CX82320
ADSL USB Endpoint
Windows Driver
User Guide (Preliminary)
REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM
Doc. No. 100430A
January 21, 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CX82320 and is the answer not in the manual?

Questions and answers

Related Manuals for Conexant CX82320

Summary of Contents for Conexant CX82320

  • Page 1 CX82320 ADSL USB Endpoint Windows Driver User Guide (Preliminary) REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM Doc. No. 100430A January 21, 2002...
  • Page 2 Conexant products are not intended for use in medical, lifesaving or life sustaining applications. Conexant customers using or selling Conexant products for use in such applications do so at their own risk and agree to fully indemnify Conexant for any damages resulting from such improper use or sale.

  • Page 3: Table Of Contents

    CX82320 ADSL USB Endpoint Windows Drivers User Guide Contents Introduction ..........................1-1 Overview ..............................1-1 Scope................................1-1 Audience ..............................1-1 Document Structure ..........................1-1 System Requirements..........................1-2 Reference Documents ..........................1-2 Installation and Setup......................2-1 Installation ..............................2-1 2.1.1 Installing the ADSL USB Endpoint ....................2-1 2.1.2 Installing the Windows Driver......................2-1 2.1.2.1...

  • Page 4: Introduction

    1.2 Scope This document provides the descriptions of the procedure to install and uninstall the Windows USB driver for the CX82320 ADSL USB Endpoint and the usages of the Web configuration pages. Given the EEPROM has stored the USB device, configuration, interface, and endpoint descriptors, the Conexanat propreitary DOS-based EEPROM Programming Utility does not introduce in this document.

  • Page 5: System Requirements

    Windows driver. Chapter 2, Software Installation and Configuration, describes how to install, and uninstall the Conexant Windows driver. Chapter 3, Provide the descriptions and usages for CX82320 ADSL USB Endpoint’s Web configuration pages. 1.5 System Requirements •...
  • Page 6 CX82320 ADSL USB Endpoint Windows Drivers User Guide This page is intentionally blank. Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...

  • Page 7: Installation And Setup

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 2 Installation and Setup 2.1 Installation 2.1.1 Installing the ADSL USB Endpoint The ADSL USB Reference Board can be connected to any available USB port connector on the MACHINE. There are no option switches for the user to set. Once the board is connected to the USB port and the driver software has been installed, connect the DSL line input to the DSL RJ11 jack on the card.
  • Page 8 CX82320 ADSL USB Endpoint Windows Drivers User Guide 3. The Found New Hardware Wizard will prompt for the device drivers. Select the Search for a suitable driver for my device option. Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...
  • Page 9 5. If Windows does not find the drivers automatically, a Wizard prompt will appear. 6. Browse to the CD and select the appropriate driver. Click Open. Note: Choose CxE2CB06.inf for CX82320 ADSL USB Endpoint; choose CxE2CB05.inf for CX82110 ADSL products...
  • Page 10 CX82320 ADSL USB Endpoint Windows Drivers User Guide 7. When the appropriate driver is found, select OK to continue. Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...
  • Page 11 CX82320 ADSL USB Endpoint Windows Drivers User Guide 8. If a Digital Signature Not Found screen is displayed, select Yes to continue. Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...

  • Page 12: Uninstalling The Windows Driver

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 9. When the installation is complete, use the Network Neighborhood (for Windows 9x) or My Network Places properties to configure the network settings as defined by the local service provider. 2.1.3 Uninstalling the Windows Driver The Windows Add/Remove Programs function found on the Windows Control Panel should be used to initiate the uninstall process for INF installations.
  • Page 13 CX82320 ADSL USB Endpoint Windows Drivers User Guide Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...
  • Page 14 CX82320 ADSL USB Endpoint Windows Drivers User Guide This page is intentionally blank. Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...

  • Page 15: Web

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3 Web page configurations 3.1 Login 1. Launch the Web browser. 2. Enter the USB port default IP address http://10.0.0.2. 3. Entry of the username and password will be prompted. Enter the default login User Name and Password.
  • Page 16 CX82320 ADSL USB Endpoint Windows Drivers User Guide Firmware Version: This field displays the Conexant firmware (vxworks.z) version number. Showtime Firmware Version: This field displays the Conexant ADSL data pump firmware version number. Customer Software Version: This field displays the customer’s own firmware version number and it is based on revision.txt.

  • Page 17: Adsl Status Page

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.2.2 ADSL Status Page The ADSL Status page shows the ADSL physical layer status. ADSL Line Status: This field displays the ADSL connection process and status. ADSL Modulation: This field displays the ADSL modulation status for G.dmt or T1.413.
  • Page 18 CX82320 ADSL USB Endpoint Windows Drivers User Guide SNR Margin: Amount of increased noise that can be tolerated while maintaining the designed BER (bit error rate). The SNR Margin is set by Central Office DSLAM. If the SNR Margin is increased, bit error rate performance will improve, but the data rate will decrease.

  • Page 19: Lan Page

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.2.3 LAN Page The LAN page shows the information and status of LAN port, DHCP client table, and USB link. LAN: These fields display the IP address, Subnet Mask and MAC address for the LAN interface.

