Summary of Contents for EZ Life Systems KateZ Lift
- Page 1 User Manual Dealer: This manual must be given to the user of the KateZ Lift. User: Before using KateZ Lift, read this manual and save for future reference.
-
Page 2: Warnings
WARNING! A qualified technician must perform the initial set up of this KateZ Lift. Do not use your KateZ Lift without first completely reading and understanding the instructions in this manual. If you are unable to understand the warnings, cautions or instructions, contact your dealer before attempting to use this equipment - otherwise, injury or damage may occur. -
Page 3: Table Of Contents
EZ Life Systems: KateZ Lift User Manual Table of Contents Warnings ............................... 2 Table of Contents ............................3 Important Safety Precautions ........................4 Safety/Handling ............................6 Operation ..............................8 Care and Maintenance ..........................16 Troubleshooting ............................17 Limited Warranty ............................18 Patent Pending ............................ -
Page 4: Important Safety Precautions
Weight Limitations The KateZ Lift has a weight limitation of 250 lbs above and beyond the weight of the wheelchair. WARNING! Adding accessories or a different seat will increase the weight of your wheelchair. - Page 5 EZ Life Systems: KateZ Lift User Manual Lift Stability KateZ Lift must be used on stable ground. Although sensors will prevent the lift from raising on unstable ground, never use the lift on a slope greater than 5°.or uneven surfaces, on slick or wet surfaces, or surfaces prone to shifting (such as gravel or sand).
-
Page 6: Safety/Handling
5°.or uneven surfaces, on slick or wet surfaces, or surfaces prone to shifting (such as gravel or sand). Using the KateZ Lift on unstable ground may adversely affect the stability of the wheelchair, resulting in serious bodily injury to the user and passenger and damage to the wheelchair and surrounding property. - Page 7 EZ Life Systems: KateZ Lift User Manual • Reaching, leaning backwards - WARNING! DO NOT lean over the top of the back upholstery to reach objects behind you, as this may cause the wheelchair to tip over. Position wheelchair as close as possible to the desired object. Reach back only as far as your arm will extend without changing your sitting position.
-
Page 8: Operation
DO NOT attempt to stop a moving wheelchair with wheel locks. Wheel locks are not brakes. • DO NOT attempt to lift the wheelchair by the KateZ Lift. This may result in injury to the user or damage to the KateZ Lift. - Page 9 EZ Life Systems: KateZ Lift User Manual This illustration describes the features of your KateZ Lift. Carefully review the function and location of each item described. [Figure 4. Rear view of KateZ Lift] Hand Control Battery Quick Release Handle Control Box...
- Page 10 EZ Life Systems: KateZ Lift User Manual Battery Battery charging guidelines: • WARNING! You must recharge the 24 volt battery with the recommended battery charger. Do not use a non-authorized battery charger. • MANDATORY! Read the battery charging instructions in this manual before charging the battery.
- Page 11 EZ Life Systems: KateZ Lift User Manual Checking battery charge: • Press and release the rear gray flat button for a LED color indication of the battery level. o Green means there is full charge. o Yellow means there is a good charge.
- Page 12 EZ Life Systems: KateZ Lift User Manual Battery or battery charger replacement instructions: To purchase a new 24 volt battery or battery charger, contact your authorized dealer. Battery Recommendations • Replace the battery every year. • Recharge the battery each night if the light is not green.
- Page 13 PROHIBITED! Make sure area under the KateZ Lift is clear of obstructions, including pets and small children while in operation. • WARNING! Do not use the KateZ Lift next to any table or object that may prevent the KateZ Lift from reaching its full height and potentially pinch or squeeze the user. •...
- Page 14 To raise your wheelchair: • Push the blue button down until the KateZ Lift reaches the desired position or maximum height. To lower your wheelchair: • Push the red button down until the KateZ Lift reaches the desired position or minimum height.
- Page 15 Tilt switch operation Your KateZ Lift is equipped with an internal tilt switch located inside the housing that prevents the chair from tilting more than 5°. If you are lifting the wheelchair when the tilt switch engages, you will hear a beep and the wheelchair will stop rising.
-
Page 16: Care And Maintenance
General cleaning guidelines: • The KateZ Lift can be hand washed with soap and water. However, automatic drive-through car washes should be avoided as they may interfere with and cause damage to the KateZ Lift. Maintenance schedule: • Replace the battery every year. -
Page 17: Troubleshooting
Why? A battery with a low charge will keep chair from rising. 4. Fully engage quick release pins. Why? KateZ Lift will not rise if the pins are not fully engaged. 4. Other If none of the solutions above solves the issue, call the dealer. -
Page 18: Limited Warranty
EZ Life Systems: KateZ Lift User Manual Limited Warranty EZ Life Systems (“Seller”) warrants that the KateZ Lift (“Goods”) will be free from defects in material and workmanship for 24 months beyond the date of sale/shipment (“Warranty”). Seller warrants its Goods only to the original buyer (“Buyer”). -
Page 19: Patent Pending
EZ Life Systems: KateZ Lift User Manual Patent Pending Seller shall have no liability for infringement of any patents, trademarks, copyrights, trade dress, trade secrets or similar rights except as specifically provided in this section. Any liability of Seller shall be limited as set forth in the Limited Warranty. - Page 20 EZ Life Systems: KateZ Lift User Manual EZ Life Systems 1351 Sibley Memorial Highway Mendota, MN 55150 Phone: 651-207-5634 www.ezlifesystems.com Last Updated 6/4/2012...
