These Supplementary Instructions explain where the descriptions will differ from those in the Operating Instructions
and Reference Manual.
n Supplied Accessories
l Product Recovery DVD-ROM Windows
l The tether described in the Operating Instructions is not included.
The tether below is included.
• Tether . . . . . . . . .
The other accessories are included as described in the Operating Instructions.
CAUTION
l Do not pull the tether with excessive force. The stylus may hit the computer, person's body or other objects when
released.
n Using the Handle, Hand Strap, and Put up Hinge
Handle
When carrying the computer, close the Put up Hinge and
use the Handle.
CAUTION
l Do not loosen or remove the screws that secure the handle, hand strap, and Put up Hinge.
l Prior to use, make sure the screws are not loose.
n Connectors
Left side
SIM Card slot is equipped.
SUPPLEMENTARY INSTRUCTIONS
®
7 Professional SP is not included.
Hand Strap
Put up Hinge
Personal Computer
Model No.
To use the computer while standing, put your hand
between the computer and the hand strap to prevent it
from falling, and firmly hold the computer.
Right side

CF-D1DW2
series

Advertisement

loading

Related Manuals for Panasonic CF-D1DW2 Series

Summary of Contents for Panasonic CF-D1DW2 Series

  • Page 1 SUPPLEMENTARY INSTRUCTIONS Personal Computer CF-D1DW2 Model No. series These Supplementary Instructions explain where the descriptions will differ from those in the Operating Instructions and Reference Manual. n Supplied Accessories ® l Product Recovery DVD-ROM Windows 7 Professional SP is not included. l The tether described in the Operating Instructions is not included.

  • Page 2: Battery Recalibration

    When performing Hard Disk Recovery • No function l Outside of Hard Disk Recovery • When pressed : Start or exit Dashboard for Panasonic PC • When held down : No function You can use Setup Utility. You can use [Tablet PC Setting] (under [Control Panel] - [Hardware and Sound]) to change function assignment to the button.

  • Page 3: Reinstalling Software

    Turn on the computer, and click [Click for Enter Setup] on the screen while [Panasonic] boot screen is displayed. The Setup Utility starts up. If the [Panasonic] boot screen is not displayed, as soon as the computer starts up, press several times until the Setup Utility screen appears.
  • Page 4 l [Reinstall to the System and OS partitions.] Select this option when the hard disk has already been divided into several partitions. For how to create a new partition, refer to “To change the partition structure” ( Operating Instructions). You can keep the partition structure. This does not appear if Windows cannot be reinstalled to the partition containing boot files and the area usable by Windows.

  • Page 5: Specifications

    , Battery Recalibration Utility, Aptio Setup Utility, Hard Disk Data Erase Utility , PC Diagnostic Utility, Quick Boot Manager, Dash- board for Panasonic PC, Display Rotation Tool, Tablet Button Manager, Hotkey Appendix, Power Plan Extension Utility, Hand Writing Others Same as CF-DA series ( Operating Instructions “Specifications”)
  • Page 6 Even when the AC adaptor is not connected to the computer, power is consumed (Max. 0.3 W) simply by having the AC adaptor plugged into an AC outlet. Rated power consumption. 3-E- Operations of this computer are not guaranteed except for the pre-installed OS. Must be installed before use. Perform on the recovery partition. © Panasonic Corporation 0 PS0-0 PCE03A_XP/7...