  • Page 20: Ppp Page

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.2.4 PPP Page The PPP Status page shows the status of PPP for each PPP interface. PPP: These fields display the Connection Name (user defined), Interface (PVC), Mode (PPPoE or PPPoA), Status (Connected or Not Connected), Packets Sent, Packets Received, Bytes Sent and Byte Received.

  • Page 21: Configuration

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.3 Configuration Pages The links under Configuration column are associated to the pages that represent the configurations of system and interfaces. Note: When the configurations are changed, please go to the Save Settings page to save the new setting and reboot the board.

  • Page 22: Atm

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.3.1.1 ATM Service Category: UBR and CBR are supported from the ATM. Bandwidth: Bandwidth setting takes effect only when the CBR is selected. The maximum available bandwidth is from the upstream data rate of ADSL status page (see Section 3.2.2, ADSL).

  • Page 23: Ppp Configuration

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.3.1.3 PPP Configuration Service Name: The service name of PPP is required by some ISPs. If the ISP does not provide the Service Name, please leave it blank. Disconnect Timeout: The Disconnect Timeout allows the user to set the specific period of time to disconnect from the ISP.

  • Page 24: Lan Configuration

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.3.2 LAN Configuration The LAN configuration page allows the user to set the configuration for the LAN port. LAN IP Address & Subnet Mask: The default is 10.0.0.2 and 255.0.0.0. User can change it to other private IP address, such as 192.168.1.2, and 255.255.255.0.
  • Page 25 CX82320 ADSL USB Endpoint Windows Drivers User Guide The Conexant firmware supports the DNS proxy function. For the DHCP requests from local machine, the DHCP server will set the LAN port IP as the default DNS server. Thus, all DNS query messages will come into LAN port first. The DNS proxy on the ADSL USB endpoint recorded the available DNS servers, and forward DNS query messages to one of DNS server.

  • Page 26: Save Settings

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.3.4 Save Settings The Save Settings page allows the user to save the new configuration to the flash and reboot the system. When the configurations are changes via the Web pages, the new settings need to be saved into the flash, so it is necessary to go to this Save Settings page to save and reboot the system for the changes to be taken effect.

  • Page 27: Admin Privilege

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4 Admin Privilege The links under Admin Privilege are only to be accessed and configured, when it is login with administrator login name and password. 3.4.1 WAN Status The WAN Status page shows the information and status of WAN Connection.
  • Page 28 CX82320 ADSL USB Endpoint Windows Drivers User Guide Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...

  • Page 29: Tcp Status

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.3 TCP Status The TCP Status page shows the statistics for all TCP connections. Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...

  • Page 30: Adsl Configuration

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.4 ADSL Configuration The ADSL Configuration page allows the user to set the configuration for ADSL protocols. Trellis: This field allows the user to enable or disable the Trellis Code. By default, it is always enabled.

  • Page 31: Admin

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.5 Admin The Admin Password Configuration page allows the user to set the password for administrator. The Admin password is same pas the FTP password, so it must has at least 8-characters for the FTP to work.

  • Page 32: User

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.6 User The User Password Configuration page allows the user to set the password for the user. 3.4.7 Miscellaneous Configuration The Miscellaneous Configuration allows the user to set all the miscellaneous configurations.
  • Page 33 CX82320 ADSL USB Endpoint Windows Drivers User Guide HTTP Server Access: This field allows the user to configure the Web pages can be accessed from. All: When this field is checked, it allows both WAN and LAN access to the Web pages.

  • Page 34: Reset To Factory Default

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.8 Reset to Factory Default The Reset to Factory Default page allows the user to reset the modem to original factory default configuration (factory.reg). Conexant 100430A REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...

  • Page 35: Diagnostic Test

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.9 Diagnostic Test The Diagnostic Test page shows the test results for the connectivity of the physical layer and protocol layer for both LAN and WAN sides. Testing USB Connection: This test checks the USB interface connection.
  • Page 36 Ping Primary DNS: This test checks the primary DNS can be reached through ping request. Query DNS for www.conexant.com: This test checks the host name can be resolved to IP address though domain name servers Ping www.conexant.com: This test checks the specified host can be reached through ping request.

  • Page 37: System Log

    CX82320 ADSL USB Endpoint Windows Drivers User Guide 3.4.10 System Log The System Log page shows the events triggered by the system. Clear Log: This field allows the user to clear the current contents of the System Log. Save Log: This field allows the user to save the current contents of the System Log by right click HERE and select “Save Target As”...
  • Page 38 CX82320 ADSL USB Endpoint Windows Drivers User Guide The System Log records: • DSL Layer − DSL Link detected − DSL Link connected − DSL Link disconnected • ATM Layer − ATM detected − ATM connected − ATM disconnected −...
  • Page 39 CX82320 ADSL USB Endpoint Windows Drivers User Guide This page is intentionally blank. Conexant 100430A 3-13 REVIEW COPY- NOT RELEASED - 9/10/02 6:13 PM...
  • Page 40 FCC Statement This device complies with part 15 pg the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 41 NOTES...
  • Page 42 LAST PAGE – SALES OFFICES (Added to the PDF file during document release)
