5. This emergency ballast is for factory or field installation in either the ballast channel or on top of the fixture..
Step 6. This product is for use in indoor fixtures except air handling heated air outlets, and wet, damp or hazardous location fixtures.
Step 7. An unswitched AC power source is required. (120 or 277 volts).
Step 8. Do not attempt to service the battery. A sealed, no-maintenance battery is used that is not field replaceable. Contact the manufacturer for
information on service.
Step 9. Servicing should be performed by qualified service personnel.
®
LISTED
SURE-LITES 1121 Highway 74 South Peachtree City, GA 30269
CONTAINS NICKEL-CADMIUM
RECHARGEABLE BATTERY.
MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
5/98
024000085
Advertisement
Table of Contents
Related Manuals for Sure-Lites FBP-2-40H
Summary of Contents for Sure-Lites FBP-2-40H
-
Page 1: Important Safeguards
4. Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel. 5. The use of accessory equipment not recommended by Sure-Lites may cause an unsafe condition. 6. Do not use this equipment for other than its intended purpose. - Page 2 INSTALLATION WARNING: TO PREVENT HIGH VOLTAGE ON RED & YELLOW OUTPUT LEADS PRIOR TO INSTALLATION, BATTERY CONNECTOR MUST BE OPEN. JOIN BATTERY CONNECTOR AFTER INSTALLATION, AND AFTER AC POWER IS TURNED ON. NOTE: Make sure that the necessary branch circuit wiring is available. An unswitched source of power is required.
- Page 3 ADDITIONAL WIRING DIAGRAMS-1 LAMP EMERGENCY OPERATION DETERMINE APPROPRIATE DIAGRAM USING NUMBER AND COLORS OF AC BALLAST LEAD WIRES 14A. 4-LAMP INSTANT START 2A. 1-LAMP RAPID START TO UNSWITCHED AC TO UNSWITCHED AC BLUE BLACK BLUE ORANGE BLACK BLUE BLUE ORANGE 277V USE PROPER TAP 277V...
- Page 4 WIRING DIAGRAMS 1-LAMP EMERGENCY OPERATION EMERGENCY BALLAST AND AC BALLAST MUST BE FED FROM THE SAME BRANCH CIRCUIT TYPICAL SCHEMATICS ONLY. MAY BE USED WITH OTHER BALLAST. CONSULT THE FACTORY FOR OTHER WIRING DIAGRAMS B. TWO (2) LAMP RAPID START BALLAST A.
- Page 5 ILLUSTRATION 5 TROFFER STYLE FIXTURE STRIP STYLE FIXTURE Fixture Fixture Emergency Leads to Charging Indicator Light Ballast Ballast Indicator Indicator Channel Light Light 7/8" Bushing Cover Inserted into 7/8" Punch Ballast Channel Cover Plastic Tubing 1/2" White Bushing (cut to necessary 1/2"...
- Page 6 ADDITIONAL WIRING DIAGRAMS-2 LAMP EMERGENCY OPERATION NOTE: WIRING DIAGRAMS (THIS SIDE) ONLY FOR EMERGENCY BALLASTS RATED FOR 2-LAMP EMERGENCY OPERATION. CHECK UNIT LABEL TO DETERMINE NUMBER OF LAMPS THAT CAN BE OPERATED IN EMERGENCY. DETERMINE APPROPRIATE DIAGRAM USING NUMBER AND COLORS OF AC BALLAST LEAD WIRES. 3B.
