- Page 1 MX-E750D MX-E751D MX-E760D MX-E761D MX-E770D MX-E771D DVD MINI COMPONENT SYSTEM user manual Imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register...
-
Page 2: Safety Warnings
Safety Information Safety Warnings TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates “dangerous voltage” This symbol indicates important CAUTION : TO PREVENT ELECTRIC SHOCK, inside the product that presents a risk of... -
Page 3: Cautions On Handling And Storing Discs
NOTE Do not allow the discs to become contaminated with dirt. Copyright Do not load cracked or scratched discs. © 2012 Samsung Electronics Co., Ltd. All rights Handling and Storing Discs reserved. Copy Protection If you get fingerprints or dirt on the disc, clean it with a mild detergent diluted in water and wipe with a soft cloth. -
Page 4: Table Of Contents
Icons that will be used in manual Disc Types and Characteristics Description Top Panel (MX-E760D/E761D/E770D/E771D only) Front Panel Rear Panel (MX-E750D/E751D/E760D/E761D) Rear Panel (MX-E770D/E771D) Remote control CONNECTIONS Connecting the Speakers Attaching the toroidal ferrite core to the Power cable (optional) -
Page 5: Getting Started
ADVANCED FUNCTIONS USB Function Recording Function OTHER INFORMATION Troubleshooting Language code list Specifications Getting Started Icons that will be used in manual Precautions • Ensure that the AC power supply in your house complies Make sure to check the following terms before with the identification sticker located on the back of your reading the user manual. product. • Install your product horizontally, on a suitable base (furniture), Icon Term Definition... -
Page 6: Disc Types And Characteristics
Getting Started Getting Started Do not use the following types of disc! Disc Types and Characteristics • LD, CD-G, CD-I, CD-ROM, DVD-ROM and Region Code DVD-RAM discs cannot be played on this product. If such discs are played, a <WRONG DISC The product and the discs are coded by region. - Page 7 CD-R JPEG Discs Supported Audio Formats • Only files with the "jpg" extensions can be played. Sampling Format Bit Rate Frequency • If the disc is not closed, it will take longer to start playing and not all of the recorded files may be played. 80~320kbps 44.1khz • Only CD-R discs with JPEG files in ISO 9660 or Joliet...
-
Page 8: Description
Getting Started Supported file Formats USB Devices that can be used with the Still Format Music Movie product Picture File name DivX • USB Storage Device, MP3 Player, Digital Camera File • Removable HDD .MP3 .WMA .WMV .AVI extension .JPEG - Removable HDDs equipped with less than 160 80~320 56~128... -
Page 9: Front Panel
18. USB 2 REC jack 19. USB 2 REC button • P ress this button to switch your mini-compact system. 20. OPEN/CLOSE button PARTY button (only for MX-E750D/MX-E751D) 21. USB 2 button LED LIGHTING button (only for MX-E760D/MX-E761D/ 22. ENTER button MX-E770D/MX-E771D) 23. -
Page 10: Rear Panel (Mx-E750D/E751D/E760D/E761D)
Getting Started Rear Panel (MX-E750D/E751D/E760D/E761D) 2.1 CH SPEAKER CONNECTOR TERMINALS Connect the front speakers. ONLY FOR SERVICE This jack is just for testing, please don't use it. MX-E760D/E761D VIDEO OUT JACK Only Connect your TV's Video Input jack (VIDEO IN) to the VIDEO OUT jack. -
Page 11: Remote Control
Remote control Tour of the Remote Control MUTE button POWER button FUNCTION button EQ button SOUND button DVD DISC SKIP * button TIMER/CLOCK button SLEEP button TIMER ON/OFF button TITLE MENU button DISC MENU button SYNC* button Number(0~9) button VOLUME - button VOLUME + button Skip, RDS PTY * button Search, RDS DISPLAY * button... -
Page 12: Connections
If this occurs, place the ◆ Right speaker (marked R) speaker away from your TV set. To achieve the correct sound quality, connect those speaker connector cables to the speaker connector terminals of the MX-E750D/E751D system. Position of the product Front Front Place it on a stand or cabinet shelf, or under the TV stand. -
Page 13: Attaching The Toroidal Ferrite Core To The Power Cable (Optional)
Connections Attaching the toroidal ferrite core to the Power cable (optional) Installing Toroidal ferrite to Power If you attach a Toroidal ferrite core to the Power cable, it will help to prevent RF interference from cable radio signals. 1. Pull the fixing tab of the Toroidal ferrite core to open 2. -
Page 14: Connecting External Components
Connections Connecting External Components AUX IN 1: Connecting an External Component/MP3 player Audio Cable AUDIO OUT (not supplied) Components such as an MP3 Player. 1. Connect AUX IN 1 (Audio) on the front of the product to the Audio Out of the external component/ MP3 player. -
Page 15: Connecting The Fm/Am(Optional) Antenna
Connections Connecting the FM/AM(optional) Antenna If this product does not receive AM broadcasts. FM Antenna (optional) 1. Connect the FM antenna (optional) to the FM Antenna jack. 2. Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a wall or other rigid surface. -
Page 16: Setup 16 Before Starting (Initial Setting)
Setup Before Starting (Initial Setting) Setting the Setup menu The access step may differ depending on the selected 1. Press the POWER button when it is plugged in menu. The GUI (Graphical User Interface) in this TV for the first time. manual may differ, depending on the firmware version. -
Page 17: Display
Display Audio Settings Display TV Aspect : WIDE DRC (Dynamic Range Compression) You can configure various display options such as Audio the TV Aspect. System Language This feature balances the range between the loudest Security and quietest sounds. You can use this function to TV Aspect Suppor enjoy Dolby Digital sound when watching movies at... -
