- Page 1 5J0xxx / DM-070xxxx OPI-4012 Wireless 1D/2D Imager Instruction Manual （Tentative） OPTOELECTRONICS Co., Ltd. This specification is subject to change at any time without prior notice...
- Page 2 Thank you for purchasing the OPI-4012 wireless imager scanner. Please read this instruction manual carefully before handling this product. This instruction manual provides safety and operating instructions for the OPI-4012. Specifications and additional detailed settings are available in the OPI-4012 Master Specifications and the Universal Menu Book.
-
Page 3: Table Of Contents
Table of Contents 1. Precautions for Your Safety......................3 2. Handling Precautions ........................6 3. Package Contents ........................8 4. Detailed View..........................9 5．Getting Started..........................11 6．Scanning Barcodes........................13 7．Wireless Communication......................14 8．How to Configure the Wireless Communication Settings............. 18 9．Default Settings .......................... -
Page 4: Precautions For Your Safety
1. Precautions for Your Safety For your own safety, read these procedures carefully before using this product. After reading this document, keep it accessible for future reference. This instruction manual includes the following symbols and markings to help you use this product properly and safely. - Page 5 ■ About the Scanner DANGER Do not use this device near flammable substances (such as gas and explosives). Prohibited WARNING Do not throw this device into a fire. Doing so may cause the battery case to burst, resulting in injury or possibly acting as an accelerant for the fire. Prohibited Do not insert foreign substances into the device.
- Page 6 CAUTION Do not drop this device or set it on an unstable surface from which it could fall. Prohibited Do not open the battery case lid in the area where battery is likely to contact with water. Do not expose the battery pack to liquids or allow the battery contacts to get wet. Prohibited ■...
-
Page 7: Handling Precautions
Conditions of the device, which the OPI-4012 is connected to, may also affect the communication speed and communication range of the OPI-4012. ・ There is a Bluetooth antenna embedded to the OPI-4012. An extreme contact with a metal object may affect the performance of the antenna. - Page 8 If you have any questions or troubles, please contact our marketing group. ・ OPTOELECTRONICS Co., Ltd. shall not be held responsible for any accidental data losses or data damages which may occur by defects or accidents.
-
Page 9: Package Contents
3. Package Contents The package contents are listed as below. Please confirm that you have the following items before getting started. - 1 scanner (OPI-4012) with an embedded battery pack - 1 hand strap - 1 copy of Instruction manual - 1 dedicated AC adapter The number of accessories may differ depending on the product specification. -
Page 10: Detailed View
4. Detailed View 4.1 OPI-4012 (Scanner) Part Function 1. Serial Label 2. Certification Label A certification label for wireless communication technology 3. Trigger Switch To scan and decode a barcode, you need to press the trigger switch. The scanner emits a laser beam through the optical window while scanning a 4. - Page 11 4.2 CHG-4001 (Dedicated cradle for the OPI-4012, optionally sold) Name Functions 1. Serial Label 2. Electrical Terminal ( ＋) Charging terminals are used to supply power to the scanner from a dedicated cradle (CHG-4001). 3. Electrical Terminal ( ―) 4. DC Jack Connect a dedicated AC adapter.
-
Page 12: 5．Getting Started
About the OPI-4012 The OPI-4012 scanner is set to low power mode by default. Please press and hold down the trigger switch for a while to activate the scanner. The scanner will not operate if the main battery is empty. Please charge the main battery using a dedicated AC adapter before getting started. - Page 13 Charging the scanner (its main battery) on the CHG-4001 cradle Scanner on the cradle Concave (凹) Electrical contacts Switch for terminal detection Replacing battery <Removing battery> <Placing battery>...
-
Page 14: 6．Scanning Barcodes
6．Scanning Barcodes During a scan, the green LED patterns shown below will be visible. These patterns assist you in aiming the scanner; they are superimposed on the illuminated scan field. The aiming patterns are only a guide. They do not indicate exact scannable width or distance between a scanner and a barcode. -
Page 15: 7．Wireless Communication
7．Wireless Communication 7.1 Wireless Specifications ・ The OPI-4012 communicates using Bluetooth (Ver 2.0) wireless communication technology. The OPI-4012 supports SPP (serial port profile) and communicates with other Bluetooth devices which support the same profile. ■ Protocol Stack RF (Radio Frequency Protocol) - Page 16 ■ ACK/NAK Timeout Settings ■ Bluetooth Device Address Settings ・ Carry out Bluetooth device address settings to identify the Bluetooth device to which the OPI-4012 will be connected. ・ Refer to the Bluetooth device address label attached to the Bluetooth device. Find appropriate menu barcodes to scan the 12-digit address.
