Summary of Contents for Sensoria EnRoute500
-
Page 1: Installation Guide
Document No. 05648-01 Rev A4 EnRoute500 Installation Guide Rev. A4 Internetworking the Physical World™ Sensoria Corporation 15950 Bernardo Center Drive, Suite J, San Diego, CA 92127 www.sensoria.com technical support email: support@sensoria.com... - Page 2 EnRoute500 Installation Guide Sensoria, the Sensoria logo and EnRoute500 are trademarks of Sensoria Corporation. All rights reserved. All other company, brand, and product names are referenced for identification purposes only and may be trademarks that are the properties of their respective owners.
-
Page 3: Fcc Notice To Users And Operators
Any changes or modification to said product not expressly approved by Sensoria Corporation could void the user's authority to operate this device. The Sensoria EnRoute500 Mesh Router must be installed by a trained professional, value added reseller, or systems integrator who is familiar with RF cell planning issues and the regulatory limits defined by the FCC for RF exposure, specifically those limits outlined in sections 1.1307. - Page 4 EnRoute500 Installation Guide EnRoute500 Interfaces The interfaces available on the EnRoute500 are power, Ethernet and 2 radio antenna ports. Mesh radio AP radio port port Power Ethernet Figure 1. EnRoute500 interfaces Interface Description Power (100-240VAC) Main Power input Radio 1 5.8GHz mesh radio antenna connector...
-
Page 5: Installation Equipment
EnRoute500 Installation Guide Installation Equipment Mounting kits that cater to different applications are available for the EnRoute 500. E500 Mounting and power kit, wall SNMNTPW-W E500 Mounting and power kit, small vertical pole SNMNTPW-V E500 Street lamp power and mounting kit, horizontal pole... - Page 6 EnRoute500 Installation Guide Vertical Pole Mounting (SNMNTPW-V) The EnRoute500 can be mounted to any vertical pole up to 1.5” using the SNMNTPW-V Vertical Pole Mount Kit. The kit includes a mounting bracket, U-bolts and the ancillary hardware necessary to affix the bracket to the enclosure.
- Page 7 The Horizontal Pole Mounting kit includes two channel bracket mounting rails, two 2” pipe support straps, four Allen screws and lock washers. It also includes a streetlight power tap adapter used for supply power to the EnRoute500. Figure 4. Streetlight horizontal pole mounting bracket kit Figure 5.
- Page 8 A ball-head Allan driver will need to be used to affix the screws. See Figure 6. Figure 6. Channel bracket positioning The EnRoute500 can be affixed to poles up 1.5” to 2” using the supplies pipe straps. Poles with diameters larger than 2” up to 4” can be accommodated with the corresponding straps.
- Page 9 EnRoute500 Installation Guide Figure 7. Channel bracket pipe strap Secure pipe straps to the pole as shown in Figure 7. Pipe strap screws should be tightened with enough force to prevent the enclosure from rotating. Channel Brackets Pipe Straps Figure 8. Pole Mount bracket installation kit...
- Page 10 Plug the opposite end of the power adapter cable into the EnRoute500. Secure any excess cabling with wire ties. If the Ethernet port is not being used, install the weather proof dust cap.
- Page 11 EnRoute500 Installation Guide Figure 11. Pole Mount bracket streetlight assembly 05648-01 Rev. A4...
- Page 12 Radio-2 is the antenna port for the 2.4GHz access point radio. Install the rubber duck style omni directional 2.4GHz 5dBi antenna on Radio-2 port. The antenna is manufactured by Wanshih. The datasheet can be viewed in the appendix. Radio 1 port Radio 2 port Figure 12. EnRoute500 radio ports 05648-01 Rev. A4...
-
Page 13: Appendix A: Safety Information For The Enroute500
OET-65 and ANSI C95.1, 1991. Proper operation of this radio according to the instructions found in this manual and the hardware and software guides on the Sensoria EnRoute500 will result in user exposure that is substantially below the FCC recommended limits. -
Page 14: Appendix B: Configuring Radio Transmit Power
2. Configure the computer that you are using to log in to the EnRoute500 to have an IP address on the same subnet as the EnRoute500. The parameters for the EnRoute500’s configuration Ethernet interface are listed in Table 2. - Page 15 EnRoute500 Installation Guide You must set the value of ‘mesh0.txpower’ to be in the range from 1 to 60 to be in compliance with FCC regulations. 7. Enter use wlan1 to select the wlan1 interface. 8. Use set txpower=<tx power>...