Page 18: System
Setup System Security The Parental Lock function works in conjunction with Initial Setting DVDs that have been assigned a rating which helps you control the types of DVDs that your family watches. By using the Initial Setting, you can set language and There are up to 8 rating levels on a disc. -
Page 19: Basic Functions 19 Disc Playback
Basic Functions Disc Playback Audio CD(CD-DA)/MP3/WMA Playback 1. Press the OPEN/CLOSE button. 2. Place a disc gently into the disc Compartment with the disc's label facing up. 3. Press the OPEN/CLOSE button to close the Track01 disc Compartment. 1/17 ✎ NOTE Resume function: When you stop disc play, the product remembers where you stopped, so when... -
Page 20: Jpeg File Playback
Basic Functions JPEG File Playback Using the Playback Function Forward/Reverse Search Images captured with a digital camera or camcorder, or JPEG files on a PC can be stored on a CD and then played back with this product. dBAD 1. Insert a JPEG disc on the disc Compartment. 2. - Page 21 Step Motion Play Using the Title Menu For DVDs containing multiple titles, you can view the Press the PAUSE button title of each movie. repeatedly. 1. During playback, press and hold the • The picture moves forward one frame TITLE MENU button on the remote each time the button is pressed during control.
- Page 22 Basic Functions Repeat Playback A-B Repeat Playback dBAD You can repeatedly play back a designated section of a DVD or CD. DVD/DivX Repeat 1. During the DVD disc or CD playback, press the You can repeat the title, chapter or the section(A-B REPEAT button on the remote control.
- Page 23 Displaying Disc Information when there is more than one in the disc. For example, if there is more than one movie on a DVD, each movie will be identified as a Title. Chapter( ) : Most DVD discs are recorded in chapters so that you can quickly find a specific chapter.
-
Page 24: Sound Mode
Basic Functions Selecting the Subtitle Language Angle Function 1. Press the TOOLS button. This function allows you to view the same scene in different angles. 2. Press the ▲▼ buttons to select SUBTITLE ( ) display. 1. Press the TOOLS button. 3. - Page 25 DYNAMIC SPOT Mode ✎ NOTE You can directly select the Dynamic spot mode The equalizer is set to "OFF" automatically and for listening music. becomes not available during a CD recording. The EQ mode may be different depending on Press the DYNAMIC SPOT button your region.
-
Page 26: Mute Function
The Dimmer function The Dimmer function is selected and the display MX-E750D/E751D: darkens. PARTY 1 ; PARTY 2 ; PARTY 3 ; OFF LED OFF MX-E760D/E761D/E770D/E771D: The LED is turned off while the dimmer function is working. -
Page 27: Listening To Radio
Listening to Radio ✎ NOTE Using buttons on the Remote Control This applies only when listening to an FM station. 1. Press the FUNCTION button to select FM or This product may not support the AM function AM band. depending on your region. 2. -
Page 28: Setting The Clock
Basic Functions 3. Press the ENTER button. Setting the Clock Result: ON is displayed for a few seconds, you can set the timer switch-on time. For each step, you have a few seconds to set the 4. Set the timer switch-on time. required options. -
Page 29: Sleep Timer Function
Connecting the Microphone You can enjoy the feeling of a karaoke bar in the Selecting DVD/CD or USB will automatically change to TUNER if there is no disc or USB is inserted. comfort of your home. If the switch-on or -off time is the same as the timing Watch the video and sing along the lyrics displayed recording time, only the switch-on or -off time is on the TV screen against the accompaniment. - Page 30 Advanced Functions Recording Function USB Function Playing Media Files using the USB Host Feature You can record sound of the CD, the Radio Broadcasting or sound from the external source into You can enjoy media files such as pictures, movies the USB storage device.
- Page 31 To delete a file “CHECK FILE”“COPY xx” ; “COPY END” is You can delete a file on your USB device. displayed. When the recording is done, “STOP” will Play a file you want to delete. be displayed. If there is duplicating file name, "FILE EXIST" is Press the DELETE button on the main unit.
- Page 32 Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the unit, disconnect the power cord, and contact the nearest authorized dealer or Samsung Electronics Service Center. Symptom Check/Remedy I cannot eject the disc.
- Page 33 Other Information Symptom Check/Remedy • The product is not working. • While “NO DISC” message appears on the display of the product, press and hold the (Example: The power goes out or STOP (@) button on the main unit for longer than the front panel key doesn't work 5 seconds with no disc is inserted (reset function).
- Page 34 Input sensitivity (AUX)800 mV *: Nominal specification - Samsung Electronics Co., Ltd reserves the right to change the specifications without notice. - Weight and dimensions are approximate. - Design and specifications are subject to change without prior notice. - For information on the power supply and power consumption, refer to the label attached to the product.
- Page 35 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Area Contact Center Web Site Area Contact Center Web Site 0-800-555-555 0-88-555-55-55 8-10-800-500-55-500 0-800-61440...
- Page 36 Code No. AH68-02454B (Rev 0.0)