- Page 17 ■ Handshaking Settings ・ You can set the handshaking for the communication between the host and the scanner. ・ When it is set to “No handshaking”, the reliability of the transmitted data will be lower. It is recommended to enable ACK/NAK. ACK/NAK No Response ACK/NAK ■...
- Page 18 The scanner will not carry out the scanning operation if the data memorizing setting is disabled. Auto reconnect feature will operate in every 20 seconds. ■ Trigger Connection ・ You can set the scanner to connect or disconnect by pressing down the trigger key for the set duration.
-
Page 19: 8．How To Configure The Wireless Communication Settings
8．How to Configure the Wireless Communication Settings 8.1 Connect without Authentication 1. Use the universal menu book to set the scanning options and read options of the scanner. ・ This operation will not be necessary if you would like to use the scanner with the default settings. 2. - Page 20 8.2 Connect with Authentication 1. Use the universal menu book to set the scanning options and read options of the scanner. ・ This operation will not be necessary if you would like to use the scanner with the default settings. 2.
- Page 21 ■Notes ・ The scanner does not scan any barcodes other than menu barcodes before it is connected to the Bluetooth device. (If the [BM1] settings are configured, the scanner will scan other barcodes.) ・ If you scan a 12-digit barcode label before connecting the scanner to the Bluetooth device, the scanner will acknowledge the 12-digit barcode as a Bluetooth device address.
-
Page 22: 9．Default Settings
9．Default Settings * Refer to the Product Specification Manual and the Universal Menu Book for the readable codes. 9.1 Default Settings 1: Readable Codes Transmit Suffix Transmit Calculate Transmit Prefix Code type Reading code setting other settings length UPC-A ○ ×... - Page 23 9.1 Default Settings 1: Readable Codes (continued) Transmit Transmit Calculate Transmit Prefix Suffix Code type Reading code length other settings settings RSS-14 Standard Truncated ○ × × ○ － Stacked Stacked Omni-directional RSS Limited ○ × × ○ － Standard ○...
-
Page 24: 10．Menu Barcodes
Setting Encryption Disabled 10．Menu Barcodes This section contains the menu barcodes of the OPI-4012 default settings. Other menu labels are listed in the Universal Menu Book, such as Code options, String options, Read options, and Indicator options. 10.1 Setting Method There are two ways to configure the settings: Setting 1. - Page 25 <Menu Barcodes>...
- Page 26 <Bluetooth Options > CODE39 labels QR code label _Z7_ _CNPC_ CNPC Connect to PC Connect to _CNCR_ CNCR Connect to Cradle _ZZ_ CODE39 labels QR code label _ZZ_ _BDAS_ Set Bluetooth BDAS address Bluetooth address setting _BDAE_ End Bluetooth BDAE address _ZZ_...
- Page 27 Barcode for Bluetooth address setting _Q0_ _Q9_ _Q1_ _0A_ _Q2_ _0B_ _Q3_ _0C_ _Q4_ _0D_ _Q5_ _0E_ _Q6_ _0F_ _Q7_ _Q8_ Flow : ［ZZ］⇒［BDAS］⇒［12Digit Bluetooth address］⇒［BDAE］⇒［ZZ］ In case reading wrong address, restart from reading ［BDAS］...
- Page 28 CODE39 labels QR code label _ZZ_ _AUTE_ AUTE Enable Authentication _AUTD_ AUTD Disable _ZZ_ CODE39 labels QR code label _ZZ_ _ENCE_ ENCE Enable Encryption _ENCD_ ENCD Disable _ZZ_...
- Page 29 CODE39 labels QR code label _ZZ_ _PINS_ PINS Set PIN code setting _Q0_ _Q1_ _Q2_ _Q3_ _Q4_ PIN code _Q5_ _Q6_ _Q7_ _Q8_ _Q9_ _PINE_ PINE End PIN code setting _ZZ_...
- Page 30 _ZZ_ <Connection／Disconnection> _+-CONN-+_ Manually connect +-CONN-+ _+-DISC-+_ Manually disconnect +-DISC-+ <Default (Interface)> CODE39 labels QR code label _ZZ_ _SO_ Default _ZZ_ OPTOELECTRONICS Co., Ltd. OPI-4012 Instruction Manual 12-17, Tsukagoshi 4-chome, Warabi, Saitama 335-0002 Japan Marketing Group TEL: +81-48-446-1183 FAX: +81-48-434-2820...
- Page 31 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
