Global PCS Inc.
SS0001
Bluetooth Access Point

User Guide

Version: 1.1.2
December 12, 2002
Document Number: BTAP-UM-0001
台揚企業集團
Global PCS Inc.
1, Innovation Road II
Hsinchu Science-Based Industrial Park
Hsinchu 300, Taiwan, R.O.C.
Phone: 886-35771155
Fax: 886-35772578
http://www.g-pcs.com.tw/
E-mail :
divg_sales@mti.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SS0001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Global PCS SS0001

  • Page 1: User Guide

    Global PCS Inc. SS0001 Bluetooth Access Point User Guide Version: 1.1.2 December 12, 2002 Document Number: BTAP-UM-0001 台揚企業集團 Global PCS Inc. 1, Innovation Road II Hsinchu Science-Based Industrial Park Hsinchu 300, Taiwan, R.O.C. Phone: 886-35771155 Fax: 886-35772578 http://www.g-pcs.com.tw/ E-mail :...

  • Page 2: Product Introduction

    G-PCS Bluetooth Access Point (SS0001) is a universal adapter for Ethernet, cable modem and xDSL. SS0001 provides the low cost solution for point-to-point/point to multi points links at a 2.4GHz band, which covers unlicensed band in worldwide comply Bluetooth Specification 1.1.

  • Page 3: Install Hardware

    Global PCS Inc. SS0001 User Guide 2. Install Hardware Global PCS Bluetooth Access Point x 1 6V Power Adapter Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 3 of 18...

  • Page 4: Network Setup

    Global PCS Inc. SS0001 User Guide 3. Network Setup SS0001 is setup and configured through an internal Web server. 3.1 Internet Explorer Setup You can connect to web server using any of the three methods, the default Access Point IP address is 1.1.1.1...
  • Page 5 When you click the “Change password” link, you can change the default password configuration as shown in figure 3.3. You must enter the old password and the new password, and figure 3.4 shows the result. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 5 of 18...
  • Page 6 Global PCS Inc. SS0001 User Guide Figure 3.3 Change Password Figure 3.4 Change Password Complete Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 6 of 18...
  • Page 7 Level 2 (Service-level enforced security): a device does not initiate security procedures before channel establishment at L2CAP level. Level 3 (Link-level enforced security): a device initiates security procedures before the link set-up at LMP level is completed. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 7 of 18...
  • Page 8 DNS address in Figure 3.6. Figure 3.7 shows the configuration you enter in figure 3.6. You can check the information you input. Figure 3.6 Network Configuration ( fixed IP address ) Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 8 of 18...
  • Page 9 (3.2.2) Network configuration (PPPoE): If you select PPPoE, you must input the PPPoE login ID and password. Figure 3.8 shows this situation and figure 3.9 shows the result. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 9 of 18...
  • Page 10 Global PCS Inc. SS0001 User Guide Figure 3.8 Network configuration (PPPoE) Figure 3.9 Network configuration Complete (PPPoE) Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 10 of 18...
  • Page 11 Global PCS Inc. SS0001 User Guide (3.2.2) Network configuration (DHCP): The configuration of DHCP is very easy, Figure 3.10 shows the result. Figure 3.10 Network configuration Complete (DHCP) Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 11 of 18...
  • Page 12 SS0001 User Guide 3.2 Other function of SS0001 SS0001 LAP provides a COM port interface, you must have a RS-232 line to connect between SS0001 and DT (Data Terminal). After DT creates a connection with COM port (usually using windows HyperTerminal), it can send some commands to control SS0001 through the created COM port.
  • Page 13 7 connections. Close the port: Close the server serial port for RFCOMM connection. (v) Close all server ports: Close the server serial port for all RFCOMM connection. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 13 of 18...
  • Page 14 Change LAP mode among general accessible mode, limit accessible mode, non-accessible mode and connectable mode only. (r) Change LAP role: Change LAP role as master or slave. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 14 of 18...
  • Page 15 Display debug message on hyper terminal or not. (h) Execute HCI command: Enter an HCI command to execute. (s) Enable PPP authentication or not: Authenticate ID and password for PPP connection or not. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 15 of 18...
  • Page 16 Global PCS Inc. SS0001 User Guide (p) Halt the PPP server: Stop the PPP service. PPP now is not available. (s) Shutdown PPP: Close all existing PPP connections. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 16 of 18...

  • Page 17: Important Note

    --Consult the dealer or an experienced radio/TV technician for help. The user should not modify or change this equipment without written approval form Global Pcs. Inc. Modification could void authority to use this equipment. Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential...
  • Page 18 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter." Dec. 10, 2002 Global PCS Inc., Proprietary and Confidential Page 18 of 18...
