Emerson InSinkErator DS200 Quick Installation And Care Manual page 2

Installation
instructions
Measurements (mm)
95
50
55 24
322
242
175
300 ml
54
Tools needed
32mm
/ 1 1/4"
Ø24-27mm
IMPORTANT SAFETY INFORMATION
Indicates a hazardous situation
CAUTION
!
which could result in injury.
Indicates a situation which
NOTICE
could damage the product.
WHAT'S IN THE BOX
95
A
G
H
B
D
65 C
E
F
A Nozzle D Washer & Nut G Straw
B Holder E Stem H Bottle
C Gasket F Adaptor
STEP 1
Handle
power tools
! CAUTION
with care
NOTICE
Check all measurements
before drilling and ensure
the dispense nozzle wil
hang over the sink after
installation.
24-27
Ø
STEP 2
Insert straw
into nozzle
STEP 4
Place holder
and stem into
hole in sink top
STEP 6
Tighten
adaptor
onto
bottle
STEP 8
Fill bottle
55mm
with
max
detergent
Care for your product
STEP 3
Remove
washer &
nut from
stem
Remove
adaptor
from stem
STEP 5
NOTICE
NOTICE
Tighten stem with
washer & nut.
STEP 7
Only clean with soft materials
NOTICE
Tighten
bottle
onto stem
download detailed instructions
STEP 9
Place dispenser
nozzle onto holder
NOTICE
Only fi ll with
household detergents
Scan the QR code to
in your language
