- Page 1 FCC ID: NPQFCS8900 ATTACHMENT USER`S MANUAL Copyright Ⓒ 2005, DIGITAL EMC Co., Ltd.
- Page 2 FCS-8900 (Avvio8000)
-
Page 3: Table Of Contents
CONTENTS 1. SAFETY INFORMATION----------------------------------------------------------------------- 2. PREPARE YOUR PHONE FOR USE -------------------------------------------------------- 2.1 Install the battery ---------------------------------------------------------------------------- 2.2 Charge the battery --------------------------------------------------------------------------- 2.2.1 Base 2.2.2 Handy 3. FEATURE HIGHLIGHTS ---------------------------------------------------------------------- 4. ABOUT THE PHONE --------------------------------------------------------------------------- 4.1 Name and function --------------------------------------------------------------------------- 4.2 Key functions ---------------------------------------------------------------------------------- 4.3 Display indicators ----------------------------------------------------------------------------- 4.3.1 Idle screen ----------------------------------------------------------------------------... - Page 4 5.10 SMS and Voice mail-------------------------------------------------------------------------- 6. USE PHONE MENUS --------------------------------------------------------------------------- 6.1 Navigate menus ----------------------------------------------------------------------------- 6.1.1 Scroll through menus -------------------------------------------------------------- 6.1.2 Use a shortcut------------------------------------------------------------------------ 6.1.3 Exit menu levels -------------------------------------------------------------------- 6.2 List of Menus --------------------------------------------------------------------------------- 7. ENTER LETTERS AND NUMBERS ----------------------------------------------------------- 7.1 Enter Letters ----------------------------------------------------------------------------------- 7.1.1 Edit name ----------------------------------------------------------------------------- 7.1.2 Change case of letters and numbers ----------------------------------------------- 8.
- Page 5 10.5 Use Voice mail ------------------------------------------------------------------------------ 11. SET SOUND --------------------------------------------------------------------------------------- 11.1 Set Ring Type ------------------------------------------------------------------------------- 11.2 Set Ring Tone ------------------------------------------------------------------------------- 11.3 Set Ring Volume ---------------------------------------------------------------------------- 11.4 Set Key Tone -------------------------------------------------------------------------------- 11.5 Set Sound Setting---------------------------------------------------------------------------- 11.6 Set Alarm------------------------------------------------------------------------------------- 12. USE SETTINGS ------------------------------------------------------------------------------------ 12.1 Set Auto Redial ----------------------------------------------------------------------------- 12.2 Set Lift Answer ----------------------------------------------------------------------------- 12.3 Set One Touch ------------------------------------------------------------------------------...
-
Page 6: Safety Information
15. TECHNICAL INFORMATION ------------------------------------------------------------------ SAFETY INFORMATION SAFETY INFORMATION FOR FIXED PHONES For the safe and efficient operation of your phone, observe the following guidelines: EXPOSURE TO RADIO FREQUENCY (RF) ENERGY Your wireless telephone is a high power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. - Page 7 two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation. RF ENERGY INTERFERENCE / COMPATIBILITIES Note : Nearly every electronic device is susceptible to RF energy interference from external sources if in adequately shielded, designed, or otherwise configured for RF energy compatibility.
- Page 8 inflate with great force. If a phone is placed in the air bag deployment area and the air bag inflates, the phone may be propelled with great force and cause serious injury to occupants of the vehicle. Potentially Explosive Atmospheres Turn off your phone prior to entering any area with a potentially explosive atmosphere.
- Page 9 flashing lights, such as when watching television or playing video games. These seizures or blackouts may occur even if a person never had a previous seizure or blackout. If you experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your doctor.
-
Page 10: Prepare Your Phone For Use
PREPARE YOUR PHONE FOR USE 2.1 Install Battery - Base... -
Page 11: Charge The Battery
- Handy Note : To use when sudden power failure, the base battery shall be installed at all times. Charge after you insert the battery to the handset. Caution : To prevent injury or burns, do not allow metal objects to contact the battery terminals. - Page 12 Caution: At initial charging, phone should be charged at least 4 hours. After the phone is fully charged, battery icon stops scrolling. 2.2.1 Base ① Connect the lead from the charger to the side of the Base. ② Connect the charger to an AC wall outlet. Note : When you turn on the power, red LED is on.
