Summary of Contents for Awarepoint S2
- Page 1 Awarepoint Sensor S2 Installation Manual Date: 02/14/2008 Document History Date Author Changes 02/14/2008 Derek Smith Initial Draft Awarepoint Corporation 225 Broadway, Suite 1670 San Diego, CA 92101 www.awarepoint.com ...
- Page 2 Copyright Copyright 2008 Awarepoint Corporation All rights reserved. This product or document is protected by copyright and distributed under licenses restricting its use, copying, distribution, and decompilation. No part of this product or document may be reproduced in any form by any means without prior written authorization of Awarepoint and its licensors, if any. Awarepoint, the Awarepoint logo, and Real‐time Awareness Solution, are trademarks or registered trademarks of Awarepoint Corporation in the United States and in other countries. FCC Compliance Awarepoint Sensor model S2 FCC ID: UAG‐S2 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this Device may not cause harmful interference and (2) this Device must accept any interference received, including Interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. CAUTION: This manual describes installation procedures for electrical equipment. Proper precautions are required. Particular attention should be given to text highlighted with the following symbol: Awarepoint Sensor S2 © 2008 Awarepoint Corporation Installation Manual...
-
Page 3: Table Of Contents
Physical Installation ................5 Secure Awarepoint Sensors ..............6 Verify the Sensor Connects to the Network ......... 6 Place Awarepoint Sensor on Map ............6 Troubleshooting ..................30 Awarepoint Sensor ................30 ... -
Page 4: Introduction
1. Small Ethernet switches (if necessary to plug in your laptop) 2. Hospital Grade Power Strips (if necessary to put an Awarepoint Sensor in an outlet that is full) 3. Installation Kit, consisting of the following: Serial Cable with Null Modem Adapter and F‐F Gender Changer Ethernet Cable Zip‐Ties Double‐Sided Tape Mounting Strips 4. Installation Tools, consisting of the following: Laptop Terminal emulator software (we recommend TeraTerm, available from http://www.tucows.com/preview/195282 ) USB to Serial adapter (if laptop does not have a serial port) Wire cutters – for trimming Zipties Insulated blade screwdriver – for electrical faceplates, if you make an error when taping the Awarepoint Sensors down Phillips screwdriver – for installing the Awarepoint Appliance 1.2.2 Information Prior to installation, you will need the following information: 1. Maps for all floors, in paper and electronic format with coverage area outlined 2. Awarepoint Bridge IP Addressing: DHCP or Static. If using Static addressing then: IP Address, Default Gateway, and Subnet Mask. IP Address of Awarepoint Appliance Awarepoint Sensor S2 © 2008 Awarepoint Corporation Installation Manual... -
Page 5: System Components
Location, with an Ethernet port that has been tested and configured to work with 10 Base‐T, full duplex Ethernet. ( A 10/100 autosense setting should be adequate) System Components The Awarepoint Real‐time Awareness Solution consists of several components as shown in the diagram below. The parts of the system that require installation include Awarepoint Tags, Awarepoint Sensors, Awarepoint Bridges, and the Awarepoint Appliance. The Awarepoint Appliance contains all software necessary for system operation. Figure 1-1.1: System Diagram 1.3.1 Sensor There are several models of Sensors. Awarepoint Sensor S2 © 2008 Awarepoint Corporation Installation Manual... -
Page 6: Awarepoint Sensor Installation
Figure 1.1-2: Awarepoint Sensor model R1 Figure 1.1-3: Awarepoint Sensor model S2 The Sensor model R1 displays its status three visual indicators in the form of Light Emitting Diodes (LEDs). The topmost LED indicates network status. Red indicates that the Sensor cannot communicate with any other devices. Yellow indicates that it can communicate with the Bridge but not the Appliance. Green means that it can communicate with the Bridge and Appliance. The middle LED indicates network activity. In normal operation, it will occasionally blink. The bottom LED (blue) indicates power. If the device is plugged into an outlet that has power then it is illuminated. The Sensor model S2 displays its status with one LED visual indicator. If it is off then the device is defective or not powered. Red indicates that the Sensor cannot communicate with any other devices. Yellow indicates that it can communicate with the Bridge but not the Appliance. Green means that it can communicate with the Bridge and Appliance. Awarepoint Sensor Installation Sensors need to be located throughout the coverage area, including along the perimeter. When installing Sensors, begin by installing Sensors near the Bridge and work progressively outward in concentric circles. In this manner, you will minimize the number of Sensors that must be moved. Prior to installing the Sensors, the Appliance and Bridge must be installed correctly. Physical Installation The Sensors are installed in standard electrical power receptacles. Prior to installing the Sensor you must locate a powered outlet. Verify that the receptacle has power by using an electrical tester. Awarepoint Sensor S2 ©... -
Page 7: Secure Awarepoint Sensors
contact the electrical prongs while they are still inserted in the outlet. For insertion or removal, grasp the sensor by the sides only. Verify the Sensor Connects to the Network Once you plug the Sensor into an outlet, it will attempt to connect to the Awarepoint network. This process will take approximately one minute. When the Sensor has completed this process, the Network LED will be illuminated Green. If the Sensor is unable to connect to the network (out of range of a network or network not properly configured), the Sensor will continue to attempt to connect to the network and the Network LED will be Red. Once the Sensor has successfully connected to the network, mark the Sensor location and its MAC address on a paper copy of the map. Place Awarepoint Sensor on Map Open the System Manager and click on the Positioning: Configuration tab. The Sensor you just installed should show up in the Unassigned section of the device tree. If it is functioning correctly, the icon for the Sensor should be green. In the device tree, expand the Campus and Building so that you can see the floor. Click on the floor to display the map for the floor. Drag the Sensor icon onto the map and place it where it is located. Figure 2‐1: Positioning: Configuration Tab ‐ Placing Awarepoint Sensor Awarepoint Sensor S2 © 2008 Awarepoint Corporation Installation Manual... -
Page 8: Troubleshooting
Finally, click the Apply button. Continue to place all Sensors. As they are placed, they will join the network. Some routing lines will be displayed as shown below. Figure 2‐2: Positioning: Configuration Tab ‐ Placing all Awarepoint Sensors Troubleshooting Customer Support: 1‐888‐TAGIT‐NOW Awarepoint Sensor If the Sensor appears Red in the Positioning: Configuration tab or on the Awarepoint Network Operations Center, the Sensor has a problem. Try the following steps: 1. Verify the Bridge nearest the Sensor is functioning correctly. Verify the Appliance is functioning correctly. 2. If multiple Sensors were down and they are all grouped together, likely these were all routing through one Sensor and that Sensor lost connectivity. Wait approximately one hour and check the status again. If the Sensors are still down, proceed to step 3. 3. Verify that the Sensor is physically present. If so, then proceed. 4. Unplug and replug the Sensor. If it is still red, replace the Sensor. If another Sensor is red in the same location, likely the Sensor is out of range of the next nearest Sensor. Move the Sensor closer to the Sensors that are working. Awarepoint Sensor S2 © 2008 Awarepoint Corporation Installation Manual...
