Summary of Contents for AUTHOR Alarm OBD Block
- Page 1 OPERATING MANUAL...
- Page 2 version 709.1...
-
Page 3: Table Of Contents
One of the ways to hijack a car is to make an unauthorized access to a diagnostic outlet and hack standard sofware aimed to bypass the anti-theft system. OBD BLOCK system is designed to prevent the diagnostic outlet from the unauthorized access. System benefts OBD BLOCK key benefits: •... -
Page 4: Operation Description
Operation description OBD BLOCK is comprised of a key (hereafer “adapter”) and a two channel digital relay. When the adapter is connected to the standard OBD-II outlet, the system checks compliance of a digital key and a digital relay. When the correct key is detected, the relay closes and the OBD-II outlet connection link recovers. -
Page 5: Check
F. Blue. DC- output to HP locking (0,25A max). G. It is required to check the connecton to earth/ground on this outlet (5 pin). If earth/ground is not connected, do it individually. Check Afer connecting the digital relay, check the interruption of a diagnostic line with diagnostc equipment. -
Page 6: What Is Included
(with an adapter in OBD-II) ........21 mА Maximum current in a blocked chain (D-E) to each channel ..............1 А Maximum current of the output to locking ..0,25 А What is included? OBD BLOCK adapter 1 pcs Digital relay 1 pcs Operatng manual... -
Page 7: Warranty Certificate
WARRANTY CERTIFICATE Warranty is 12 months from the date of the purchase. During this period technical support and maintenance are guaranteed for free. The warranty does not apply to the items with: • mechanical damage, burnt and char pieces, components, conductive tracks etc.;... - Page 8 Supported Cars List App.