-
Page 13: Feature Highlights
FEATURE HIGHLIGHTS Dial tone generation Auto Dialing Auto answer Voice mail Short Message Service (160 characters x 20ea) Emergency call Call logs Call restriction Caller ID Clock with alarm Cordless function (Out of range display and warning tone) Blue back light for LCD and keypad Multiple ring tones Profile setting Pager button... -
Page 14: About The Phone
Ear phone / microphone jack PC FAX Data communication through Mini USB Phone Lock ABOUT THE PHONE This phone is operated in digital mode within 800MHz frequency band. 4.1 Name and function... -
Page 15: Key Functions
Key functions Menu The functions of the selection keys depend on the Selection Key guiding texts shown above the keys. Press to directly go to Menu indicated on the screen above the key. -
Page 16: Display Indicators
Press to directly access to Search to search the phone book. Send key Press to make a call to name / number shown on the screen. Press to answer a call. Press once to enter the list of recently dialed numbers. End key Press to end a call. -
Page 17: Scroll Bar
4.3.2 Scroll bar When you access the phone’s menu, there is a scroll bar at the far left or right of the screen. This bar indicates user’s location in the menu: each “tab” on the bar represents a different menu item. Icons Icons are graphical representations of a specific item or situation. -
Page 18: Basic Operations
This indicator shows the signal strength of the wireless network at your current location. The higher the bar, the stronger signal. Roaming Status BASIC OPERATIONS Power ON and OFF Case 1 : To turn the phone on, press and hold Or, handy is automatically powered on when you place the handy on the base. -
Page 19: Make A Call
To turn the phone off, press and hold Make a call Case 1: ① Enter the phone number including the are code and press ② Press to end the call or to cancel the call attempt. If handy is placed in a base, call is automatically terminated. -
Page 20: Redial The Recent Call Number
Press to increase the volume. Press to decrease the volume. Redial the recent call number You can redial the recent call number. The maximum recent call can be stored up to 30 recently dialed or received call numbers. Stored numbers may be up to 32 digits long. ①... -
Page 21: Paging
generates “Out of Range” warning beep sound every 2 minutes. This tone lasts for 20 minutes until you close to the base. If you try to make a call during this state, handy generates error beep sound and display “Hand-Out of Range”. When handy is close to the base, “Out of Range”... -
Page 22: Use Phone Menus
A new SMS or Voice mail arrives, the back light of the handy is on and the handy displays “XX New Text” or “XX Voice Mail” and call back number on the screen. USE PHONE MENUS Navigate menus A menu is a list of choices you can make. Your phone has 6 main menus. Each main menu contains numerous submenus that allow you to use the phone book, change the ringing tone, and so on. -
Page 23: Scroll Through Menus
6.1.1 Scroll through menus From the idle screen, press Menu, and then scroll through the menu using the 6.1.2 Use a shortcut You can use a shortcut to get to options directly without scrolling through lists. 6.1.3 Exit menu levels To return the previous menu level, press Back or No. - Page 24 1. Last Call 2. All Calls 3. Received Calls 4. Dialled Calls 3. Message 1. Write Message 2. Inbox 3. Outbox 4. Erase Message 1. Inbox 2. Outbox 3. Voice Mail 4. Erase All 5. Settings 1. Save Sent SMS 2.
- Page 25 3. Ring Volume 4. Key Tone 1. Tone Length 1. Long DTMF 2. Short DTMF 2. Tone Volume 5. Sound Settings 1. Minute Alert 2. Connect Alert 3. Release Alert 4. Charge Alert 5. Error Alert 6. Alarm 1. Alarm #1 2.
-
Page 26: Enter Letters And Numbers
1. Voice 2. Data 3. Fax 2. Baud Rate 1. 230400bps 2. 115200bps 3. 19200bps 6. Security 1. Auto Lock 2. Change Code 3. Restrict 1. Receiving 2. Dialling 3. International 4. Reset ENTER LETTERS AND NUMBERS You can enter letters or numbers with phone key pad to save the information into your phone. -
Page 27: Edit Name
Characters Characters 1 . @ - ' , / : ? ( P Q R S 7 A B C 2 T U V 8 D E F 3 W X Y Z 9 G H I 4 Enter an empty space J K L 5 Changes "Abc",... -
Page 28: Use The Phone Book
USE THE PHONE BOOK About the phone book You can store up to 200 entries in the phone. Entries stored in phone allow numbers of up to 32 digits, and names of up to 33 characters. In the idle screen, you can press (Search) on the right... -
Page 29: Add A New Phone Book Entry
(Search) on the left to enter immediately Phone Book List. Add a new phone book Entry To create a phone book entry: ① Press Menu > Phone book. ② Scroll to Add New and press Select. ③ Enter the number you want to store and press Next. ④... -
Page 30: Search Name
To search a phone book list by Entry: ① Press Menu > Phone book. ② Scroll to Search Entry and press Select. ③ Entry?____ appears in the display and enter the number you want to find, or press Search to list all entries stored in the phone book. -
Page 31: My Phone
My Phone # To store your own phone number in the phone: ① Press Menu > Phonebook. ② Enter your number to store and press Save to complete. USE CALL LOGS The Call History keeps track of: Missed Calls Received Calls Dialled Calls Erase Logs Call Duration... - Page 32 Note: Your phone can store up to 30 call numbers including missed, received and dialed 확인요망 calls. ( When you miss a call(s), the message of missed call number, time and call back number appears on the screen. You can press OK after check the screen and go back to Standby.
-
Page 33: Use Sms (Short Message Service)
You can check the call time in below: Last Calls Check the call duration of the last call. All Calls Check the total call times and call duration of all outgoing calls. Received Calls Check the total times and call duration of all received calls. Dialled Calls Check the total times and call duration of all dialed calls. -
Page 34: Send A Text Message
Outbox [00] Erase Message Settings Voice Mail [00] 10.1 Send a Text Message You can send a text message to one or more recipients. You can manually enter each recipient’s phone number, or you can select the number from the phone book. Note: The maximum length of a text message differs depending on the capabilities of the network from which it originated. -
Page 35: View Inbox / Outbox
⑥ Choose one of the options in below and press Select. Send Send message to only one number. Edit Message Edit the message you wrote. Edit Number Edit the number you entered. Save Message Save message to the draft. Priority Select priority between Urgent and Normal. -
Page 36: Message Settings
④ Select One by one to delete a message one by one and press Select. Or, select Erase All to delete all in the message box. ⑤ Press Erase to delete or press Back to quit. Caution : Note that this action cannot be undone once you perform this function. 10.4 Message Settings To configure the message settings :... -
Page 37: Set Sound
SET SOUND You can set your own preference on the following functions. Ring Type Ring Tone Ring Volume Key Tone Sound Settings Alarm... -
Page 38: Set Ring Type
11.1 Set Ring Type ① Press Menu > Sound > Ring Type. ② Scroll to one of the below options you want and press Select. Ringer Slide Ringer Silent 11.2 Set Ring Tone ① Press Menu > Sound > Ring Tone. ②... -
Page 39: Set Alarm
11.6 Set Alarm When Alarm is set, the icon appears on the idle screen. You can set up to three Alarms. ① Press Menu > Sound > Alarm. ② Scroll to Alarm # you want to set and press Select. ③... -
Page 40: Set Auto Redial
Data Service 12. 1 Set Auto Redial You can set Auto Redial to enable the phone to keep trying dialing if the called party is not available. ① Press Menu > Settings > Auto Redial ② Scroll to Retry time and press Select. ③... -
Page 41: Set Lcd Contrast
10 Seconds 20 Seconds 30 Seconds 12.6 Set LCD Contrast There are 7 levels for LCD Contrast. ① Press Menu > Settings > LCD Contrast. ② Adjust contrast using and key ③ Press Select to save or Back to quit. 12.7 Set Language You can select the language you need. -
Page 42: Set Auto Lock
You must press default security code “0000” to enter into this menu and you can change security code as you want. 13.1 Set Auto Lock You can lock the phone to prevent unauthorized use of phone. Even though your phone is locked, you still can make a call to the emergency number programmed into your phone, such as 911 or any other official emergency number. -
Page 43: Reference Information
② Press Yes to reset the phone or No to quit. REFERENCE INFORMATION 14.1 Emergency Calls IMPORTANT! This phone, like any wireless phone, operates using radio signals, wireless and landline networks, and user-programmed functions. Because of this, connections in all conditions cannot be guaranteed. -
Page 44: Make An Emergency Call
wireless phone networks or when certain network services and/or phone features are in use. Check with local service providers. 14.1.1 Make an emergency call ① Enter the emergency number for your present location (for example, 911 or any other official emergency number emergency numbers vary by location). ②... - Page 45 TECHNICAL INFORMATION The model wireless phone meets the government’s requirements for exposure to radio waves. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission(FCC) of the U.S.
- Page 46 scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age or health. The exposure standard for wireless fixed phone employs a unit of measurement known as the Specific Absorption Rate, or SAR.
- Page 47 Handy : 168.0grams(0.37 lbs) Weight Base : 153.5 grams(0.33 lbs) Handy : 160.3mm(H) x 50.0mm(W) x 34.8(T) (Antenna adds 27.0mm to the height) 5.31”(H) x 1.96”(W) x 1.37”(T) Size (H x W x D) (Antenna adds 1.06” to the height) Base : 83.2mm(H) x 125.0mm(W) x 133.7mm(T) 3.27”(H) x 4.92”(W) x 5.26”(T)
